Multifunction Electronic Modules: Other Mercury Mountaineer III

Module Controlled Functions

The 2 multifunction electronic control modules on this vehicle are

1. Driver seat module (DSM)
2. Smart junction box (SJB)

Driver Seat Module (DSM)

The driver seat module (DSM) is located under the driver seat. The DSM controls the memory functions of the memory seat positions, and the adjustable pedals. The memory driver seat feature allows the driver to program a personalized seat position that can be recalled using the memory switches or the remote keyless entry (RKE) transmitter. For additional information, refer to SEATING .

Smart Junction Box (SJB)

The SJB is a combination of a multifunction control module and an interior junction box. SJB functions control multiple systems, which include

1. Exterior lamps
2. Horn
3. Illuminated entry and interior lamps
4. Power door locks
5. RKE system
6. Warning chimes
7. Windshield wiper

Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 105-R025C or equivalent

Scheme 67

Scheme 68

Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 105-R025C or equivalent

Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 69
