Maintenance Information: Overview Mercury Mountaineer I рестайлинг

PASSENGER COMPARTMENT FUSE PANEL IDENTIFICATION - 1998

Note. see scheme 7

1. 1 - 7.5 Amp - Power Mirror Switch
2. 2 - 7.5 Amp - Blower Motor Relay, PAD Module, Air Bag Diagnostic Monitor
3. 3 - 7.5 Amp - Trailer Tow Connector
4. 4 - 10 Amp - Left Headlamp
5. 5 - 10 Amp - OBDII System
6. 6 - 7.5 Amp - Air Bag System, Blower Motor Relay, PAD Module
7. 7 - 7.5 Amp - Trailer Tow Connector
8. 8 - 10 Amp - Right Headlamp, Fog Lamp Relay, Daytime Running Lamps
9. 9 - 7.5 Amp - Stop Lamp Switch
10. 10 - 7.5 Amp - Speed Control/Amplifier Assembly, Brake Pressure Switch, Generic Electronic Module (GEM), Shift Lock Actuator, Blend Door Actuator, Main Light Switch, RABS Resistor, A/C Heater Assembly, Flasher
11. 11 - 7.5 Amp - Instrument Cluster, Main Light Switch, RABS Resistor
12. 12 - 10 Amp - Power Window Relay, Washer Pump Relay
13. 13 - 20 Amp - Stop Lamp Switch, Brake Pressure Switch
14. 14 - 20 Amp - Rear Anti-Lock Brake System
15. 10 Amp - 4 Wheel Anti-Lock Brake System (4WABS) Module, 4WABS Main Module
16. 15 - 7.5 Amp - Instrument Cluster
17. 16 - 30 Amp - Windshield Wiper Motor, Wiper Hi-Lo Relay, Wiper Run/Park Relay
18. 17 - 7.5 Amp - Cigar Lighter
19. 18 - 15 Amp - Driver's Unlock Relay, All Unlock Relay, All Lock Relay
20. 19 - 25 Amp - PCM Power Diode
21. 20 - 7.5 Amp - RAP Module, Generic Electric Module (GEM), Radio
22. 21 - 15 Amp - Flasher (Hazard)
23. 22 - 20 Amp - Auxiliary Power Socket
24. 23 - 15 Amp - Turn Signals
25. 24 - Not Used
26. 25 - 7.5 Amp - Instrument Cluster, GEM System
27. 26 - 10 Amp - Battery Saver Relay, Electronic Shift Relay, Interior Lamp Relay, Power Window Relay, Electronic Shift Control Module, Transmission Control
28. 27 - 15 Amp - Switch, DRL, Backup Lamps Switch, DTR Sensor, Instrument Illuminations Dimming Module, Dome/Map Lamp, GEM, Electric Shift, Interior Lights, Glove Box Lamp & Switch
29. 28 - 7.5 Amp - GEM System
30. 29 - 15 Amp - Radio
31. 30 - 15 Amp - Park Lamp/Trailer Tow Relay
32. 31 - Not Used
33. 32 - 10 Amp - Rear Blower
34. 33 - 15 Amp - Headlamps, Daytime Running Lamps (DRL) Module, Instrument Cluster
35. 34 - 7.5 Amp - Rear Integrated Control Panel, CD
36. 35 - 10 Amp - RABS Test Connector
37. 36 - 7.5 Amp - CD, Rear Integrated Control Panel, Memory Seat, Message Center

POWER DISTRIBUTION BOX IDENTIFICATION - 1997

Scheme 1

POWER DISTRIBUTION BOX IDENTIFICATION - 1998

Scheme 2
