SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Ford FS-10 10-Cyl. |
| Compressor Belt Tension | (1) |
| System Oil Capacity | (2) 7 ozs. |
| Refrigerant (R-134a) Capacity | 30 ozs. |
| System Operating Pressures (3) |
| Low Side | 22-45 psi (1.5-3.1 kg/cm 2 ) |
| High Side | 125-225 psi (8.8-18.8 kg/cm 2 ) |
| (1) Belt tension is automatically adjusted by tensioner pulley. (2) Use YN-12c PAG Oil (Part No. F7AZ-19589-DA). (3) Approximate operating pressures with ambient temperature of 80°F (27°C). |
| (1) | Belt tension is automatically adjusted by tensioner pulley. |
| (2) | Use YN-12c PAG Oil (Part No. F7AZ-19589-DA). |
| (3) | Approximate operating pressures with ambient temperature of 80°F (27°C). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Accumulator-To-Evaporator | 26-31 (35-42) |
| Compressor Mounting Bolts | 15-21 (21-29) |
| Instrument Panel Cowl Side/ Outer Top Bolts | 19-25 (25-34) |
| Manifold & Tube Bolt | 13-17 (17-23) |
| Speed Control Servo Bolt | 7-9 (9-12) |
| INCH Lbs. (N.m) |
| Compressor Clutch Bolt | 98-123 (11-14) |
| Condenser Mounting Bolts | 75-99 (8-11) |
| Evaporator Housing-To-Dash Panel Nuts | 36-44 (4-5) |
| Heater Plenum Chamber-To-Dash Panel Nuts | 27-44 (3-5) |
| Instrument Panel Cowl Top Bolts (Inner) | 18-26 (2-3) |
| Peanut Fitting | 62-79 (7-9) |
| Power Steering Reservoir Bolts | 67-92 (8-10) |
Scheme 1
Scheme 1: VACUUM HOSE DIAGRAM(S)
Automatic A/C-Heater System Wiring Diagram (Explorer & Mountaineer - 1 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (Explorer & Mountaineer - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (Explorer & Mountaineer - 2 Of 2). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (Explorer & Mountaineer - 2 Of 2)
