Module Communications Network System: Diagnosis Mercury Montego III

Communication Devices 14 illustrations ~328 words

Inspection and Verification

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse 29 (80A) Smart junction box (SJB) fuse 9 (20A) Wiring harness Connections
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, connect the diagnostic tool to the data link connector and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
  5. If the diagnostic tool still does not communicate with the vehicle, GO to «PINPOINT TEST O»(ref-233024-S26098093452006052400000) .
  6. GO to «PINPOINT TEST PC»(ref-233024-S36160468962006052400000) .

Diagnostic Trouble Code (DTC) Index

DTCDescriptionSourceAction
U0001High Speed Communication BusDEMGO to PINPOINT TEST M .
U0002High Speed Communication Bus PerformanceInstrument ClusterGO to PINPOINT TEST M .
U0020Low Speed Communication Bus PerformanceInstrument ClusterGO to PINPOINT TEST N .
U0073High Speed Communication BusTransmission Control Module (TCM)GO to PINPOINT TEST M .
U1900CAN Communication Bus FaultABS ModuleGO to PINPOINT TEST M .
U1900CAN Communication Bus FaultAudio UnitGO to PINPOINT TEST N .
U1900CAN Communication Bus FaultDSMGO to PINPOINT TEST N .
U1900CAN Communication Bus FaultRCMGO to PINPOINT TEST M .
U1900CAN Communication Bus FaultSJBGO to PINPOINT TEST N .
U1900CAN Communication Bus Fault - Receive Error (high speed CAN)Instrument ClusterGO to PINPOINT TEST M .
U1901CAN Network #2 Communication BUS Fault - Receive Error (medium speed CAN)Instrument ClusterGO to PINPOINT TEST N .

DIAGNOSTIC TROUBLE CODE (DTC) INDEX

  1. PC1 DATA LINK DIAGNOSTICS TEST Key in ON position. Carry out the «PINPOINT TEST PC: DATA LINK DIAGNOSTICS TEST»(ref-233024-S36160468962006052400000) . Is system passed obtained? Yes : The test passed. RETURN to the Symptom Chart of the section for the module in question. No : If international standards organization (ISO) 9141 communications network circuit fault; all electronic control units no response/not equipped, GO to «PINPOINT TEST L»(ref-233024-S27650953712006052400000) . If high speed controller area network (CAN) circuit faults; all electronic control units no response/not equipped, GO to «PINPOINT TEST M»(ref-233024-S19881955352006052400000) . If medium speed CAN circuit faults; all electronic control units no response/not equipped, GO to «PINPOINT TEST N»(ref-233024-S26951296552006052400000) . If no response from the diagnostic tool, GO to «PINPOINT TEST O»(ref-233024-S26098093452006052400000) . If the module in question is no response/not equipped, GO to «SYMPTOM CHART»(ref-233024-S32786547432006052400000) .

Symptom Chart

ConditionPossible SourcesAction
The differential electronic module (DEM) does not respond to the diagnostic toolCircuit or connection in the high speed controller area network (CAN) DEMGO to PINPOINT TEST A .
The anti-lock brake system (ABS) module does not respond to the diagnostic toolCircuit or connection in the high speed controller area network (CAN) ABS moduleGO to PINPOINT TEST B .
The transmission control module (TCM) does not respond to the diagnostic tool - continuously variable transaxle (CVT)Circuit or connection in the high speed controller area network (CAN) TCMGO to PINPOINT TEST C .
The transmission control module (TCM) does not respond to the diagnostic tool - 6-speed transaxleCircuit or connection in the high speed controller area network (CAN) TCMGO to PINPOINT TEST D .
The instrument cluster does not respond to the diagnostic toolCircuit or connection in the high speed controller area network (CAN) Circuit or connection in the medium speed CAN Instrument clusterGO to PINPOINT TEST E .
The powertrain control module (PCM) does not respond to the diagnostic toolCircuit or connection in the high speed controller area network (CAN) PCMGO to PINPOINT TEST F .
The restraint control module (RCM) does not respond to the diagnostic toolCircuit or connection in the high speed controller area network (CAN) RCMGO to PINPOINT TEST G .
The audio unit does not respond to the diagnostic toolCircuit or connection in the medium speed controller area network (CAN) Audio unitGO to PINPOINT TEST H .
The driver seat module (DSM) does not respond to the diagnostic toolCircuit or connection in the medium speed controller area network (CAN) DSMGO to PINPOINT TEST I .
The dual automatic temperature control (DATC) module does not respond to the diagnostic toolCircuit or connection in the medium speed controller area network (CAN) DATC moduleGO to PINPOINT TEST J .
The digital versatile disc (DVD) player does not respond to the diagnostic toolCircuit or connection in the medium speed controller area network (CAN) DVD playerGO to PINPOINT TEST K .
The smart junction box (SJB) does not respond to the diagnostic toolCircuit or connection in the medium speed controller area network (CAN) SJBGO to PINPOINT TEST N .
The parking aid module (PAM) does not respond to the diagnostic toolCircuit or connection in the international standards organization (ISO) 9141 communications network PAMGO to PINPOINT TEST L .
No international standards organization (ISO) 9141 communications network communicationCircuit or connection in the ISO 9141 communications network Parking aid module (PAM)GO to PINPOINT TEST L .
No high speed controller area network (CAN) communicationCircuit or connection in the high speed CAN Anti-lock brake system (ABS) module Differential electronic module (DEM) (if equipped) Instrument cluster Powertrain control module (PCM) Restraint control module (RCM) Transmission control module (TCM) - 6-speed transaxle TCM - continuously variable transaxle (CVT)GO to PINPOINT TEST M .
No medium speed controller area network (CAN) communicationCircuit or connection in the medium speed CAN Audio unit Digital versatile disc (DVD) player (if equipped) Driver seat module (DSM) (if equipped) Dual automatic temperature control (DATC) module (if equipped) Instrument cluster Smart junction box (SJB)GO to PINPOINT TEST N .
No module/network communication - no power to the diagnostic toolData link connector (DLC) C251 Smart junction box (SJB) fuse 9 (20A) Circuitry Diagnostic toolGO to PINPOINT TEST O .

SYMPTOM CHART

Scheme 1

Scheme 1: Connector Circuit Reference

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14
