GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Premium Windshield Washer Concentrate (US) ZC-32-A or B (US) | WSB-M8B16-A2 |
| Premium Quality Windshield Washer Fluid (Canada) CXC-37-(A, B, C, D, E, F, G, H) (Canada) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Windshield washer reservoir bolts | 7 |
| Windshield washer reservoir nut | 7 |
| Windshield wiper mounting arm and pivot shaft assembly bolts | 5 |
| Wiper pivot arm nuts | 20 |
| Wiper motor-to-wiper mounting arm bolts | 8 |
TORQUE SPECIFICATIONS
The windshield wiper and washer system consists of the following
- Windshield wiper blade
- Windshield wiper pivot arm
- Windshield wiper mounting arm and pivot shaft
- Windshield wiper motor
- Windshield washer reservoir
- Windshield washer pump
- Check valve (integral to the washer pump)
- Multi-function switch
- SJB
If equipped with automatic headlamps, the SJB will illuminate the exterior lamps, including the parking lamps, when the front wipers are on for more than 10 seconds.
When the wiper control is set on any intermittent setting except INT 1, the speed dependent wipers will automatically adjust with the vehicle speed. This feature decreases the time between wipes when the vehicle speed increases.
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool 73III Automotive Meter 105-R00057 or equivalent Flex Probe Kit 105-R025B or equivalent SABRE Premium Battery and Electrical System Tester 010-00736 or equivalent
Scheme 1
Scheme 2
