Camshaft Position (CMP) Sensor
| Item | Specification |
|---|---|
| Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent | WSS-M2C930-A |
Material
Scheme 20
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | LH camshaft position sensor (CMP) electrical connector |
| 2 | W500214 | LH CMP bolt |
| 3 | 6B288 | LH CMP |
| 4 | W700497 | Wiring harness retainer |
| 5 | W701539 | Radio frequency interference capacitor nut |
| 6 | 18801 | Radio frequency interference capacitor |
| 7 | 14A464 | RH CMP electrical connector |
| 8 | W500214 | RH CMP bolt |
| 9 | 6B287 | RH CMP |
RH sensor
- Disconnect the wiring harness and retainer from the RH valve cover stud and position it aside.
- Remove the nut and the radio frequency interference capacitor from the RH valve cover stud and position it aside. To install, tighten to 6 Nm (53 lb-in).
- Disconnect the camshaft position sensor (CMP) electrical connector.
- Remove the bolt and the CMP sensor. To install, tighten to 10 Nm (89 lb-in).
- To install, reverse the removal procedure.
Crankshaft Position (CKP) Sensor
| Item | Specification |
|---|---|
| Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent | WSS-M2C930-A |
Material
Scheme 21
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Crankshaft position (CKP) sensor electrical connector |
| 2 | W500214 | CKP sensor bolt |
| 3 | 6C315 | CKP sensor |
| 4 | CKP sensor O-ring seal |
Heated Oxygen Sensor (HO2S) and Catalyst Monitor Sensor - Exploded View
Note. Front wheel drive (FWD) shown, all wheel drive (AWD) similar.
Scheme 22
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Heated oxygen sensor (HO2S) electrical connectors |
| 2 | 9F472 | HO2S |
| 3 | 14A464 | Catalyst monitor sensor (CMS) electrical connectors |
| 4 | 9G444 | CMS |
- For additional information, refer to the appropriate procedures.
Heated Oxygen Sensor (HO2S)
Special Tools Illustration Tool Name Tool Number Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)
| Item | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 (US); CXG-2-B (Canada) | ESE-M12A4-A |
| Penetrating and Lock Lubricant XL-1 (US); CXC-51-A (Canada) |
Material
Catalyst Monitor Sensor
Special Tools Illustration Tool Name Tool Number Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)
| Item | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 (US); CXG-2-B (Canada) | ESE-M12A4-A |
| Penetrating and Lock Lubricant XL-1 (US); CXC-51-A (Canada) |
Material
