GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants and Chemicals | |
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
| Engine Ignition | |
| Spark plug gap | 1.25-1.35 mm (0.049-0.053 in) |
| Spark plug | 6M8G-12405-BB |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Ignition coil-on-plug bolts | 10 |
| Spark plugs | 12 |
| Generator inlet duct | 6 |
TORQUE SPECIFICATIONS
The electronic ignition (EI) system is a coil-on-plug ignition system. The coil-on-plug ignition system consists of the
- coil-on-plug.
- spark plugs.
- crankshaft position (CKP) sensor.
- camshaft position (CMP) sensor.
The coil-on-plugs
- change low voltage signals from the powertrain control module (PCM) to high voltage pulses.
- produce the high voltage pulses to the spark plugs.
- are connected directly to each spark plug.
The spark plugs
- change high voltage pulses into a spark which ignites the fuel and air mixture.
The CKP sensor
- is a variable reluctance sensor.
- is triggered by a 36-minus-1 tooth trigger wheel mounted on the crankshaft.
- provides base timing and crankshaft speed (rpm) to the PCM.
The CMP sensor
- is a Hall-effect sensor.
- provides camshaft rotational location information to the PCM.
Refer to the Introduction - Gasoline Engines .
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Ignition coil-on-plug electrical connector (4 required) (part of 12B637) |
| 2 | W500215 | Ignition coil-on-plug bolt (4 required) |
| 3 | 12A366 | Ignition coil-on-plug (4 required) |
| 4 | 12405 | Spark plug (4 required) |
- For additional information, refer to the appropriate procedures.
