GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator, 2.3L | |
| Rating | 90/150 amp (max) @ 1,800-6,000 generator rpm, approximately 700-2,500 engine rpm |
| Generator pulley ratio | 2.45:1 |
| Voltage regulator type | Electronic internal with generator |
| Generator, 3.0L | |
| Rating | 90/150 amp (max) @ 1,800-6,000 generator rpm, approximately 500-2,000 engine rpm |
| Generator pulley ratio | 2.60:1 |
| Voltage regulator type | Electronic internal with generator |
| Generator, 3.5L | |
| Rating | 90/150 amp (max) @ 1,800-6,000 generator rpm, approximately 500-2,000 engine rpm |
| Generator pulley ratio | 2.66:1 |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Generator B+ terminal nut | 12 |
| Generator bolts | 47 |
| Generator lower air duct bolts (2.3L) | 4 |
| Generator nuts | 47 |
| Generator shield nuts (2.3L) | 25 |
| Generator stud bolts (2.3L) | 24 |
| Generator stud bolt (3.0L) | 47 |
| Generator stud (3.5L) | 8 |
| Generator upper air duct bolt (2.3L) | 8 |
| Generator upper air duct nuts (2.3L) | 8 |
TORQUE SPECIFICATIONS
The generator is belt-driven by the engine accessory drive system. The generator has an internal voltage regulator that is not replaced separately. The generator and voltage regulator are repaired as an assembly.
Refer to CHARGING SYSTEM - GENERAL INFORMATION .
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | Generator upper air duct bolt | |
| 2 | W707944 | Generator upper air duct nuts (2 required) |
| 3 | 10C392 | Generator upper air duct |
| 4 | 6A228 | Front end accessory drive belt tensioner |
| 5 | 6C301 | Front end accessory drive belt |
| 6 | W520414 | Generator shield nuts (2 required) |
| 7 | 10A346 | Generator shield |
| 8 | 10C392 | Generator intermediate air duct |
| 9 | W706414 | Generator B+ terminal nut |
| 10 | Generator B+ terminal (part of 14B060) | |
| 11 | Generator harness locator (part of 12B637) | |
| 12 | Generator electrical connector (part of 12B637) | |
| 13 | Generator harness locator (part of 12B637) | |
| 14 | Crankshaft position (CKP) electrical connector (part of 12B637) | |
| 15 | W500131 | Generator bolt |
| 16 | W520414 | Generator nuts (2 required) |
| 17 | 10300 | Generator |
| 18 | W503254 | Generator lower air duct bolts (3 required) |
| 19 | 10C392 | Generator lower air duct |
| 20 | W712013 | Generator stud bolts (2 required) |
