Power Windows Mercury Capri III

Windows 26 illustrations ~2396 words

DESCRIPTION & OPERATION

WARNINGVehicles are equipped with air bag supplemental restraint system. Before attempting ANY repairs involving steering column, instrument panel or related components, see SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in appropriate AIR BAG RESTRAINT SYSTEMS article.

The power windows system is powered from the Ignition Switch through the POWER WIND fuse (30 amp) of the Interior Fuse Panel and is hot when the Ignition Switch is in the START or RUN positions. When either of the two Window Switches are activated, current flows from the Ignition Switch through the Window Switch(es) to one lead of the Power Window Motor for UP or the other lead for DOWN.

The current causes the Power Window Motor to rotate in a clockwise or counterclockwise direction to raise or lower the window. Both motor leads are grounded through the Power Window Main Switch when all the Window Switches are OFF. The Driver's side has a Power Window Main Switch which can raise or lower any of the windows. The Power Window Main Switch has a lock switch which cuts the power to the right hand Power Window Switch. This allows only the driver to operate the windows.

COMPONENT LOCATIONS

ComponentLocation
Ground G103Left Front Corner of Engine Compartment. (Scheme 1)
Ground G200Behind Left, Center of Dash. (Scheme 2)
Interior Fuse PanelLower Left Side Of Instrument Panel
Left Power Window MotorIn Left Door
Power Window Main SwitchIn Left Door
Right Power Window MotorIn Right Door
Right Power Window SwitchIn Right Door

COMPONENT LOCATIONS

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

LUBRICATION

The front door windows are operated by two encased cables. The cables are attached from the motor to the regulator's slider bracket. The cables are secured by nylon fasteners inside the door. Lubrication of the cables is not necessary. The door window mechanism should be well-lubricated to provide ease of operation.

The mechanism should be lubricated whenever the glass channel or window regulator is removed or when excessive effort is required to operate the windows. To lubricate the door window mechanism, apply an even coating of Multi-Purpose Grease (DOAZ-19584-A), or equivalent, to the window regulator guides and entire length of channel. (Scheme 4)

Scheme 4

Scheme 4: LUBRICATION
Scheme 4: LUBRICATION

DOOR GLASS HEIGHT STOP ADJUSTMENT

  1. Lower window.
  2. Remove lower door trim panel. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.
  3. Loosen height stop bracket retaining screw. (Scheme 5)
  4. Raise door glass until it is seated correctly in weatherstrip.
  5. Tighten height stop bracket to 62-88 INCH Lbs. (7-10 N. m).
  6. Lower and raise door glass to make sure alignment is correct.
  7. Install lower door trim panel. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.

DOOR GLASS LATERAL ADJUSTMENT

  1. Make sure upper edge of door glass is seated under lip of weatherstrip when glass is fully raised. (Scheme 5) If adjustment is required, proceed to next step.
  2. Leave door glass in raised position.
  3. Remove lower door trim panel. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.
  4. Loosen adjuster locknut at lower end of front door glass channel.
  5. Turn adjuster screw in or out to obtain correct positioning of glass under weatherstrip.
  6. Tighten adjuster locknut to 45-61 INCH Lbs. (5-7 N. m). (Scheme 6)
  7. Raise and lower door glass to ensure adjustment is correct.
  8. Install lower door trim panel. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

DOOR GLASS LONGITUDINAL ADJUSTMENT

  1. Make sure full length of door glass is seated under lip of weatherstrip when door glass is fully raised. (Scheme 5)
  2. Remove lower door trim panel and watershields. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.
  3. Working through openings in door, loosen two regulator-to-glass bolts. (Scheme 6)
  4. Align door glass so it contacts weatherstrip evenly front-to-back and is fully seated in weatherstrip.
  5. Tighten regulator-to-glass bolts to 45-61 INCH Lbs (5-7 N. m)
  6. Lower and raise door glass several times to make sure alignment is correct.
  7. Install watershields and lower door trim panel. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.

DOOR GLASS REAR CHANNEL ADJUSTMENT

Note. The rear channel adjustment must be correct to ensure that door glass moves freely up and down.

  1. Lower door glass.
  2. Remove lower door trim panel. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.
  3. Loosen two longitudinal adjustment bolts on rear channel adjuster. (Scheme 6)
  4. Raise and lower door glass, then tighten adjustment bolts to 24-28 INCH Lbs. (2.7-3.2 N. m).
  5. Loosen lateral adjuster screw locknut and turn adjuster screw in or out to relieve any tension on door glass channel. Tighten locknut to 45-61 INCH Lbs. (5-7 N. m).
  6. Raise and lower door glass to ensure it moves freely up and down.
  7. Install lower door trim panel. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows) under REMOVAL & INSTALLATION.

WEATHERSTRIP

  1. Loosen four weatherstrip retaining screws. (Scheme 7)
  2. Position weatherstrip so metal frame is even with lower edge of convertible top side rail.
  3. Tighten retaining screws to 23-28 INCH Lbs. (2.5-3.2 N. m).

Scheme 7

Scheme 7
Scheme 7

SYSTEM INSPECTION

Visually inspect the components of the power windows system. See POWER WINDOW SYSTEM INSPECTION table. With the key in the RUN position, operate all the power window switches and listen to the motor for any mechanical concerns. With the key in the RUN position, operate all the power window switches and verify the condition.

MechanicalElectrical
Window AlignmentBlown Fuse
Window MountingWiring Harness
Window Frame InterferencePoor Connections
Noise—

POWER WINDOW SYSTEM INSPECTION

Possible Sources

Possible source(s) or problem.

  1. Fuse
  2. Power circuit
  3. Ground circuit
  4. Power window main switch

Action To Take

Go to A1: Check Fuse under POWER WINDOW SYSTEM PINPOINT TEST.

Possible source(s) or problem.

  1. Power window motor
  2. Power window motor circuit
  3. Power window main switch

Go to A7: Check Power Window Main Switch under POWER WINDOW SYSTEM PINPOINT TEST.

Possible source(s) of problem.

  1. Power window motor
  2. Power window passenger switch
  3. Power window motor circuit
  4. Power window passenger switch power circuit

Go to A8: Check Wire To Passenger Switch under POWER WINDOW SYSTEM PINPOINT TEST.

TESTING PROCEDURE

Do NOT start POWER WINDOW PINPOINT TEST before going to TROUBLE SHOOTING section. Find symptom that matches problem with vehicle. Symptom trouble shooting will direct you to appropriate pinpoint test.

A1: Check Fuse

Locate the interior fuse panel. Turn the ignition switch to OFF. Remove and inspect 30 amp POWER WINDOW fuse. Is fuse okay? If yes, then go to A5: Check Power Supply To Power Window Main Switch . If not, then go to next step.

A2: Check System

Replace 30 amp POWER WINDOW fuse. Turn the ignition switch to ON. Reinspect the 30 amp POWER WINDOW fuse. Does the fuse fail again? If yes, then go to A3: Check Power Window Operation . If no, go to A4: Check For Short To Ground .

A3: Check Power Window Operation

Turn the ignition switch to ON. Operate all power windows with switches one at a time. Are power windows operating properly? If yes, then system is functioning properly at this time. If not, then go to A5: Check Power Supply To Power Window Main Switch .

A4: Check For Short To Ground

Turn ignition switch to OFF. Locate and disconnect interior fuse panel connector. Disconnect power window main switch. Measure resistance between Black/Red wire at interior fuse panel connector and ground. See WIRING DIAGRAMS . Is resistance greater then 10,000 ohms? If yes, then replace power window main switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION. If not, then repair Black/Red wire. Retest system for normal operation.

A5: Check Power Supply To Power Window Main Switch

Disconnect power window main switch. Turn ignition switch to ON. Measure voltage on Black/Red wire at power window main switch connector. See WIRING DIAGRAMS . See WIRING DIAGRAMS . Is the voltage 10 volts or greater? If yes, then go to A6: Check Power Window Main Switch Ground . If not, then repair Black/Red wire between power window main switch and interior fuse panel.

A6: Check Power Window Main Switch Ground

Turn ignition switch to OFF. Disconnect power window main switch. Measure resistance between Black wire at power window main switch connector and ground. See WIRING DIAGRAMS . Is resistance less than 5 ohms? If yes, then go to A7: Check Power Window Main Switch . If not, then repair Black wire between power window main switch and ground.

A7: Check Power Window Main Switch

Turn ignition on, with engine off. Locate power window main switch. Check voltages between Black wire and and other terminals. See WIRING DIAGRAMS. (Scheme 6) If all voltages are not correct, replace power window main switch. If all voltages ARE correct, and driver's windows does not work, go to A11: Check Power Window Motor Circuit Continuity. If all voltages ARE correct and passenger's window does not work, go to A8: Check Wire To Passenger Switch.

Scheme 8

Scheme 8: A7: Check Power Window Main Switch
Scheme 8: A7: Check Power Window Main Switch

A8: Check Wire To Passenger Switch

Disconnect passenger power window switch. Turn ignition switch to ON. Push power switch on power window main switch to ON position. Measure voltage on Black/Blue wire at passenger power window switch connector. See WIRING DIAGRAMS . Is the voltage 10 volts or greater? If yes, then go to A9: Check Passenger Switch Circuit Continuity . If not, then repair Black/Blue wire between power window main switch and passenger power window switch.

A9: Check Passenger Switch Circuit Continuity

Turn ignition switch to OFF. Disconnect power window main switch. Disconnect power window passenger switch. Measure resistance of the Green/Black and Red/Black wires between the main switch connector and the passenger switch connector. See WIRING DIAGRAMS . Is the resistance less than 5 ohms? If yes then go to A10: Check Power Window Passenger Switch . If not, then repair Green/Black and Red/Black wires between main switch and passenger switch.

A10: Check Power Window Passenger Switch

Turn on ignition, with engine off. Push power switch on main switch to ON position. Check voltages between specified wiring and ground while moving the switch.

  1. UP: Green wire should be less than 1 volt. Red wire should be more than 10 volts.
  2. DOWN: Green wire should be more than 10 volts. Red wire should be less than 1 volt.

If power window switch is okay, go to

. Replace if defective, then retest system for normal operation.

A11: Check Power Window Motor Circuit Continuity

Turn ignition switch to OFF. Disconnect power window main switch, passenger switch and window motors. Measure resistance of the Red and Green wires between the power window switches and power window motors. See WIRING DIAGRAMS . If resistance is less than 5 ohms, go to A12: Check Power Window Motor Function . If resistance is not less than 5 ohms, repair wiring between power window switches and power window motors. Retest system for normal operation.

A12: Check Power Window Motor Function

Test power window motor. See MOTOR under COMPONENT TESTS. Replace if necessary. See MOTOR under REMOVAL & INSTALLATION. If motor is okay, retest system for normal operation.

MOTOR

Disconnect power window motor. Apply 12 volts to one lead of the power window motor connector and ground the other lead for at least two seconds. Reverse polarity of the leads for at least two seconds. The motor should operate in both directions. Replace motor if necessary. See MOTOR under REMOVAL & INSTALLATION.

REMOVAL & INSTALLATION

CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

Scheme 9

Scheme 9: Removal & Installation
Scheme 9: Removal & Installation

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
  1. Remove three screws and lower door trim panel. (Scheme 9)
  2. With flat-bladed screwdriver, carefully pry off pull handle cover. (Scheme 10)
  3. Remove two screws and pull handle.
  4. Remove one screw at inner door latch release lever. (Scheme 11)
  5. Remove two screws from the front and two screws from the rear of upper door trim panel.
  6. Remove three screws at lower edge of upper trim panel.
  7. Remove mirror trim cover.
  8. Disconnect wiring harness at power window switch. Remove window switch assembly from door panel.
  9. Remove speaker and disconnect connector.
  10. Remove handle reinforcement bracket from door if necessary. (Scheme 12)
  11. Remove watershield.
  12. To install, reverse removal procedure.

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13: Removal & Installation
Scheme 13: Removal & Installation

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Remove door trim panel and watershield. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows). Leave power window switch connected.
  2. Remove screw and end seal. (Scheme 13)
  3. Remove outer weatherstrip. (Scheme 14)
  4. Remove rear inner weatherstrip. (Scheme 15)
  5. Remove guide bolts and allow guide to drop to the bottom of channel.
  6. Support window and remove both regulator slider retaining bolts. (Scheme 16)
  7. Remove window glass from door.
  8. Remove nut, washer, grommet, and spacer as required. (Scheme 17)
  9. To install, reverse removal procedure. Adjust door glass. See «DOOR GLASS HEIGHT STOP ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-height-stop-adjustment), «DOOR GLASS LATERAL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-lateral-adjustment), «DOOR GLASS LONGITUDINAL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-longitudinal-adjustment) and «DOOR GLASS REAR CHANNEL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-rear-channel-adjustment) under ADJUSTMENTS.
  1. Raise the window and support in the full-up position. If the glass cannot be raised and is in a partially down or full-down position, it must be supported so that it will not fall into the door during removal of the motor.
  2. Remove door trim panel and watershield. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows).
  3. Disconnect window motor electrical connector.
  4. Remove three window motor retaining rivets.
  5. Remove the three nuts securing window slide track to door frame. (Scheme 18)
  6. Remove two bolts retaining regulator slider to window. (Scheme 19)
  7. Remove motor, regulator cables and slide track as a unit.
  8. Remove stop bracket if necessary. (Scheme 20)
  9. To install, reverse removal procedure. Adjust door glass. See «DOOR GLASS HEIGHT STOP ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-height-stop-adjustment), «DOOR GLASS LATERAL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-lateral-adjustment), «DOOR GLASS LONGITUDINAL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-longitudinal-adjustment) and «DOOR GLASS REAR CHANNEL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-rear-channel-adjustment) under ADJUSTMENTS.

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Remove door trim panel and watershield. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows).
  2. Disconnect electrical connector at switch. (Scheme 21)
  3. Depress metal retainers on bottom of switch, and push switch out of door trim panel. (Scheme 22)
  4. To install, reverse removal procedure.

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Remove door trim panel and watershield. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows).
  2. Remove window glass. See «DOOR GLASS»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows).
  3. Remove upper nut and washer. (Scheme 23)
  4. Remove two screws connecting adjuster assembly.
  5. Remove rear channel assembly.
  6. To install, reverse removal procedure. Adjust door glass. See «DOOR GLASS HEIGHT STOP ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-height-stop-adjustment), «DOOR GLASS LATERAL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-lateral-adjustment), «DOOR GLASS LONGITUDINAL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-longitudinal-adjustment) and «DOOR GLASS REAR CHANNEL ADJUSTMENT»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows__door-glass-rear-channel-adjustment) under ADJUSTMENTS.

Scheme 23

Scheme 23
Scheme 23
  1. Remove door trim panel and watershield. See «DOOR TRIM PANEL»(/mercury/capri/iii-1990-1995/remont/windows/#power-windows). Leave power window switch connected.
  2. Position window to allow access to guide retaining bolts.
  3. Remove bolts and slide guide out from channel. (Scheme 24)
  4. To install, reverse removal procedure.

Scheme 24

Scheme 24
Scheme 24

TORQUE SPECIFICATIONS

ApplicationINCH Lbs. (N. m)
Door Glass Channel Adjuster
Bolt24-28 (2.7-3.2)
Locknut45-61 (5-7)
Height Stop Adjustment Bracket62-88 (7-10)
Regulator-To-Glass Bolts45-61 (5-7)
Shingle Weatherstrip Screws23-28 (2.5-3.2)

TORQUE SPECIFICATIONS

Scheme 25

Scheme 25: WIRING DIAGRAMS
Scheme 25: WIRING DIAGRAMS

Scheme 26

Scheme 26
Scheme 26
