Rear door control module, location - GF91.16-P-4102-01S
The head restraint adjustment raise/lower switches (N69/3s8)/(N69/4s8) are located in the left rear door control module (N69/3)/right rear door control module (N69/4) in the left and right rear door.
Identifying Rear Door Control Module Location. Scheme 28
Multi-contour seat switches, location/purpose/design/function - GF91.25-P-2100S
MODEL 215, 220 with CODE (404b) Driver's seat with multi-contour backrest
MODEL 215, 220 with CODE (405b) Passenger seat with multi-contour backrest
MODEL 220 with CODE (224c) Rear bucket seats, electrically adjustable, with seat ventilation, seat heater and memory package
| Multi-contour seat switches, location | GF91.25-P-2100-01S | ||
|---|---|---|---|
| Multi-contour seat switches, purpose | Manually inflating and deflating lumbar cushion group, side backrest cushions and also, on front seats only, shoulder cushion group. An additional switch serves for activating and deactivating the dynamic lumbar adjustment feature. | ||
| Multi-contour seat switches, design | Model 215 | GF91.25-P-2100-02A | |
| Model 220 | GF91.25-P-2100-02S | ||
| Multi-contour seat switches, function | The switch positions are voltage-coded by means of resistors. The coded voltages are then read in by the corresponding multicontour backrest control module. |
Multicontour seat control module, location/task/design/function - GF91.25-P-2101S
MODELS 215, 220 up to 31.8.02 with CODE (404b) Multicontour backrest driver seat
MODELS 215, 220 up to 31.8.02 with CODE (405b) Multicontour backrest passenger seat
MODEL 220 up to 31.8.02 with CODE (224c) Electrically adjustable rear single seats, with seat ventilation, seat heater and memory package
Location left front multicontour backrest control module/right front multicontour backrest control module
Identifying Front Seat Adjustment Motor Group Components Location - Shown On Model 220. Scheme 29
Location on model 220 only
Rear multicontour backrests control module
Identifying Rear Multicontour Backrests Control Module Location. Scheme 30
| Multicontour seat control module, location | The left front multicontour backrest control module (N32/15)/the right front multicontour backrest control module (N32/16) is located under the respective seat. The rear multicontour backrest control module (N32/14) is located under the right half of the rear seat bench. | ||
|---|---|---|---|
| Multicontour seat control module, task | GF91.25-P-2101-02S | ||
| Multicontour seat control module, design | Apart from the actuation/evaluation electronics, pressure control valves (one for each air cushion) are located in all control modules of the multicontour backrests. The air cushions are filled and emptied via these pressure control valves. | ||
| Multicontour seat control module, function | The control module reads in the switch conditions of the switch groups of the multicontour backrests, detects the air pressure in the air cushions via piezoresistive pressure sensors, actuates the pressure control valves and receives/sends data from/to the respective seat control module. | ||
| GF54.30-P-3017A |
Dynamic seat control module location/task - GF91.25-P-2105S
MODELS 215, 220 with CODE (433) Left dynamic seat, incl. multicontour seat with CODE (434) Right dynamic seat, incl. multicontour seat
Location
Dynamic seat control module
Identifying Right Front Seat Adjustment Control Module With Memory Location - Shown On Model 220. Scheme 31
| Dynamic seat control module location | The left front dynamic seat control module (N32/19) and right front dynamic seat control module (N32/22) is located in the respective seat backrests on the driver's/front passenger's side. | ||
|---|---|---|---|
| Dynamic seat control module location | GF91.25-P-2105-01S |
Dynamic seat control module location - GF91.25-P-2105-01S
Tasks
- To fill and empty the multicontour backrest in accordance with the requirements read in by the switch
- Control of dynamic lumbar support, triggered by the multicontour backrest switch with the inscription: "PULSE"
- Control of dynamic lateral support triggered by the "DYNAMIC" switch
- Detection of the actual pressure values of the air cushions by piezoresistive pressure sensors and keeping these pressures constant
- Reading in the voltage-coded MMKL adjusting switch and the DYNAMIC switch
- Communication with the interior CAN via the respective seat control module
- Adjusting the stored pressure values when calling up the memory feature and storing the actual contours
- Cutout of the respective function if the pressure control valve responsible has overheated
Dynamic seat switch, location/task - GF91.25-P-2110S
MODEL 220 as of 1.9.02 with CODE (433) Left dynamic seat, incl. multicontour seat with CODE (434) Right dynamic seat, incl. multicontour seat
Location
Dynamic seat switch
Identifying Dynamic Seat Switches Location. Scheme 32
| Dynamic seat switch, location | The right/left front DS [FDS] switch group (S108/1;S109/1) in each case is located under the front multicontour backrest switch group on the seat cushion. | ||
|---|---|---|---|
| Dynamic seat switch, task | To switch the dynamic lateral support function on and off. |
Rear seat control module, location/task/design/function - GF91.29-P-2108S
MODEL 220 with CODE (223b) Electrically adjustable rear bench seat
MODEL 220 with CODE (224c) Electrically adjustable rear single seats, with seat ventilation, seat heater and memory package
MODEL 220 with CODE (402a) Seat ventilation of rear seats
MODEL 220 with CODE (872) Electrically heated left and right rear seats
Illustration shows
Identifying Rear Seat Control Module Location. Scheme 33
| Rear seat control module, location | The rear seats control module (N25/6) is located under the right half of the rear bench seat/under the right rear seat. | ||
|---|---|---|---|
| Rear seat control module, task | Control of heated rear seats (special equipment) Control of rear seat ventilation (special equipment) Reading in and actuation of components of these systems Communication with the multicontour backrest control module (special equipment) | ||
| Rear seat control module, design | The control module is accommodated in the stable plastic housing. Power semiconductors which actuate the consumers directly are located in the control module. The electrical connection is via eight connectors. | ||
| Electric seat adjustment (ESA) function | GF91.29-P-0004S | ||
| Seat ventilation function | GF91.30-P-0002S | ||
| Heated seats (HS) function | GF91.30-P-0003S |
Rear compartment control module, location/task/design - GF91.29-P-2111A
MODEL 215
Illustration shows
Identifying Rear Compartment Control Module Location. Scheme 34
| Rear control module location | The rear control module (N22/6) is located under the right half of the rear bench seat. | ||
|---|---|---|---|
| Rear seat control module, task | GF91.29-P-2111-01A | ||
| Rear seat control module, design | For the electrical connection the CAN-capable control module has two multipin plug sockets. | ||
| Rear seat control module, function | The control module has an undervoltage and overvoltage cut-out. The power outputs are resistant to short-circuits. |
Heated seats/seat ventilation switch location/task - GF91.30-P-3004S
MODEL 220 with CODE (401a) Front luxury seat, incl. heated seat and seat ventilation
MODEL 220 with CODE (402a) Seat ventilation of rear seats
MODELS 215, 220 with CODE (873) Electrically heated left and right front seats
MODEL 220 with CODE (872) Electrically heated left and right rear seats
Location of the component shown on MODEL 220
Identifying Heated Seats/Seat Ventilation Switch Components Location - Shown On Model 220. Scheme 35
| Seat heating/seat ventilation switches, location | The two switches for operating the heated seats/seat ventilation are located in the door control modules for left front (N69/1), right front (N69/2), left rear (N69/3) and right rear (N69/4). | ||
|---|---|---|---|
| Seat heating/seat ventilation switches, task | Using the two switches, the heated seats/seat ventilation can be switched on, over and off in stages. The operating condition of the heated seats/seat ventilation is indicated in this case by LEDs which are positioned above the switches. |
Front seat ventilation motors, location/task/design/function - GF91.30-P-3100S
MODELS 215, 220 up to 31.8.02 with CODE (401a) Front luxury seat, incl. heated seat and seat ventilation
Shown on Model 220
Identifying Front Seat Ventilation Motors Location - Model 220. Scheme 36
| Front seat ventilation motors, location | The motor groups for the seat ventilation are installed in the seat cushion and seat backrest of the respective seat. | ||
|---|---|---|---|
| Front seat ventilation motors, task | Active ventilation of seat cushion and backrest. | ||
| Front seat ventilation motors, design | The motor group for the seat cushion ventilation has six fan motors (MODEL 215: 4 motors). The motor group for the seat backrest ventilation has four fan motors. Each motor drives a small ventilator that produces a flow of air. | ||
| Front seat ventilation motors, unction | The motors in each motor group are connected in parallel. They are actuated by the relevant seat control module. The actuation signal at the control module output is boosted by a discrete regulator. |
Front seat ventilation motors, location/task/design/function - GF91.30-P-3100SS
MODELS 215, 220 as of 1.9.02 with CODE (401a) Front luxury seat, incl. heated seat and seat ventilation
Location of the component shown on MODEL 220
Scheme 37
| Front seat ventilation motors, location | The motors for the seat backrest ventilation are installed in the respective backrest lining. The motor group now comprises two fans with enlarged diameter. No change is planned for the motors of the seat cushion ventilation. | ||
|---|---|---|---|
| Front seat ventilation motors, task | Active ventilation of seat cushion and backrest. | ||
| Front seat ventilation motors, design | The seat cushion ventilation has six fan motors (MODEL 215: 4 motors). The seat backrest ventilation now comprises two fans with enlarged diameter. Each motor drives a small ventilator that produces a flow of air. | ||
| Front seat ventilation motors, function | The motors in each motor group are connected in parallel. They are actuated by the relevant seat control module. The actuation signal at the control module output is boosted by a regulator. |
Front seat ventilation motors, location - GF91.30-P-3100-01S
Model 215, model 220
Illustrated on model 220
Identifying Steering Wheel, Airbag (Folded Together), Gas Generator, Housing And Pad. Scheme 38
Rear seat ventilation motors, location/task/design/function - GF91.30-P-3101S
MODEL 220 up to 31.8.02 with CODE (402a) Seat ventilation of rear seats
Location of the component shown on the front seat of MODEL 220
Identifying Passenger Airbag Components Location. Scheme 39
| Rear seat ventilation motors, location | The individual motors for the seat ventilation are located in the rear seats in the same way as in the front seats. | GF91.30-P-3100-01S | |
|---|---|---|---|
| Rear seat ventilation motors, task | Active ventilation of seat cushion and backrest. | ||
| Rear seat ventilation motors, design | The rear seat cushion ventilation on left/right has four fan motors each. The rear seat backrest ventilation on left/right now has two fan motors each. Each motor drives a small ventilator that produces a flow of air. | ||
| Rear seat ventilation motors, function | The motors in each motor group are connected in parallel. They are actuated via the control module for rear seats (N25/6). The actuation signal at the control module output is boosted by a blower regulator for rear seat ventilation on left (N29/3)/right (N29/4). |
Rear seat ventilation motors, location/task/design/function - GF91.30-P-3101SS
MODEL 220 as of 1.9.02 with CODE (402a) Seat ventilation of rear seats
Location of the component shown on MODEL 220
Identifying Passenger Airbag, Function. Scheme 40
| Rear seat ventilation motors, location | The individual motors for the seat ventilation are located in the individual rear seats in the same way as in the front seats. | ||
|---|---|---|---|
| Rear seat ventilation motors, task | Active ventilation of seat cushion and backrest. | ||
| Rear seat ventilation motors, design | The motor groups for rear seat cushion ventilation on left/right have four fan motors each. The rear seat backrest ventilation on left/right now has two fan motors with enlarged diameter each. Each motor drives a small fan. | ||
| Rear seat ventilation motors, function | The motors in each motor group are connected in parallel. They are actuated via the control module for rear seats (N25/6). The actuation signal at the control module output is boosted by the blower regulator for rear seat ventilation on left (N29/3)/right (N29/4). |
Seat ventilation blower regulator, location/task/design/function - GF91.30-P-3102S
MODEL 210 as of 1.7.99, 215, 220 with CODE (401a) Front luxury seat, incl. heated seat and seat ventilation
MODEL 220 with CODE (402a) Seat ventilation of rear seats
Location of component shown on the left front seat (MODEL 220)
Scheme 41
| Seat ventilation blower regulator, location | The blower regulators for left front seat ventilation (N29/5), right front seat ventilation (N29/6), left rear seat ventilation (N29/3) and right rear seat ventilation (N29/4) are located in the backrest of the respective seat. | ||
|---|---|---|---|
| Seat ventilation blower regulator, purpose | The blower regulators for front seat ventilation on left (N29/5)/right (N29/6), as well as for MODEL 220 the blower regulator for rear seat ventilation on left (N29/3)/right (N29/4) boost the actuation voltage from the control module for the motors of the seat ventilation. | ||
| Seat ventilation blower regulator, design | The blower regulators are discrete elements, which are connected between the control module and the motors. | ||
| Seat ventilation blower regulator, function | The blower regulators are designed as non- overloading regulators. |
Front emergency tensioning retractor, location/task/design/function - GF91.40-P-4000C
MODEL 215 up to 31.8.02
Arrangement of components
Identifying Front Emergency Tensioning Retractor Location. Scheme 42
| Front emergency belt tensioner - task | The emergency tensioning retractor eliminates seat belt slack in the event of a crash (front and rear collision) and prevents the seat belt's film reel effect. The close-fitting seat belt means that vehicle occupants are exposed to the deceleration forces acting on the body at an earlier stage. | ||
|---|---|---|---|
| Front emergency tensioning retractor, design | GF91.40-P-4000-02S | ||
| Front emergency belt tensioner - function | GF91.40-P-4000-03S |
Front emergency tensioning retractor, location/task/design/function - GF91.40-P-4000M
MODEL 220 as of 1.9.02
Driver and passenger emergency tensioning retractors
Identifying Window Airbag Components Location. Scheme 43
| Front emergency belt tensioner, location | The driver ETR [GUS] ignition squib (R12/1) and passenger ETR [GUS] ignition squib (R12/2) are located at the bottom of the respective B-pillar behind the plastic lining. | ||
|---|---|---|---|
| Front emergency belt tensioner - task | The emergency tensioning retractor serves to take up the slack in the seat belt in the event of a crash (frontal or rear end collision) and prevents the seat belt's film reel effect. The close-fitting seat belt means that vehicle occupants are exposed to the deceleration forces acting on the body at an earlier stage. | ||
| Front emergency tensioning retractor, design | GF91.40-P-4000-02S | ||
| Front emergency belt tensioner - function | GF91.40-P-4000-03S |
Front emergency tensioning retractor, location/task/design/function - GF91.40-P-4000N
MODEL 215 as of 1.9.02
Driver and passenger emergency tensioning retractors
Identifying Front Emergency Tensioning Retractor Location - Model 215 As Of 1.9.02. Scheme 44
| Front emergency belt tensioner, location | The driver ETR [GUS] ignition squib (R12/1) and passenger ETR [GUS] ignition squib (R12/2) are located at the bottom of the respective B-pillar behind the plastic lining. | ||
|---|---|---|---|
| Front emergency belt tensioner - task | The emergency tensioning retractor serves to take up the slack in the seat belt in the event of a crash (frontal or rear end collision) and prevents the seat belt's film reel effect. The close-fitting seat belt means that vehicle occupants are exposed to the deceleration forces acting on the body at an earlier stage. | ||
| Front emergency tensioning retractor, design | GF91.40-P-4000-02T | ||
| Front emergency belt tensioner - function | GF91.40-P-4000-03T |
Front emergency tensioning retractor, location/task/design/function - GF91.40-P-4000S
MODEL 220 up to 31.8.02
Arrangement of components
Identifying Front Emergency Tensioning Retractor Location - Model 220 Up To 31.8.02. Scheme 45
| Emergency tensioning retractor, location | GF91.40-P-4000-01S | ||
|---|---|---|---|
| Emergency tensioning retractor, task | The emergency tensioning retractor serves to take up the slack in the seat belt in the event of a crash (frontal or rear end collision) and prevents the seat belt's film reel effect. The close-fitting seat belt means that vehicle occupants are exposed to the deceleration forces acting on the body at an earlier stage. | ||
| Emergency tensioning retractor, design | GF91.40-P-4000-02S | ||
| Emergency tensioning retractor, function | GF91.40-P-4000-03S |
Front emergency tensioning retractor, location - GF91.40-P-4000-01S
Model 220
Emergency tensioning retractors, driver, passenger
Scheme 46
Rear emergency tensioning retractor, location/purpose/design/function - GF91.40-P-4001B
MODEL 215
Scheme 47
| Rear emergency tensioning retractor, purpose | The emergency tensioning retractor eliminates the belt slack in the event of a collision (front and rear end collision) and prevents the film winding effect of the seatbelt. The tight seatbelt ensures that the vehicle passenger decelerates at nearly the same rate as the vehicle. | ||
|---|---|---|---|
| Rear emergency tensioning retractor, design | GF91.40-P-4000-02S | ||
| Rear emergency tensioning retractor, function | GF91.40-P-4000-03S |
Rear emergency tensioning retractor, location/purpose/design/function - GF91.40-P-4001S
MODEL 220
Rear emergency tensioning retractor, location Model 210 with code 293 GF91.40-P-4001-01A Model 210 as of 6/98 , , model 220 Rear emergency tensioning retractor, purpose The emergency tensioning retractor eliminates the belt slack in the event of a collision (front and rear end collision) and prevents the film winding effect of the seatbelt. When the belt is tight the vehicle passenger starts decelerating with the vehicle more quickly. Rear emergency tensioning retractor, design GF91.40-P-4000-02S Rear emergency tensioning retractor, function GF91.40-P-4000-03S
Rear emergency tensioning retractor, location - GF91.40-P-4001-01A
Model 210 with code 293
Model 210 as of 6/98
Model 220
The rear left and right emergency tensioning retractors (R12/6, R12/7) are located on the C-pillar behind the inner paneling.
Scheme 48
Emergency Locking Retractor Sensor - Location/Design/Function - GF91.40-P-4002A
MODEL 215
Location of component
Scheme 49
| Seat belt lock sensor, location | The vehicle-sensitive seat belt lock sensor (A60) is located on the crossmember under the left half of the rear bench. | ||
|---|---|---|---|
| Seat belt lock sensor, task | GF91.40-P-4002-01A | ||
| Seat belt lock, function | At an appropriate acceleration/deceleration or inclined position of the vehicle, a steel ball located in the sensor is accelerated and so interrupts a photoelectric barrier. This interruption is detected and evaluated by the sensor electronics. |
Driver's airbag, location/purpose/design/function - GF91.60-P-4001S
MODEL 215, 220
| Driver's airbag, location | GF91.60-P-4001-01S | ||
|---|---|---|---|
| Driver's airbag, purpose | The driver's airbag protects the driver from injury in the event of a head-on collision. During a head-on collision, the airbag inflates in the space between the steering wheel and driver's body within approx. 45 ms catching the driver's body and allowing it to decelerate at a programmed rate. | ||
| Driver's airbag, design | GF91.60-P-4001-03S | ||
| Driver's airbag, function | GF91.60-P-4001-02GC |
Driver airbag, location - GF91.60-P-4001-01S
Models 215, 220
Scheme 50
Passenger airbag, location/purpose/design/function - GF91.60-P-4003S
MODEL 215, 220
| Passenger airbag, location | GF91.60-P-4003-01S | ||
|---|---|---|---|
| Passenger airbag, purpose | The passenger airbag protects the passenger against injuries in the event of a head-on or rear-end collision. The airbag inflates in the space between the instrument panel and passenger's body catching the passenger and ensuring that his body decelerates at a programmed rate. | ||
| Passenger airbag, design | The passenger airbag consists of an extruded aluminum element with two-stage gas generator on one side and folded airbag with cover on the other. | ||
| Passenger airbag, function | GF91.60-P-4003-02S |
Passenger airbag, location - GF91.60-P-4003-01S
Models 215, 220
Driver/passenger side airbags, location - GF91.60-P-4004-01S
Models 215, 220
Scheme 51
Seat belt tensioner control module with airbag, location/task/design/function - GF91.60-P-4006B
MODEL 210 Applicable to 30.6.99 for vehicles with code 290 (window airbags)
MODEL 210 Applicable to 30.6.99 for vehicles with code 293 (left and right rear side airbags)
MODEL 210 as of 1.6.98 up to 30.6.99 with CODE (491) U.S. version
MODEL 210 Applicable from 1.6.98 to 30.6.99 for vehicles with code 498 (Japanese version)
MODEL 210 Applicable as of 1.7.99, 215, 220
Location on models 210, 215, 220
Scheme 52
Location on model 210
Scheme 53
| Control module for emergency belt tensioners with airbags, location | The airbag control module (N2/7) (as of 1.09.02 restraint systems control module (N2/7)) on models 215, 220 is located on the transmission tunnel in front of the gearshift guide plate under the center console. | ||
|---|---|---|---|
| MODELS 215, 220 to 31.8.02 | GF91.60-P-4006-01S | ||
| Model 210 | GF91.60-P-4006-01B | ||
| Belt Tensioner Control Module with Airbag - Task | GF91.60-P-4006-02B | ||
| Control module for emergency belt tensioners with airbags - design | The airbag control module (N2/7) (as of 1.09.02 restraint systems control module (N2/7)) is accommodated in an aluminum housing. The housing and the electrical connection are insensitive to electromagnetic interference radiation | ||
| Emergency tensioning retractor with airbag control module, function | GF91.60-P-4006-04B |
Identifying Airbag Control Module. Scheme 54
Seat occupied recognition system with automatic child seat recognition, location/task/design/function - GF91.60-P-4008A
MODELS 129, 140, 202 as of 1.6.97, 210 as of 1.3.97 up to 1.6.98 with CODE (491) U.S. version
MODELS 170, 208, 210 as of 1.6.98, 215, 220
MODEL 202 as of 1.12.97 except CODE (491) U.S. version
Location of component
Scheme 55
Seat occupied recognition sensor with automatic child seat recognition, location The passenger seat occupied and child seat recognition sensor (B48) is integrated in the seat cushion of the front passenger's seat. Seat occupied recognition sensor with automatic child seat recognition, task The seat occupied recognition sensor blocks deployment of the front passenger airbag, side airbag and emergency tensioning retractor when the front passenger seat is not occupied. The automatic child seat recognition blocks deployment of the front passenger airbag when a child seat is in its designated position. Seat occupied recognition sensor with automatic child seat recognition, design GF91.60-P-4008-02A Seat occupied recognition sensor with automatic child seat recognition - function Models 170, 208, model 202 as of 12/97 version: Models 129, 140, 202 as of 6/97 Model 210 as of 3/97 up to 6/98 GF91.60-P-4008-03A Model 210 as of 6/98, model 215, model 220 GF91.60-P-4008-03B
Side airbag sensors, location - GF91.60-P-4009-01B
Model 210 with code 290, 293, model 210 , from 6/98 to 6/99, model 210 as of 7/99, models 215, 220
The side airbag sensors are located behind the cross member below the rear bench seat.
Illustrated on model 210
Scheme 56
Airbag indicator and warning lamp, location/purpose - GF91.60-P-4011A
MODEL 129, 140, 170, 202, 208, 210, 215, 220
| Airbag indicator and warning lamp, location | The airbag indicator and warning lamp (A1e15) is located in the instrument cluster (A1). (on left or right depending on model). | GF91.60-P-4011-02A | |
|---|---|---|---|
| Airbag indicator and warning lamp, purpose | GF91.60-P-4011-01GC |
SRS malfunction indicator lamp, location - GF91.60-P-4011-02A
Models 129, 140, 170, 202, 208, 210, 215, 220
The SRS malfunction indicator lamp is located in the instrument cluster (on left or right depending on model).
Illustrated on model 202
Scheme 57
Airbag OFF indicator lamp, location/purpose - GF91.60-P-4012A
MODEL 129, 140, 202 as of 1.6.97, 210 as of 1.3.97 up to 1.6.98 with CODE (491) USA version
MODEL 163 as of 1.12.99, 170, 208, 210 as of 1.6.98, 215, 220
MODEL 202 as of 1.12.97 except CODE (491) USA version
| Airbag OFF indicator lamp, location | Model 129 | GF91.60-P-4012-01B | |
|---|---|---|---|
| Models 140, 170, 202, 208, 210, 215, 220 | GF91.60-P-4012-01A | ||
| Model 163 off 12/99 | GF91.60-P-4012-01C | ||
| Airbag OFF indicator lamp, purpose | The airbag OFF indicator lamp (E16 or N72e1 or A1 e56) indicates proper operation of the automatic child seat recognition sensor (ACRS) and switch-off of the passenger airbag when a special child seat is recognized. |
Airbag OFF indicator lamp, location - GF91.60-P-4012-01A
Models 170, 208, 215, 220 model 202 as of 12/97, model 210 as of 6/98
version
Models 140, 202 as of 6/97 model 210 from 3/97 to 6/98
Scheme 58
Buckle switch, location/task - GF91.60-P-4013A
MODELS 129, 140, 202 up to 31.5.93
MODELS 129, 140, 170, 202, 208, 210, 215, 220 with CODE (491) U.S. version
Location
Scheme 59
| Seat belt buckle switch location | The left front seat belt buckle restraint systems switch (S68/3) and right front seat belt buckle restraint systems switch (S68/4) are located in the respective buckles. | ||
|---|---|---|---|
| Seat belt buckle switch task | The left front seat belt buckle restraint systems switch (S68/3) and front right (S68/4) monitor the wearing of the three-point seat belt on the driver's and front passenger's seat. The airbag unit is ignited if the seat belt is not fastened during the initial triggering threshold. |
Window airbag, location/purpose/design/function - GF91.60-P-4014A
MODEL 210 up to 30.6.99 with CODE (290) Window airbag
MODEL 210 up to 30.6.99 with CODE (293) Left and right rear side airbags
MODEL 210 as of 1.6.98 up to 30.6.99 with CODE (491) USA version
MODEL 210 as of 1.6.98 up to 30.6.99 with CODE (498) Japanese version
MODEL 210 as of 1.7.99, 215, 220
| Window airbag, location | Model 210 | GF91.60-P-4014-01A | |
|---|---|---|---|
| Models 215, 220 | GF91.60-P-4014-01S | ||
| Window airbag, purpose | GF91.60-P-4014-02A | ||
| Window airbag, design | GF91.60-P-4014-03A | ||
| Window airbag, function | GF91.60-P-4014-04A |
Window airbag, location - GF91.60-P-4014-01S
Models 215, 220
Window airbag on driver side (vehicles with left-hand steering)
The gas generators with left rear window airbag squib (R12/22)/right rear window airbag squib (R12/23) are located in the left/right C-pillars below the interior paneling. The associated inflatable hose (3) is located folded up in the side roof frame between the A and C-pillars.
Rear side airbag, location/purpose/design/function - GF91.60-P-4015S
MODEL 220
| Rear side airbag, location | GF91.60-P-4015-01A | ||
|---|---|---|---|
| Rear side airbag, purpose | The left/right rear side airbag protects the upper body and head of the affected rear passengers against injury in the door as well as B and C-pillar areas during a side collision. It is triggered simultaneously with the front side airbag as well as the window airbag. | ||
| Rear side airbag, design | The rear side airbags consist of a gas generator with squib and airbag. The airbags consist of uncoated, recyclable polyamide fiber. They inflate to a volume of 16 liters. | ||
| Rear side airbag, function | GF91.60-P-4015-02S |
Rear side airbag, location - GF91.60-P-4015-01A
Model 210 with rear side airbag
Model 210 , as of 6/98, Model220
Scheme 60
Rear Sidebag - Location/Task/Design/Function - GF91.60-P-4015SA
MODEL 215 Applicable as of 1.6.00
Rear sidebag modules are installed as standard equipment in this vehicle. They are located along the rear side panels near the wheel wells.
Identifying Rear Sidebag Components Location. Scheme 61
| Rear Sidebag - Location | The rear sidebags and the left and right rear sidebag detonators (R12/11, R12/12) are installed along the rear side panels near the wheel wells. | ||
|---|---|---|---|
| Rear Sidebag - Task | The left/right rear sidebag serves to protect rear seat occupants from upper body and head injuries in the event of a side-impact collision affecting the door, B-pillar or C-pillar areas. Each rear sidebag is deployed simultaneously with the respective front sidebag and the windowbag. | ||
| Rear Sidebag - Design | The rear sidebag modules consist of an inflator, a detonator and an airbag. The airbags are made of an uncoated and recyclable polyamide fabric and have a volume of 16 liters when inflated. | ||
| Rear Sidebag - Function | GF91.60-P-4015-02S |
Side airbag sensors, location/purpose - GF91.60-P-4016A
MODEL 210 up to 30.6.99 with CODE (290) Window airbag
MODEL 210 up to 30.6.99 with CODE (293) Left and right rear side airbags
MODEL 210 as of 1.6.98 up to 30.6.99 with CODE (491) USA version
MODEL 210 as of 1.6.98 up to 30.6.99 with CODE (498) Japanese version
MODEL 210 as of 1.7.99, 215, 220
| Side airbag sensors, location | GF91.60-P-4009-01B | ||
|---|---|---|---|
| Side airbag sensors, purpose | In the event of a side collision the side airbag sensors (A53/1 and A54/1) sense the deceleration/acceleration effecting the vehicle in the lateral direction and start a plausibility check in the airbag control module (N2/7) . If the values are plausible an actuation signal is transmitted to the associated side airbags/window airbags. |
Supplemental restraint system (SRS) components, location/task/design/function - GF91.60-P-9999S
Models 215, 220
| Front emergency tensioning retractor, location/ task/design/function | MODEL 215 up to 31.8.02 | GF91.40-P-4000C | |
|---|---|---|---|
| MODEL 220 up to 31.8.02 | GF91.40-P-4000S | ||
| MODEL 215 as of 1.9.02 | GF91.40-P-4000N | ||
| MODEL 220 as of 1.9.02 | GF91.40-P-4000M | ||
| Rear Emergency Tensioning Retractors, location/task/design/function | Model 215 | GF91.40-P-4001B | |
| Model 220 | GF91.40-P-4001S | ||
| Seat belt tensioner control module with airbag, location/task/design/function | GF91.60-P-4006B | ||
| Emergency Locking Retractor Sensor - Location/Design/Function | Model 215 | GF91.40-P-4002A | |
| Driver's airbag, location/task/design/function | GF91.60-P-4001S | ||
| Front Passenger's Airbag, location/task/ design/function | GF91.60-P-4003S | ||
| Buckle switch, location/task | GF91.60-P-4013A | ||
| Driver's and passenger's side airbags, location/task/design/function | GF91.60-P-4004S | ||
| Sidebag Sensors, location/task | GF91.60-P-4016A | ||
| Rear side airbag, location/task/design/function | Model 215 as of 1.6.00 | GF91.60-P-4015SA | |
| Model 220 | GF91.60-P-4015S | ||
| Window airbags, location/task/design/function | GF91.60-P-4014A | ||
| Seat occupied recognition system with automatic child seat recognition, location/task/design/function | GF91.60-P-4008A | ||
| SRS Airbag Indicator and Warning Lamp, location/task | GF91.60-P-4011A | ||
| Airbag OFF Indicator Lamp, location/task | GF91.60-P-4012A | ||
| Supplemental Restraint System (SRS) function description table of contents | GF91.60-P-0999S |
