Notes on application of sealant to cylinder shutoff oil pump - AH01.30-P-1000-01A
Engine 137.970
Application of sealant to cylinder shutoff oil pump
The timing case cover is sealed with silicone sealant at the points F .
Only apply the sealant to the specified line (F) with a 2.0 mm ± 0.5 mm bead.
The sealant must be used within 10 minutes. The silicone bead must not be spread. Only the approved silicone sealant should be used.
Identifying Silicone Sealant Applying To Timing Case Cover. Scheme 392
Notes on application of sealant to front cover at cylinder head - AH01.30-P-1000-02C
Engine 275
Application of sealing compound to front cover at right cylinder head
The line ( F ) marks the application of the sealing compound.
The sealant must be applied only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm.
The sealing compound must be applied within 10 minutes
The sealing compound bead must not be spread. Only the approved sealing compound must be used.
Identifying Application Of Sealing Compound To Upper Part Of Oil Pan - Engines 113.941/942/960/962/965/981/982/993. Scheme 393
Notes on application of sealing compound to front cover at cylinder head - AH01.30-P-1000-02D
Engine 275
Application of sealing compound to front cover at left cylinder head
The line ( F ) marks the application of the sealing compound.
The sealant must be applied only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm.
The sealing compound must be applied within 10 minutes
The sealing compound bead must not be spread. Only the approved sealing compound must be used.
Identifying Sealing Compound Applying Line. Scheme 394
Notes on application of sealant to cylinder head gasket - AH01.30-P-1000-04V
Engine 113
Engine 113
Before installing the left cylinder head, it is necessary to apply sealant to the cylinder head gasket in the area of the timing case cover because of porous areas in the left cylinder head
Repair note
The sealant must be applied only in the manner shown, with a bead of 2.0 mm ± 0.5mm.
The sealant must be used within 10 min.
The silicone bead must not be spread.
Scheme 395
Notes on application of sealant to timing case cover - AH01.40-P-1000-01A
Engine 137.970
Application of sealant to timing case cover
The timing case cover is sealed with silicone sealant at the points F .
The sealant should only be applied to the areas specified with a 2.0 mm ± 0.5 mm bead.
The sealant must be used within 10 minutes. The silicone bead must not be spread. Only the approved silicone sealant should be used.
Identifying Timing Case Cover Sealant Points. Scheme 396
Notes on application of sealant timing case cover - AH01.40-P-1000-01B
Engine 112, 113
Application of sealant to timing case cover
The timing case cover is sealed with a silicone sealant at points A, C, D
No sealant must be applied to the timing case cover at points B , pressure oil galleries to crankcase, with the exception around the bolt hole G . Sealant which is applied to the points B , is entrained by the oil flow and blocks the oil supply drillings of: Main bearings, camshaft bearings, rocker arms and oil spray nozzles
Scheme 397
Clean sealing surfaces
Apply sealant only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm.
The sealant must be applied within 10 minutes!
The silicone bead must not be spread. Only the silicone sealant listed in the section Repair products may be used.
Information on application of sealant to timing case cover - AH01.40-P-1000-01C
Engine 137.970, 275
Application of sealant to timing case cover
The line ( F ) marks the application of the sealing compound
The sealant must be applied only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm
The sealing compound must be applied within 10 minutes
The sealing compound bead must not be spread. Only the approved sealing compound must be used.
Scheme 398
Notes on application of sealant to right-hand crankcase - AH01.40-P-1000-02A
Engine 137.970
Application of sealant to right-hand crankcase cover
The line F penciled in identifies the application of sealant.
The sealant should only be applied to the areas specified with a 2.0 mm ± 0.5 mm bead.
The sealant must be used within 10 minutes. The silicone bead must not be spread. Only the approved silicone sealant should be used.
Scheme 399
Information on application of sealant to crankcase bottom section - AH01.40-P-1000-03A
Sealing agent flow
The line drawn in (F) identifies the sealing compound application
The sealant must be applied only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm. The sealing compound must be applied within 10 min. The bead should not be spread. Only the approved silicone sealant may be used.
Scheme 400
Information on application of sealant to end cover of crankcase - AH01.40-P-1000-04A
The line (G) identifies the sealant run
The sealant must only be applied to the specified surfaces with a bead of 2.0 mm ± 0.5 mm
The sealing compound must be applied within 10 min.
The bead should not be spread. Only the approved sealant may be used.
Scheme 401
Notes on application of sealant to crankcase cover - AH01.40-P-1000-05A
Engine 137.970
Application of sealant to crankcase cover inner-V
The line F penciled in identifies the application of sealant
The sealant should only be applied to the areas specified with a 2.0 mm ± 0.5 mm bead
The sealant must be used within 10 minutes.
The silicone bead must not be spread. Only the approved silicone sealant should be used.
Scheme 402
Notes application of sealant to end cover with radial shaft seal - AH01.40-P-1000-06A
Engine 112, 113
Application of sealant to end cover
The lines drawn G, E and the arrow D mark the application of sealant
Clean sealing surfaces, apply sealant only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm
The sealant must be applied within 10 minutes!
The silicone bead must not be spread. Only the silicone sealant listed in the section Repair products may be used.
Scheme 403
Notes on application of sealant to oil pan - AH01.45-P-0001-01A
The line (F) identifies the sealing compound flow
The sealant must only be applied to the specified surfaces with a bead of 2.0 mm ± 0.5 mm
The sealing compound must be worked on within 10 minutes.
The bead should not be spread. Only the approved sealant may be used.
Identifying Oil Pan Sealing Compound Line. Scheme 404
Notes on application of sealant oil pan - AH01.45-P-0001-01C
Engine 112
Application of sealant to top part of oil pan
The line drawn F marks the application of sealant
Scheme 405
Clean sealing surfaces, apply sealant only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm
The sealant must be applied within 10 minutes!
The silicone bead must not be spread. Only the silicone sealant listed in the section Repair products may be used.
Application of sealant to bottom part of oil pan
The line drawn F marks the application of sealant
Scheme 406
Clean sealing surfaces, apply sealant only to the specified surfaces with a bead of 2.0 mm ± 0.5 mm
The sealant must be applied within 10 minutes!
The silicone bead must not be spread. Only the silicone sealant listed in the section Repair products may be used.
Notes on application of sealing compound to oil pan - AH01.45-P-0001-01E
Engines 113.941/942/960/962/965/981/982/993
Application of sealing compound to upper part of oil pan
The line drawn in (F) identifies the course of the sealing compound
The sealing compound must be only applied to the specified
surfaces in the form of a bead of 2.0 mm ± 0.5 mm in diameter.
The sealing compound must be processed within 10 min. The sealing compound bead must not be spread. Only the sealing compound listed in the section "Repair products" may be used.
Application of sealing compound to bottom part of oil pan
The line drawn in (F) identifies the course of sealing compound
Scheme 407
The sealing compound must only be applied to the specified surfaces in the form of a bead of 2.0 mm ± 0.5 mm in diameter
The sealing compound must be processed within 10 min. The sealing compound bead must not be spread. Only the sealing compound listed in the section Repair products may be used.
Notes on application of sealant to oil pan - AH01.45-P-0001-01R
The line (F) indicates where the sealant is applied
Clean sealing surface. The sealant should be applied only to the indicated surface in the form of a bead of height mm and width 2.0 ± 0.5 mm. The sealant must be applied within 10 min. The silicone bead should not be spread. Only the silicone sealant listed in the section Repair products may be used
Application of sealant to top part of oil pan
Scheme 408
The line (F) indicates where the sealant is applied
Clean sealing surface. The sealant should only be applied to the indicated surface in the form of a bead of height mm and width 2.0 ± 0.5 mm. The sealant must be applied within 10 min. The silicone bead should not be spread. Only silicone sealant listed in the section Repair products may be used
Application of sealant to bottom part of oil pan
