Servicing wiring harness - AR15.18-P-0500A
MODEL 124, 126, 129, 140, 163, 168, 170, 201, 202, 208, 210, 215, 220
Scheme 132
If a cable break or similar damage exists in the area of the plug connection of the mass air flow sensor (B2) or temperature sensor (B11), it is possible to repair the wiring harness in order to avoid costly replacement of a wiring harness
| 27.9.99 | Supersedes SI 54/76 dated 23.1.96 | Remove SI 54/76 from your file. |
Modification notes
Removing and installing 1 Remove air cleaner, install. Only on engine 119 2 Expose wiring harness to mass air flow sensor or temperature sensor. Ignition switched off 3 Unplug socket from mass air flow sensor or temperature sensor. 4 Plug in repair socket together with cables at mass air flow sensor or temperature sensor and insert into cable duct. 5 Repair wiring harness using end soldering sleeves (Z). Turn together cable of engine wiring harness and cable repair socket of the same color and insert into end soldered sleeves (Z). Use end soldered sleeves (Z) only in cross section area Ø 0.7 - Ø 4.0 mm 2 AR54.18-P-0100-02A 6 Insert cables into the cable duct. 7 Connect HHT, read faults and erase see Diagnosis Manual Engine Volume 2 Index 0: Connecting and using test equipment 8 Install in the reverse order
| Part no. | Designation | Quantity |
|---|---|---|
| 140 540 00 36 | Repair kit socket (B2)1 1) Consisting of repair socket (B2) and 5 cable connectors | Acc. to condition |
| 140 540 00 81 | Repair socket (B2) | Acc. to condition |
| 202 540 01 81 | Repair socket (B11) 3-pin | Acc. to condition |
| 126 540 30 81 | Repair socket (B11) 4-pin | Acc. to condition |
| 001 546 99 41 | Cable connector | Acc. to condition |
| 006 989 84 85 | Fabric tape | Acc. to condition |
Parts ordering notes
