Contents - function description of antenna system (ATS) - GF82.62-P-0999TZ
MODEL 211.0/2 up to 31.5.06 except CODE (494) USA version except CODE (498) Japan version
| Antenna system (ATS), function | GF82.62-P-0001T |
|---|---|
| Survey of system components for antenna system (ATS), location/task/design/function | GF82.62-P-9999TZ |
Left antenna amplifier module, component description - GF82.62-P-3121TM
MODEL 211.0/2 as of 1.6.06 except CODE (494) USA version except CODE (498) Japan version
Shown on model 211.0
Scheme 1
Location
The left antenna amplifier module is mounted to the left of the C-pillar in the direction of travel.
Task (model 211.0)
- Receiving and forwarding the AM/FM signals to the audio gateway control unit (N93/1)
- Receiving and forwarding the TV signals (TV1 and TV2) to the TV combination tuner (analog/digital) (A90/1)
- Decoupling the rear window from the body mass and the wiring harness via a block circuit
Task (model 211.2)
- Receiving and forwarding the AM/FM signals via the amplifier module 1, window antenna (A2/71) to the audio gateway control unit
- Decoupling the rear window from the body mass and the wiring harness via a block circuit
Left antenna amplifier module, component description - GF82.62-P-3121TMU
MODEL 211.0/2 as of 1.7.06 with CODE (530) COMAND APS USA (with navigation system)
Shown on model 211.0
Scheme 2
Location
The left antenna amplifier module is mounted to the left of the C-pillar in the direction of travel.
Task
- Receiving and forwarding the AM/FM signals via the amplifier module 1, window antenna (A2/71) to the audio gateway control unit (N93/1)
- Decoupling the rear window from the body mass and the wiring harness via a block circuit
Left antenna amplifier module, component description - GF82.62-P-3121TXD
MODEL 211, 219 as of Model Year 9/AEJ 07
Shown on model 211.0
Scheme 3
Location
The left antenna amplifier module is located beneath the paneling at the left C-pillar.
Shown on model 211.2
Scheme 4
Location
The left antenna amplifier module is located beneath the paneling above the left rear side window.
Task (model 211.0, 219)
- Receiving, amplifying and relaying the amplitude modulation (AM)/frequency modulation (FM) signals to: the radio (A2), the radio control panel and navigation unit (A2/56) or the COMAND operating, display and controller unit (A40/3).
- Receiving and relaying the weatherband signals (with code 494 USA version).
- Receiving, demodulating and digitizing the signals for the electric central locking and relaying them to the rear SAM control unit with fuse and relay module (N10/2).
- Receiving and relaying the television (TV)1 and TV2 signals to the TV combination tuner (analog/digital) (A90/1) (with code 863 Digital/analog TV tuner, except code 494 USA version).
- Decoupling the rear window from the body mass and the subharness via a suppression filter
Task (model 211.2, except code 494 USA version)
- Receiving, amplifying and relaying the AM/FM1 signals to: the radio, the radio control panel and navigation unit or the COMAND operating, display and controller unit
- Receiving, demodulating and digitizing the signals for the electric central locking and relaying them to the rear SAM control unit with fuse and relay module.
Right antenna amplifier module component description - GF82.62-P-3122TM
MODEL 211.0/2 as of 1.6.06 except CODE (494) USA version except CODE (498) Japan version
Shown on model 211.0
Scheme 5
Location
The right antenna amplifier module is mounted to the right of the C-pillar in the direction of travel.
Task
Receiving and forwarding the TV signals (TV3 and TV4) to the TV combination tuner (analog/digital) (A90/1).
Right antenna amplifier module component description - GF82.62-P-3122TXE
MODEL 211, 219 as of Model Year 9/AEJ 07
Shown on model 211.0
Scheme 6
Location
The right antenna amplifier module is located beneath the paneling at the right C-pillar.
Shown on model 211.2
Scheme 7
Location
The right antenna amplifier module is located beneath the paneling above the right rear side window.
Task (models 211.0, 219)
- Receiving and relaying Keyless Go signals to the rear module KEYLESS GO control unit (N102) (with code (889) Keyless Go)
- Receiving and relaying band III signals to the Digital Audio Broadcasting control unit (N87/3) (with code 537 Digital radio)
- Receiving and relaying the television (TV) signals (TV3 and TV4) to the TV combination tuner (analog/digital) (A90/1) (with code 863, Digital/analog TV tuner, except code 494, USA version).
- Decoupling the rear window from the body mass and the subharness via a suppression filter
Task (model 211.2, except code 494 USA version)
- Receiving, amplifying and relaying the frequency modulation (FM)2 signals: the radio (A2), the radio control panel and navigation unit (A2/56) or the COMAND operating, display and controller unit (A40/3).
- Receiving and relaying Keyless Go radio signals to the rear module KEYLESS GO control unit (with code 889 Keyless Go)
- Receiving and relaying band III signals to the Digital Audio Broadcasting control unit (with code 537 Digital radio)
- Receiving and relaying the TV signals (TV1) to the TV combination tuner (analog/digital) (with code 863, Digital/analog TV tuner, except code 494, USA version).
Rear window antenna component description - GF82.62-P-3123TM
MODEL 211.0/2 as of 1.6.06 except CODE (494) USA version except CODE (498) Japan version with CODE (413) Panoramic glass roof with top sliding roof
MODEL 211.0/2 as of 1.7.06 with CODE (498) Japan version with CODE (413) Panoramic glass roof with top sliding roof
MODEL 211.2 as of 1.7.06 with CODE (494) USA version with CODE (413) Panoramic glass roof with top sliding roof
Scheme 8
Location
The antennas (AM, FM, RCL and TV) are part of the heating wires of the rear window defroster. The telephone antenna and GPS antenna are attached above the heating field of the rear window.
The visible wires at the top of the rear window are antennas and are not heated
Task
The antennas must convert the high frequency (HF) oscillation of the electrical field in the air to a high frequency AC voltage in an electrical conductor.
Design
The antennas are an integral part of the wires in the rear window defroster. A block circuit consisting of a number of inductive coils is integrated into the heating wires.
Function
The high frequency oscillation of the electrical field in the air is converted into a high frequency AC voltage in an electrical conductor.
A standing electrical wave is formed in the antenna as a result of the correct matching of the length of the antenna to the wavelength of the frequency to be received. In this case, the amplitude of the RF signal has a constant value at a random point of the antenna. However, at the connecting point the HF signal level is at the maximum. Any deviation in antenna length from the optimum length will result in a reduction of the HF signal level at the antenna output.
If the deviation is too large, no further HF signal is received (e.g. if the antennae are connected to the antenna amplifier incorrectly). The telephone antenna and the GPS antenna at the top section of the rear window are active antennas.
GPS antenna splitter, component description - GF82.62-P-3129TXB
MODEL 211 with CODE (359) TELE AID emergency call system with CODE (512) COMAND APS with DVD changer with CODE (528) COMAND with DVD changer as of Model Year 9/AEJ 07
Scheme 9
Location
The GPS antenna splitter is located in the trunk at the left-hand side above the wheel arch.
Task
The GPS antenna splitter splits the Global Positioning System (GPS) signal from the GPS antenna (A2/49a2) and transmits it to the COMAND operating, display and controller unit (A40/3) and the emergency call system control unit (N123/4).
Design/function
The GPS antenna splitter consists of the diplexer, which is supplied with voltage (phantom voltage) by either the navigation processor or the emergency call system control unit over the coaxial line. The antenna splitter is equipped with 3 coaxial plug sockets for connection purposes.
Antenna splitter, component description - GF82.62-P-3136TM
MODEL 211.0/2 as of 1.7.06 with CODE (530) COMAND APS USA (with navigation system)
MODEL 211.0/2 with CODE (512) COMAND APS with DVD changer with CODE (528) COMAND with DVD changer with CODE (494) USA version as of Model Year 9
Shown on model 211.0
Scheme 10
Location
The emergency call system antenna splitter is installed on the equipment bridge in the luggage compartment in front of the spare tire well.
Task
Upon activation of service (e.g. emergency call), the emergency call system antenna splitter switches the telephone signal through to the emergency call system control unit (N123/4).
Multifunction antenna, component description - GF82.62-P-3137TM
MODEL 211.0/2 as of 1.6.06 except CODE (494) USA version except CODE (498) Japan version except CODE (413) Panoramic glass roof with top sliding roof
MODEL 211.0/2 as of 1.7.06 with CODE (494) USA version except CODE (413) Panoramic glass roof with top sliding roof
MODEL 211.0/2 as of 1.7.06 with CODE (498) Japan version except CODE (413) Panoramic glass roof with top sliding roof
MODEL 211.0 as of 1.7.06 with CODE (494) USA version with CODE (413) Panoramic glass roof with top sliding roof
Shown on model 211.0
Scheme 11
Location
The roof antenna is installed on the rear of the vehicle roof.
Tasks (up to model year 09)
- Transmitting telephone signals (D-net and E-net)
- Receiving and forwarding telephone signals via the E-net compensator (A28/3) and the UPCI [UHI] cell phone holder (Universal Handy Interface) (A34/15) to the Universal Cell phone Interface (UPCI [UHI]) control unit (N123/1).
- Receiving and forwarding Global Positioning System (GPS) signals to the navigation processor (N41/1).
- Receiving and forwarding satellite digital audio radio (satellite radio) (SDAR) signals (with code (536), SIRIUS satellite radio and code (494), USA version).
Tasks (as of model year 09)
- Transmitting telephone signals
- Receiving and forwarding telephone signals via the E-net compensator and the Universal Portable Cell Phone Interface (UPCI [UHI]) cell phone holder to the radio (A2), the radio control panel and navigation unit (A2/56) or the COMAND operating, display and controller unit (A40/3).
- Receiving and forwarding GPS signals to the radio control panel and navigation unit or the COMAND operating, display and controller unit.
- Receiving and forwarding signals to the Digital Audio Broadcasting control unit (N87/3) (with code (537) Digital radio and code (833) Great Britain version) or to the satellite digital audio radio (satellite radio) (SDAR) (with code (536) SIRIUS satellite radio and code (494) USA version).
Bluetooth antenna, component description - GF82.62-P-4201TXB
MODEL 211, 219 with CODE (523) MB Audio 20 radio with CODE (510) Audio 20 with CD changer with CODE (525) MB Audio 50 APS radio with CODE (511) Audio 50 APS with DVD changer with CODE (528) COMAND with DVD changer with CODE (527) COMAND APS with single DVD drive (with navigation) with CODE (512) COMAND APS with DVD changer with CODE (386) Preinstallation for telephone "Handy", UPCI system as of Model Year 9/AEJ 07
Illustrated on model 219
Scheme 12
Location
The Bluetooth antenna is located in the stowage tray in the center console.
Depending on the equipment installed one of the following control units will be installed, hereafter referred to as the "audio unit"
- Radio (A2), with code 523 MB Audio 20 radio or code 510 Audio 20 with CD changer
- < &PTABR >Radio control panel and navigation unit (A2/56), with code 525 MB Audio 50 APS radio or code 511 Audio 50 APS with DVD changer
- COMAND operating, display and controller unit (A40/3), with code 528 COMAND with DVD changer, code 527 COMAND APS with single DVD drive (with navigation system) or code 512 COMAND APS with DVD changer
Task
- Receiving signals
- Conversion of signals
- Transmitting signals
Receiving signals
- Receiving mobile radio signals and data via the air interface of the Bluetooth module (comfort telephony), with code 386 Preinstallation for telephone "cell phone", UPCI [UHI] system.
- Receiving mobile radio signals and data via the air interface and the mobile phone antenna of the Bluetooth interface integrated in the mobile phone (basic telephony).
- Receiving mobile radio signals and data via discrete line from "Audio unit"
To be able to operate a Bluetooth-compatible mobile phone that is authorized on the "audio unit" in the vehicle in vehicles without code 386 Preinstallation for telephone "cell phone", UPCI [UHI] system, the mobile phone must support Hands Free Profile (HFP) 1.0 or 1.5. More information is available under
- www.mercedes-benz-mobile.com
On vehicles with code 498 Japan version, a Bluetooth-compatible mobile phone can only be operated if no mobile phone is connected to the cell phone separation point (X39/37) and the mobile phone adapter cable. Here too, the mobile phone must be authorized at the "audio equipment" and must support HFP 1.0 or 1.5. More information is available under
- www.mercedes-benz-mobile.com
Converting signals
The Bluetooth antenna converts the mobile phone signals and data to electrical signals and vice versa.
Transmitting signals
- Transmitting mobile radio signals and data via the air interface to the Bluetooth module (comfort telephony), with code 386 Preinstallation for telephone "cell phone", UPCI [UHI] system.
- Transmitting mobile radio signals and data via the air interface and the mobile phone antenna to the Bluetooth interface integrated in the mobile phone (basic telephony).
- Transmitting mobile telephone signals and data via discrete line to the "Audio unit"
