Air inlet, location - GF83.10-P-2100-01A
Illustrated on model 210
The air inlet (1) is located below the engine hood at the bottom of the windshield.
Scheme 62
Air ducts, location - GF83.10-P-2101-01A
The air duct for the defroster nozzle (1) is located beneath the windshield where it is integrated into the instrument panel.
The air ducts (2, 3) for the side nozzles are located below the instrument panel on the left and right.
The air ducts (4, 5) run along the vehicle floor from the front footwell to the rear footwell.
Air duct (6) is located in the center console.
Scheme 63
Blower, location - GF83.10-P-2102-01A
The blower (A32m1) is located below the glove compartment.
Scheme 64
Blower, location/purpose/design/function - GF83.10-P-2102A
MODEL 210
MODEL 140 as of 1.9.95
MODEL 202
MODEL 208
MODEL 170
| Blower, location | Model 210 | GF83.10-P-2102-01A | |
|---|---|---|---|
| Blower, location | Model 140 | GF83.10-P-2102-01B | |
| Model 202 up to 31.08.95 | GF83.10-P-2102-01E | ||
| Models 170, 208 and 202 as of 01.09.95 | GF83.10-P-2102-01G | ||
| Purpose | In the fresh air mode the blower sucks fresh air in through the fresh air flap; in the recirculated air mode air is sucked through the recirculated air flap from the vehicle passenger compartment into the heater or air conditioning housing. In the residual engine heat utilization mode the blower circulates the air in the passenger compartment. | ||
| Design | The blower is designed as a two-stage radial fan. | ||
| Blower, function | Model 210, 140, 170, 208, 202 as of 09/95 | GF83.10-P-2102-02A | |
| Model 202 up to 31.08.95 | GF83.10-P-2102-02B |
Blower regulator, location - GF83.10-P-2103-02A
The blower regulator (1) is located below the glove compartment and is screwed onto the blower.
Scheme 65
Dust filter, location - GF83.10-P-2104-01A
The dust filter (1) is located below the glove compartment.
Scheme 66
Dust filter, location - GF83.10-P-2104-01B
The dust filter (1) is located below the glove compartment.
Scheme 67
Rear vent, location - GF83.10-P-2105-02A
Illustrated on model 210
The rear vent (1) is located on the right rear fender behind the bumper.
On model 140 and 170 a rear vent is located on both the left and right sides
Scheme 68
Defroster nozzle, location - GF83.10-P-2106-01A
Illustrated on model 210
The two-piece defroster nozzle (1, 2) is located at the front of the instrument panel below the windshield.
Scheme 69
Center nozzle, location - GF83.10-P-2107-02A
Illustrated on model 210
The center nozzle (1) is located at the top in the center console.
Scheme 70
Side nozzle, location - GF83.10-P-2108-02A
The side nozzles (1) are located in the instrument panel on the left and right sides.
Scheme 71
Side nozzle, location/purpose/design/function - GF83.10-P-2108A
MODEL 210
Design
Scheme 72
| Side nozzle, Purpose | The side nozzles (1) on the left and right allow the air to be directed and distributed along the side windows and at the sides of the passenger compartment as desired. The side nozzle (2) is divided into two sections. The upper air outlet (4) provides ventilation for the side window keeping it from fogging up. The bottom air outlet serves for ventilation of the passenger compartment. | ||
|---|---|---|---|
| Side nozzle, location | GF83.10-P-2108-02A | ||
| Side nozzle, function | GF83.10-P-2108-01A |
Front footwell air outlet, location - GF83.10-P-2109-02A
Illustrated on model 210
The front footwell air outlets (1) are located in the left and right footwells next to the center console.
Scheme 73
Rear footwell air outlet, location - GF83.10-P-2110-02A
Illustrated on model 210
The rear footwell air outlets (1) are located on the left and right below the front seats.
Scheme 74
Rear compartment nozzle, location - GF83.10-P-2111-02A
The rear compartment nozzle (1) is located at the rear of the center console armrest.
Scheme 75
Stowage compartment ventilation nozzle, location - GF83.10-P-2112-02A
The stowage compartment ventilation nozzle (1) is located in the armrest.
Scheme 76
Switchover valve, location - GF83.10-P-2115-02A
Illustrated on model 210
The switchover valve (Y13) is located behind the glove compartment.
Scheme 77
Fresh/recirculated air flap vacuum element, location - GF83.10-P-2122-02A
Illustration of automatic heater (HEAT) and air conditioning (Tempmatic)
The fresh/recirculated air flap vacuum element (44) is located on the heater/air conditioning housing.
Scheme 78
Air inlet, location/function - GF83.10-P-2138A
MODEL 210
Scheme 79
| Air inlet, location | GF83.10-P-2100-01A | ||
|---|---|---|---|
| Air inlet, function | The fresh air required for ventilation flows through the air inlet (6) from the vent slots in the engine hood to the fresh air/recirculated air flap. Any water entrained is collected in the water collector (8) and drained to the outside through the water drain (9). |
Air ducts, location/purpose/design - GF83.10-P-2139A
MODEL 210
Design
Scheme 80
| Air ducts, location | GF83.10-P-2101-01A | ||
|---|---|---|---|
| Air ducts, purpose | The air ducts (1-6) guide the air required for ventilation of the vehicle from the heater/air conditioning housing (7) to the air outlets in the vehicle passenger compartment. |
Blower regulator, location/purpose/function - GF83.10-P-2141A
MODEL 210
MODEL 140 as of 1.9.95
MODEL 202 up to 31.8.95 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 202 as of 1.9.95
MODEL 208
MODEL 170
| Blower regulator, location | Model 210 | GF83.10-P-2103-02A | |
|---|---|---|---|
| Model 140 | GF83.10-P-2103-02B | ||
| Model 202 with code 580 and 581a up to 08/95 | GF83.10-P-2103-02E | ||
| Models 170, 208 and 202 as of 09/95 | GF83.10-P-2103-02G | ||
| Blower regulator, purpose | The blower regulator supplies the power to the blower depending on the blower stage set. | ||
| Blower regulator, function | Model 140 as of 09/95 Models 210, 208, 202 as of 09/95 with code 581a | GF83.10-P-2103-01A | |
| Model 170 Models 210, 208, 202 as of 09/95 except code 581a | GF83.10-P-2103-01C | ||
| Model 202 with code 580 and 581a up to 08/95 | GF83.10-P-2103-01E |
Dust filter, location/purpose/function - GF83.10-P-2142A
MODEL 210
MODEL 140 as of 1.9.95
| Dust filter, location | Model 210 HEAT/TAC | GF83.10-P-2104-01A | |
|---|---|---|---|
| Model 210 AAC | GF83.10-P-2104-01B | ||
| Model 140 | GF83.10-P-2104-01C | ||
| Dust filter, purpose | The dust filter filters the air flowing through the heater/air conditioning housing. Fresh air as well as recirculated air is filtered. | ||
| Dust filter, function | GF83.10-P-2104-02A |
Rear ventilation, location/purpose/function - GF83.10-P-2143A
MODEL 210
MODEL 140 as of 1.9.95
MODEL 129 as of 1.6.96
| Rear ventilation, location | Models 140, 210 | GF83.10-P-2105-02A | |
|---|---|---|---|
| Model 129 | GF83.10-P-2105-02B | ||
| Rear ventilation, purpose | After ventilation of the passenger compartment, air exits from the vehicle through the rear ventilation. | ||
| Rear ventilation, function | GF83.10-P-2105-01A |
Defroster nozzle, location/purpose/function - GF83.10-P-2144A
MODEL 210
MODEL 140 as of 1.9.95
MODEL 202
MODEL 208
MODEL 129 as of 1.6.96
| Defroster nozzle, location | Models 210, 202, 208 | GF83.10-P-2106-01A | |
|---|---|---|---|
| Model 140 | GF83.10-P-2106-01B | ||
| Model 129 | GF83.10-P-2106-01C | ||
| Defroster nozzle, purpose | The two-piece defroster nozzle serves for ventilation and keeping the windshield from fogging up. | ||
| Defroster nozzle, function | The air supply to the defroster nozzle can be opened and closed on the pushbutton control module. Separate adjustment is not possible. Blended air exits from the defroster nozzle. |
Front footwell air outlet, location/purpose/function - GF83.10-P-2145A
MODEL 210, 140 as of 1.9.95
| Front footwell air outlet, location | Model 210 | GF83.10-P-2109-02A | |
|---|---|---|---|
| Model 140 | GF83.10-P-2109-02B | ||
| Front footwell air outlet, purpose | The front footwell air outlet serves for ventilation of the left and right front footwell. | ||
| Front footwell air outlet, function | Model 210 | GF83.10-P-2109-01A | |
| Model 140 | GF83.10-P-2109-01B |
Rear footwell air outlet, location/purpose/function - GF83.10-P-2146A
MODEL 210
MODEL 140 as of 1.9.95
| Rear footwell air outlet, location | GF83.10-P-2110-02A | ||
|---|---|---|---|
| Rear footwell air outlet, purpose | The rear footwell air outlet serves for ventilation of the rear footwell. | ||
| Rear footwell air outlet, function | GF83.10-P-2110-01A |
Stowage compartment ventilation nozzle, location/purpose/function - GF83.10-P-2147A
MODEL 210 with CODE (570) Armrest with stowage compartment and rear compartment ventilation with CODE (954a) Avantgarde with CODE (955a) Elegance
| Stowage compartment ventilation nozzle, location | GF83.10-P-2112-02A | ||
|---|---|---|---|
| Stowage compartment ventilation nozzle, purpose | The stowage compartment ventilation nozzle (1) serves for ventilation of the stowage compartment and heating or cooling beverages or similar. | ||
| Stowage compartment ventilation nozzle, function | GF83.10-P-2112-01A |
Center nozzle, location/purpose/function - GF83.10-P-2149A
MODEL 210
MODEL 140 as of 1.9.95
MODEL 202
MODEL 208
MODEL 170
| Center nozzle, location | Models 170, 210, 202, 208 | GF83.10-P-2107-02A | |
|---|---|---|---|
| Model 140 | GF83.10-P-2107-02B | ||
| Center nozzle, purpose | The center nozzle provides for specific guidance and distribution of the air in the upper section of the front vehicle passenger compartment. | ||
| Center nozzle, function | Models 170, 210, 202, 208 | GF83.10-P-2107-01A | |
| Model 140 | GF83.10-P-2107-01B |
Rear compartment nozzle, location/purpose/function - GF83.10-P-2151A
MODEL 210 with CODE (570) Armrest with stowage compartment and rear compartment ventilation with CODE (954a) Avantgarde with CODE (955a) Elegance
MODEL 140 as of 1.9.95 except CODE (582) Rear air conditioning
| Rear compartment nozzle, location | Model 210 | GF83.10-P-2111-02A | |
|---|---|---|---|
| Model 140 | GF83.10-P-2111-02B | ||
| Rear compartment nozzle, purpose | The rear compartment nozzle provides for ventilation of the rear compartment in addition to the air outlets in the rear footwell | ||
| Rear compartment nozzle, function | Model 210 | GF83.10-P-2111-01A | |
| Model 140 | GF83.10-P-2111-01B |
Switchover valve, location/purpose/function - GF83.10-P-2155A
MODEL 210 except CODE (581a) Air conditioning (automatic)
| Switchover valve, location | GF83.10-P-2115-02A | ||
|---|---|---|---|
| Switchover valve, purpose | The switchover valve (Y13) controls the vacuum for actuation of the fresh air/ recirculated air flap. | ||
| Switchover valve, function | GF83.10-P-2115-01A |
Vacuum element for fresh air/recirculated air flap, location/purpose/function - GF83.10-P-2159A
MODEL 210, 208, 202, 170
| Vacuum element for fresh air/recirculated air flap, location | Model 210 | GF83.10-P-2122-02A | |
|---|---|---|---|
| Model 202 with code 580 up to 08/95 | GF83.10-P-2122-02C | ||
| Model 202 with code 305 up to 08/95 Model 202 with code 581a as of 09/95 Model 170 | GF83.10-P-2122-02D | ||
| Model 202 with code 581a | GF83.10-P-2122-02E | ||
| Model 208 | GF83.10-P-2122-02G | ||
| Vacuum element for fresh air/recirculated air flap, purpose | The vacuum element for the fresh air/ recirculated air flap serves for switching over from fresh air to recirculated air. | ||
| Model 210 | GF83.10-P-2122-01A | ||
| Model 202 with code 580 up to 08/95 | GF83.10-P-2122-01C | ||
| Vacuum element for fresh air/recirculated air flap, function | Model 202 with code 305 up to 08/95 Model 202 except code 581a as of 09/95 Model 170 | GF83.10-P-2122-01D | |
| Model 202 with code 581a | GF83.10-P-2122-01E | ||
| Model 208 | GF83.10-P-2122-01G |
Duovalve, location - GF83.20-P-2100-02A
The duovalve (Y21) is located at the right rear in the engine compartment.
Scheme 81
Heater core, location - GF83.20-P-2101-02A
Illustrated on model 210
The heater core (1) is located behind the instrument panel in the heater/air conditioning housing.
Scheme 82
Coolant circulation pump, location - GF83.20-P-2102-02A
The coolant circulation pump (M13) is located at the right front in the engine compartment.
Scheme 83
Heater housing, location - GF83.20-P-2103-01A
The heater housing (1) is located below the instrument panel.
Scheme 84
Heater housing, location/purpose/design/function - GF83.20-P-2103A
MODEL 210
Illustrated with automatic heater (HEAT) design
Scheme 85
Heater housing location GF83.20-P-2103-01A Heater housing Purpose GF83.20-P-2103-03A Heater housing function Air guidance in heater housing in normal operation (HEAT) GF83.20-P-2103-02A Heater housing function Air guidance in heater housing in heating mode (HEAT) GF83.20-P-2103-02B
Fresh/recirculated air flap, location - GF83.20-P-2104-01A
Illustrated on model 210
The fresh/recirculated air flap (2, 3) is located behind the instrument panel on the heater or air conditioning housing.
Scheme 86
Scheme 87
Function
In the fresh air mode ( not burning) the fresh air flap (2) is open and the recirculated air flap (3) closed. Fresh air is sucked into the heater/ air conditioning housing by the blower
If the pushbutton control module (N18, N19, N22) is switched over to recirculated air, the vacuum element (5) and the linkage (4) close the fresh air flap (2) and simultaneously open the recirculated air flap (3). Air is sucked out of the vehicle passenger compartment into the heater/air conditioning housing by the blower.
Function with HEAT
The system switches over automatically from recirculated air to fresh air
- after 5 minutes.
Function with air conditioning (Tempmatic)
The system switches over automatically from recirculated air to fresh air
- After 30 minutes at outdoor temperature above approx. 5° C
- After 5 minutes at outdoor temperature below approx. 5 °C
- After 5 minutes when is selected.
At outdoor temperatures above 26° C the system switches over to recirculated air automatically. The system switches back to fresh air automatically after approx. 30 minutes depending on the difference between the passenger compartment temperature and temperature set.
Function with automatic air conditioning (automatic A/C)
The system switches over automatically from recirculated air to fresh air
- After 30 minutes at outdoor temperature above approx. 5° C
- After 5 minutes at outdoor temperature below approx. 5 °C
- After 5 minutes when is selected.
At outdoor temperatures above 26° C the system switches over to recirculated air automatically. After approx. 30 minutes the system switches automatically to 80 % recirculated air or to fresh air depending on the difference between the passenger compartment temperature and temperature set.
Automatic switchover is possible only at temperature above 20° C.
The system can also be switched over to recirculated air automatically by the smog sensor (B31).
Fresh/recirculated air flap, location/purpose/design/function - GF83.20-P-2104A
MODEL 210
MODEL 202 up to 31.8.95 with CODE (305a) Dust filter with CODE (450) Taxi version with CODE (580) Air conditioning or, for USA, Tempmatic A/C with CODE (581a) Air conditioning (automatic)
MODEL 202 as of 1.9.95
MODEL 208
MODEL 170
MODEL 140 as of 1.9.95
MODEL 129 as of 1.6.96
Illustrated on model 210 Design
Scheme 88
| Fresh/recirculated air flap, location | GF83.20-P-2104-01A | ||
|---|---|---|---|
| Fresh/recirculated air flap, Purpose | The fresh/recirculated air flap allows the system to be switched over from fresh air to recirculated air. The fresh air flap (2) and recirculated air flap (3) are consolidated to form one unit in a housing (1) and connected with one another by a linkage (4). | ||
| Fresh/recirculated air flap, function | Model 210 | GF83.20-P-2104-02A | |
| Models 202/208 | GF83.20-P-2104-02E | ||
| Model 170 | GF83.20-P-2104-02G | ||
| Model 140 | GF83.20-P-2104-02S | ||
| Model 129 | GF83.20-P-2104-02B |
Duovalve, location/purpose/function - GF83.20-P-2107A
MODEL 210
MODEL 140 as of 1.9.95 except CODE (582) Rear air conditioning
MODEL 202
MODEL 208
MODEL 170
| Duovalve, location | Model 210 | GF83.20-P-2100-02A | |
|---|---|---|---|
| Model 140 | GF83.20-P-2100-02B | ||
| Model 202/208 | GF83.20-P-2100-02E | ||
| Model 170 | GF83.20-P-2100-02G | ||
| Duovalve, purpose | The duovalve regulates the quantity of coolant flowing through the heater core. | ||
| Duovalve, function | Models 170/210/202/208 | GF83.20-P-2100-01A | |
| Model 140 | GF83.20-P-2100-01B |
Heater core, location/purpose/function - GF83.20-P-2108A
MODEL 210
MODEL 140 as of 1.9.95 except CODE (582) Rear air conditioning
MODEL 129 as of 1.6.96
| Heater core, location | Model 210 | GF83.20-P-2101-02A | |
|---|---|---|---|
| Model 140, 129 | GF83.20-P-2101-02B | ||
| Heater core, purpose | The heater core serves for heating the air flowing through to the various defroster, ventilation and heating nozzles in the vehicle passenger compartment. | ||
| Heater core, function | GF83.20-P-2101-01A |
Coolant circulation pump, location/purpose/function - GF83.20-P-2109A
MODEL 210
MODEL 140 as of 1.9.95 except CODE (582) Rear air conditioning
MODEL 202
MODEL 208
MODEL 170 as of 1.9.97
MODEL 129 as of 1.6.96
| Coolant circulation pump, location | Model 210 | GF83.20-P-2102-02A | |
|---|---|---|---|
| Model 140 | GF83.20-P-2102-02B | ||
| Model 202 | GF83.20-P-2102-02E | ||
| Model 208 | GF83.20-P-2102-02K | ||
| Model 170 | GF83.20-P-2102-02G | ||
| Model 129 | GF83.20-P-2102-02C | ||
| Coolant circulation pump, purpose | The coolant circulation pump serves for maintaining a uniform flow of heating water through the heater core even at low engine speeds and in the residual engine heat utilization mode. | ||
| Coolant circulation pump, function | GF83.20-P-2102-01A |
Blower switch, location - GF83.25-P-2100-01A
Illustration: Automatic heater (HEAT) in model 210
The blower switch (2) is located on the pushbutton control module (N18).
Scheme 89
Air distribution knob, location - GF83.25-P-2101-02A
Illustration: Automatic heater (HEAT) in model 210
The air distribution knob (3) is located on the pushbutton control module (N18).
Scheme 90
Temperature dial, location - GF83.25-P-2102-02A
Illustrated with automatic heater (HEAT) Model 210
The temperature dials (1) are located on the pushbutton control module (N18).
Scheme 91
Air distribution switch, location/purpose/function - GF83.25-P-2103A
MODEL 210, 202, 208 except CODE (581a) Air conditioning (automatic)
| Air distribution switch, location | Model 202 up to 08/95 | GF83.25-P-2101-02E | |
|---|---|---|---|
| Models 210, 208, 202 as of 09/95 | GF83.25-P-2101-02A | ||
| Air distribution switch, purpose | The air distribution switch controls the air to the air outlets for ventilation of the vehicle passenger compartment. | ||
| Air distribution switch, function | Model 202 up to 08/95 | GF83.25-P-2101-01E | |
| Models 210, 208, 202 as of 09/95 | GF83.25-P-2101-01A |
Blower switch, location/purpose/function - GF83.25-P-2104A
MODEL 210, 202, 208 except CODE (581a) Air conditioning (automatic)
| Blower switch, location | Model 202 up to 08/95 | GF83.25-P-2100-01E | |
|---|---|---|---|
| Models 210, 208, 202 as of 09/95 | GF83.25-P-2100-01A | ||
| Blower switch, purpose | The blower switch switches the 4 or 5 blower stages for the fresh air and recirculated air mode. | ||
| Blower switch, function | Model 202 up to 08/95 | GF83.25-P-2100-02E | |
| Models 210, 208, 202 as of 09/95 | GF83.25-P-2100-02A |
Temperature selector, location/purpose/function - GF83.25-P-2105A
MODEL 210, 202, 208, 170 except CODE (581a) Air conditioning (automatic)
| Temperature selector, location | Model 202 up to 08/95 | GF83.25-P-2102-02E | |
|---|---|---|---|
| Models 210, 208, 202 as of 09/95 | GF83.25-P-2102-02A | ||
| Model 170 | GF83.25-P-2102-02G | ||
| Temperature selector, purpose | The temperature selector serves for setting the desired temperature in the vehicle passenger compartment. | ||
| Temperature selector, function | Models 210, 208, 202 | GF83.25-P-2102-01A | |
| Model 170 | GF83.25-P-2102-01G |
Automatic temperature control (TAC), location of components - GF83.30-P-0001-03A
Components in passenger compartment
Illustrated on model 210
Scheme 92
Automatic temperature control (TAC), location of components - GF83.30-P-0001-03B
Components in engine compartment
Illustrated on model 210
Scheme 93
Model 210 only
Scheme 94
Illustrated on model 210
Scheme 95
Model 210 only
Scheme 96
Illustrated on model 210
Scheme 97
Illustrated on model 210
Scheme 98
Illustrated on model 210
Scheme 99
Illustrated on model 210
Scheme 100
Automatic temperature control (TAC), location of components - GF83.30-P-0001-03C
Control module, cycle module
Scheme 101
Scheme 102
Automatic temperature control (TAC), location of components - GF83.30-P-0001-03E
Pneumatic components, model 210
Scheme 103
Scheme 104
Automatic temperature control (TAC), location of components - GF83.30-P-0001-03G
A/C components, model 210
Scheme 105
Air conditioning housing, location - GF83.30-P-2104-01A
The air conditioning housing (1) is located below the instrument panel.
Scheme 106
Air conditioning housing, location/purpose/design/function - GF83.30-P-2104A
MODEL 210 with CODE (580) Air conditioning or, for USA, Tempmatic A/C
Design
Scheme 107
Air conditioning housing, location GF83.30-P-2104-01A Air conditioning housing, purpose GF83.30-P-2104-04A Air conditioning housing, function Air guidance in air conditioning housing in normal operation (Tempmatic) GF83.30-P-2104-02A Air guidance in air conditioning housing in cooling mode (Tempmatic) GF83.30-P-2104-02B Air guidance in air conditioning housing in heating mode (Tempmatic) GF83.30-P-2104-02C
Receiver/drier (Tempmatic A/C), location - GF83.30-P-2106-01A
The receiver/drier (1) is located at the bottom of the engine compartment at the left front.
Scheme 108
Receiver/drier (Tempmatic A/C), location/purpose/function - GF83.30-P-2120A
MODEL 210 with CODE (580) Air conditioning or, for USA, Tempmatic A/C
MODEL 202 with CODE (580) Air conditioning or, for USA, Tempmatic A/C
MODEL 208 with CODE (580) Air conditioning or, for USA, Tempmatic A/C
MODEL 170 with CODE (580) Air conditioning or, for USA, Tempmatic A/
| Receiver/drier (TAC), location | Model 210 | GF83.30-P-2106-01A | |
|---|---|---|---|
| Models 202, 208 | GF83.30-P-2106-01E | ||
| Model 170 | GF83.30-P-2106-01G | ||
| Receiver/drier (TAC), purpose | Filtering chemical and mechanical impurities out of the refrigerant Storage reservoir for refrigerant Removal of water in refrigerant | ||
| Receiver/drier (TAC), function | GF83.30-P-2106-02A |
Air conditioning (automatic), location of components - GF83.40-P-0001-01B
Electrical
Location of components in passenger compartment
Scheme 109
Location of components in engine compartment
Scheme 110
Scheme 111
Scheme 112
Scheme 113
Scheme 114
Scheme 115
Scheme 116
Scheme 117
Scheme 118
Scheme 119
Air conditioning (Automatic) (Automatic) A/C, location of components - GF83.40-P-0001-01C
Location of pneumatic components
Scheme 120
Location of components since 09/96
Scheme 121
Location of components
Scheme 122
Air conditioning (Automatic) (Automatic) A/C, location of components - GF83.40-P-0001-01D
Location of components, cryogenics section
Scheme 123
The recirculated air button is located on the pushbutton control module (N22)
Scheme 124
The button is located on the pushbutton control module (N22)
Scheme 125
The pushbutton is located in the A/C pushbutton control module (N22)
Scheme 126
Automatic air conditioning (automatic A/C)
The button is located on the pushbutton control module (N22)
Scheme 127
Air conditioning (Tempmatic)
On the taxi version (code 450) the button is combined with the button
Scheme 128
Automatic heater (HEAT)
On the taxi version (code 450) the button is combined with the button
Scheme 129
Auxiliary fan, location - GF83.40-P-2115-02A
The auxiliary fan (M4) is located behind the radiator shroud.
Scheme 130
Cycle module, location - GF83.40-P-2116-02A
The cycle module (N65) is located in the fuse and relay box.
Scheme 131
AIR control module, location - GF83.40-P-2117-02A
Illustrated on engines 104, 602, 604, 605 and 606 from 09/95 to 02/97
The AIR control module (N65/1) is located in the left front wheelhouse.
Scheme 132
Illustrated on engines 113, 602, 604, 605 and 606 as of 03/97, 112 up to 05/98 and 613 as of 07/99
The AIR control module (N65/1) is located in the left front wheelhouse.
Scheme 133
Engine/AC electric suction fan, location - GF83.40-P-2118-02A
Illustrated on 210
The engine/AC electric suction fan (M4/3) is located behind the radiator grill.
Scheme 134
Electric suction-type fan control module (engine/A/C), location - GF83.40-P-2119-02A
Illustrated: With code 210
The electric suction-type fan control module (engine/A/C) (N76) is located in the front left wheelhouse.
Scheme 135
Condenser, location - GF83.40-P-2120-02A
Illustrated in model 210
The condenser (1) is located behind the radiator grille directly in front of the radiator.
Scheme 136
Evaporator, location - GF83.40-P-2121-02A
Illustrated on model 210
The evaporator (1) is located in the air conditioning housing behind the instrument panel. Illustrated: Behr version.
Scheme 137
Expansion valve, location - GF83.40-P-2123-02A
Illustrated on model 210
The expansion valve (1) is located at the left rear in the engine compartment next to the brake servo-unit.
Scheme 138
Expansion valve, location/purpose/design/function - GF83.40-P-2123A
MODEL 210 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (Automatic) with CODE (498) Japanese version
MODEL 140 as of 1.9.95
MODEL 202 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (Automatic)
MODEL 208 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (Automatic)
MODEL 170 with CODE (580) Air conditioning or Tempmatic for USA
MODEL 129 as of 1.6.96
Design
Scheme 139
| Expansion valve, location | Model 140, 202, 208 and 210 | GF83.40-P-2123-02A | |
|---|---|---|---|
| Model 170 | GF83.40-P-2123-02G | ||
| Model 129 | GF83.40-P-2123-02B | ||
| Expansion valve, Purpose | The expansion valve sprays the liquid refrigerant into the evaporator. | ||
| Expansion valve, function | GF83.40-P-2123-01A |
ECT sensor, location - GF83.40-P-2125-02A
Illustrated on model 210
The ECT sensor (B11/4) is located on the engine in the thermostat housing.
Scheme 140
Refrigerant pressure sensor, location - GF83.40-P-2126-02A
The refrigerant pressure sensor (B12) is located on the receiver/drier at the front left in the engine compartment.
Scheme 141
MODEL 210 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version
MODEL 140 up to 30.3.97 with CODE (498) Japanese version with CODE (350b) Information and communication system (ICS)
MODEL 140 as of 1.4.97 with CODE (498) Japanese version
EC pushbutton, location Model 210 with code 580 and 581a GF83.40-P-2103-02A Models 210 and 140 Japanese version GF83.40-P-2103-02B EC pushbutton, purpose The EC pushbutton ( ) serves for switching the air conditioning on and off. EC pushbutton, function GF83.40-P-2103-01A
MODEL 210 with CODE (581a) Air conditioning (automatic)
MODEL 140 as of 1.9.95
MODEL 129 as of 1.6.96
Auto pushbutton, location Model 210 with code 581a GF83.40-P-2106-02A Models 210 and 140 Japanese version GF83.40-P-2106-02B Model 140 as of 09/95 GF83.40-P-2106-02K Model 129 GF83.40-P-2106-02C Auto pushbutton, purpose When the automatic pushbutton ( ) is pressed, the automatic circuit is activated (air distribution, blower speed, temperature control). Auto pushbutton, function Models 140, 210 GF83.40-P-2106-01A Model 129 GF83.40-P-2106-01B
MODEL 210 with CODE (450) Taxi version with CODE (581a) Air conditioning (automatic) with CODE (670a) Residual engine heat utilization MRA with CODE (498) Japanese version
MODEL 210 as of 1.9.97 with CODE (580) Air conditioning or Tempmatic for USA
MODEL 140 as of 1.9.95
MODEL 202 up to 31.8.95 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (450) Taxi version
MODEL 202 as of 1.9.95 up to 31.8.97 with CODE (581a) Air conditioning (automatic) with CODE (450) Taxi version
MODEL 202 as of 1.9.97
MODEL 208
MODEL 170 as of 1.9.97
MODEL 129 as of 1.6.96
REST pushbutton, location Model 210 with code 450, 581a, 670a Model 210 with code 580 as of 01.09.97 GF83.40-P-2109-02A Models 210 and 140 Japanese version GF83.40-P-2109-02B Model 202 up to 08/95 GF83.40-P-2109-02C Model 202 as of 09/95 GF83.40-P-2109-02E Model 208 except code 581a Model 208 with code 581a, 140 as of 09/95 GF83.40-P-2109-02K Model 170 GF83.40-P-2109-02G Model 129 GF83.40-P-2109-02D REST pushbutton, purpose The REST pushbutton ( ) serves for switching the residual engine heat utilization function on and off. REST pushbutton, function Models 210, 140 as of 09/95 Models 129, 208, 202 as of 09/95 Model 170 GF83.40-P-2109-01A Model 202 up to 08/95 GF83.40-P-2109-01E
Engine/air conditioning electric fan, location/purpose/function - GF83.40-P-2151A
MODEL 210 with ENGINE 111 (except 111.947) as of 1.9.96, 111.947 as of 1.3.97, 112 as of 1.6.98, 611 as of 1.3.97 with CODE (580) Air conditioning or, for USA, Tempmatic A/C with CODE (581a) Air conditioning (automatic)
| Engine/AC electric fan, location | GF83.40-P-2118-02A | ||
|---|---|---|---|
| Engine/AC electric fan, purpose | The engine/AC electric fan (M4/3) serves for cooling the coolant and refrigerant. | ||
| Engine/AC electric fan, function | GF83.40-P-2118-01A |
Air conditioning coolant temperature sensor, location/purpose/function - GF83.40-P-2155A
MODEL 210 with CODE (580) Automatic air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version
MODEL 140 as of 1.9.95
MODEL 202 with CODE (580) Automatic air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 208 with CODE (580) Automatic air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 170 with CODE (580) Automatic air conditioning or Tempmatic for USA
MODEL 129 as of 1.6.96
| Air conditioning coolant temperature sensor, location | Models 170, 210, 140, 208 and 202 as of 09/95 | GF83.40-P-2125-02A | |
|---|---|---|---|
| Model 202 up to 08/95 | GF83.40-P-2125-02E | ||
| Model 129 | GF83.40-P-2125-02C | ||
| Air conditioning coolant temperature sensor, purpose | The air conditioning coolant temperature sensor serves for measuring the coolant temperature. | ||
| Air conditioning coolant temperature sensor, function | Models 129, 170, 210, 140, 208 and 202 as of 09/95 | GF83.40-P-2125-01A | |
| Models 202 up to 08/95 | GF83.40-P-2125-01E |
Refrigerant pressure sensor, location/purpose/function - GF83.40-P-2156A
MODEL 210 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version
MODEL 140 as of 1.9.95
MODEL 202 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 208 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 170 with CODE (580) Air conditioning or Tempmatic for USA
MODEL 129 as of 1.6.96
| Refrigerant pressure sensor, location | Model 210 | GF83.40-P-2126-02A | |
|---|---|---|---|
| Model 140 | GF83.40-P-2126-02B | ||
| Models 202, 208 | GF83.40-P-2126-02E | ||
| Model 170 | GF83.40-P-2126-02G | ||
| Model 129 | GF83.40-P-2126-02C | ||
| Refrigerant pressure sensor, purpose | The refrigerant pressure sensor serves for measuring the refrigerant pressure. | ||
| Refrigerant pressure sensor, function | GF83.40-P-2126-01A |
Auxiliary fan, location/purpose/function - GF83.40-P-2162A
MODEL 210 with ENGINE 104, 111 up to 31.8.96, 112 up to 31.5.98, 113 as of 1.3.97, 119, 602, 604, 605, 606, 613 as of 1.7.99 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version
MODEL 140 as of 1.9.95
MODEL 129 as of 1.6.96
| Auxiliary fan, location | Model 210 | GF83.40-P-2115-02A | |
|---|---|---|---|
| Model 140 | GF83.40-P-2115-02B | ||
| Model 129 | GF83.40-P-2115-02C | ||
| Auxiliary fan, purpose | The auxiliary fan (M4) serves for cooling the coolant and refrigerant. | ||
| Auxiliary fan, function | Model 210 | GF83.40-P-2115-01A | |
| Model 140 Japanese version | GF83.40-P-2115-01B | ||
| Model 140 as of 09/95, 129 | GF83.40-P-2115-01S |
Auxiliary fan control module, location/purpose/function - GF83.40-P-2163A
MODEL 210 with ENGINE 104 as of 1.9.96 up to 28.2.97, 602, 604, 605, 606 as of 1.9.96, 112 up to 31.5.98, 113 as of 1.3.97, 613 as of 1.7.99 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version
MODEL 140 as of 1.9.95
MODEL 129 as of 1.6.96
| Auxiliary fan control module, location | Model 210 | GF83.40-P-2117-02A | |
|---|---|---|---|
| Model 210 Japanese version | GF83.40-P-2117-02B | ||
| Model 140 | GF83.40-P-2117-02C | ||
| Model 129 | GF83.40-P-2117-02D | ||
| Auxiliary fan control module, purpose | The auxiliary fan control module switches on the auxiliary fan. | ||
| Auxiliary fan control module, function | Models 140, 210 | GF83.40-P-2117-01A | |
| Model 129 | GF83.40-P-2117-01B |
Evaporator, location/purpose/function - GF83.40-P-2164A
MODEL 210 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version
MODEL 140 as of 1.9.95
MODEL 202 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 208 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 170 with CODE (580) Air conditioning or Tempmatic for USA
MODEL 129 as of 1.6.96
| Evaporator, location | Models 170, 210, 202 and 208 | GF83.40-P-2121-02A | |
|---|---|---|---|
| Model 140 | GF83.40-P-2121-02B | ||
| Model 129 | GF83.40-P-2121-02C | ||
| Evaporator, purpose | The evaporator serves for cooling, dehumidifying and purifying the passenger compartment air. | ||
| Evaporator, function | GF83.40-P-2121-01A |
Cycle module, location/purpose/function - GF83.40-P-2166A
MODEL 210 with ENGINE 104, 111 up to 31.8.96, 119, 602, 604, 605, 606 up to 31.8.96 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
| Cycle module, location | GF83.40-P-2116-02A | ||
|---|---|---|---|
| Cycle module, purpose | The cycle module (N65) controls the infinite speed of the auxiliary fan (M4). | ||
| Cycle module, function | GF83.40-P-2116-01A |
Engine/AC electric fan control module, location/purpose/function - GF83.40-P-2167A
MODEL 210 with ENGINE 111 (except 111.947) as of 1.9.96, 111.947 as of 1.3.97, 112 as of 1.6.98, 611 as of 1.3.97 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
| Engine/AC electric fan control module, location | GF83.40-P-2119-02A | ||
|---|---|---|---|
| Engine/AC electric fan control module, purpose | The engine/AC electric fan control module (N76) switches on the engine/AC electric fan (M4/3). | ||
| Engine/AC electric fan control module, function | GF83.40-P-2119-01A |
A/C compressor, location - GF83.55-P-2100-01A
Illustrated on model 210
The A/C compressor (A9) is attached to the engine at the front left.
Scheme 142
A/C compressor, location/purpose/design/function - GF83.55-P-2100A
ENGINE 111, 112, 113, 119, 602, 604, 605, 606, 611, 613 as of 1.7.99 in MODEL 210 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version A/C compressor 7SB16C
ENGINE 104, 119 in MODEL 140 as of 1.9.95 A/C compressor 7SB16C
ENGINE 603.971 in MODEL 140 as of 1.9.95 up to 31.5.96 A/C compressor 7SB16C
ENGINE 606.961 in MODEL 140 as of 1.6.96 A/C compressor 7SB16C
ENGINE 104, 111, 112, 601, 604, 605, 611 in MODEL 202 as of 1.9.95 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) A/C compressor 7SB16C
ENGINE 111, 112 in MODEL 208 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) A/C compressor 7SB16C
ENGINE 111 in MODEL 170 with CODE (580) Air conditioning or Tempmatic for USA A/C compressor 7SB16C
Design
A/C compressor 7SB16C
Scheme 143
| A/C compressor, location | Model 210, 140 | GF83.55-P-2100-01A | |
|---|---|---|---|
| Models 208, 202 as of 09/95 | GF83.55-P-2100-01C | ||
| Model 170 | GF83.55-P-2100-01G | ||
| A/C compressor, purpose | The A/C compressor (A9) is responsible for sucking in and compressing the refrigerant. | ||
| A/C compressor, function | GF83.55-P-2100-02A |
Electromagnetic clutch, location - GF83.55-P-2101-02A
The electromagnetic clutch is located on the drive shaft of the A/C compressor (A9) at the left front in the engine compartment.
Scheme 144
Electromagnetic clutch, location/purpose/design/function - GF83.55-P-2101A
ENGINE 111, 112, 113, 119, 602, 604, 605, 606, 611, 613 as of 1.7.99 in MODEL 210 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (Automatic) with CODE (498) Japanese version
ENGINE 104, 119, 120 in MODEL 140 as of 1.9.95
ENGINE 603.971 in MODEL 140 as of 1.9.95 up to 31.5.96
ENGINE 606.961 in MODEL 140 as of 1.6.96
ENGINE 104, 111, 112, 601, 604, 605, 611 in MODEL 202 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (Automatic)
ENGINE 111, 112 in MODEL 208 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (Automatic)
ENGINE 111 in MODEL 170 with CODE (580) Air conditioning or Tempmatic for USA
| Electromagnetic clutch, location | Model 210 | GF83.55-P-2101-02A | |
|---|---|---|---|
| Model 140 | GF83.55-P-2101-02B | ||
| Model 208, 202 as of 09/95 | GF83.55-P-2101-02C | ||
| Model 202 up to 08/95 | GF83.55-P-2101-02E | ||
| Model 170 | GF83.55-P-2101-02G | ||
| Electromagnetic clutch, purpose | Connect the power flow between the vehicle engine and A/C compressor Switch off the A/C compressor in the event of a mechanical defect. | ||
| Electromagnetic clutch, design | GF83.55-P-2101-03A | ||
| Electromagnetic clutch, function | Model 170, 210, 208, 202 | GF83.55-P-2101-01A | |
| Model 140 | GF83.55-P-2101-01B |
In-car temperature sensor with aspirator blower, location - GF83.57-P-2100-01A
Illustrated on model 210
The in-car temperature sensor with aspirator blower (B10/4) is located in the dome light on the vehicle headliner.
Scheme 145
Heater core temperature sensor, location - GF83.57-P-2101-02A
Illustrated on model 210
The heater core temperature sensor (B10/1) is located on the heater/air conditioning housing behind the heater core.
Scheme 146
Evaporator temperature sensor, location - GF83.57-P-2102-01A
Illustrated on model 210
The evaporator temperature sensor (B10/6) is located in the air flow behind the evaporator.
Scheme 147
Outside air temperature sensor, location - GF83.57-P-2103-02A
The outside air temperature sensor (B14) is located at the front left in the bumper.
Scheme 148
Outside temperature sensor, location/purpose/design/function - GF83.57-P-2103B
MODEL 208, 210
| Outside temperature sensor, location | GF83.57-P-2103-02S | ||
|---|---|---|---|
| Outside temperature sensor, purpose | Capture of outside temperature as electrical value: for display of the outside temperature in the instrument cluster (A1) and for control of various functions depending on the outside air temperature. | ||
| Outside temperature sensor, design | The sensor is located in a plastic housing clipped to the vehicle | ||
| Outside temperature sensor, function | The outside temperature sensor (B14) is a temperature dependent resistor with negative temperature coefficient (NTC): The resistance decreases as the temperature increases . The outside temperature sensor (B14) is read in directly by the instrument cluster (A1). |
In-car temperature sensor with fresh air blower, location/purpose/function - GF83.57-P-2107A
MODEL 210
MODEL 140 as of 1.9.95
MODEL 202
MODEL 208
MODEL 129 as of 1.6.96
| In-car temperature sensor with fresh air blower, location | Models 210, 208 Model 202 except HEAT without dust filter up to 08/95 | GF83.57-P-2100-01A | |
|---|---|---|---|
| Model 140 | GF83.57-P-2100-01B | ||
| Model 202 with HEAT without dust filter up to 08/95 | GF83.57-P-2100-01E | ||
| Model 129 | GF83.57-P-2100-01C | ||
| In-car temperature sensor with fresh air blower, purpose | The in-car temperature sensor with fresh air blower serves for measuring the temperature in the vehicle passenger compartment | ||
| In-car temperature sensor with fresh air blower, function | Models 210, 140, 208, 129 Model 202 except HEAT without dust filter up to 08/95 | GF83.57-P-2100-02A | |
| Model 202 with HEAT without dust filter up to 08/95 | GF83.57-P-2100-02E |
Heater core temperature sensor, location/purpose/function - GF83.57-P-2108A
MODEL 210
MODEL 140 as of 1.9.95
MODEL 202 as of 1.9.95
MODEL 208
MODEL 170
MODEL 129 as of 1.6.96
| Heater core temperature sensor, location | Models 210, 208, 202 as of 09/95 | GF83.57-P-2101-02A | |
|---|---|---|---|
| Model 202 up to 08/95 | GF83.57-P-2101-02E | ||
| Model 140 | GF83.57-P-2101-02B | ||
| Model 170 | GF83.57-P-2101-02G | ||
| Model 129 | GF83.57-P-2101-02C | ||
| Heater core temperature sensor, purpose | The heater core temperature sensor measures the temperature of the heated air downstream of the heater core separately for the left and right sides. | ||
| Heater core temperature sensor, function | Models 140, 170, 202, 208, 210 | GF83.57-P-2101-01A | |
| Model 129 | GF83.57-P-2101-01B |
Evaporator temperature sensor, location/purpose/function - GF83.57-P-2109A
MODEL 210 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic) with CODE (498) Japanese version
MODEL 140 as of 1.9.95
MODEL 202 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 208 with CODE (580) Air conditioning or Tempmatic for USA with CODE (581a) Air conditioning (automatic)
MODEL 170 with CODE (580) Air conditioning or Tempmatic for USA
MODEL 129 as of 1.6.96
| Evaporator temperature sensor, location | Models 210, 208 | GF83.57-P-2102-01A | |
|---|---|---|---|
| Model 140 | GF83.57-P-2102-01B | ||
| Model 202 | GF83.57-P-2102-01E | ||
| Model 170 | GF83.57-P-2102-01G | ||
| Model 129 | GF83.57-P-2102-01C | ||
| Evaporator temperature sensor, purpose | The evaporator temperature sensor (B10/6) measures the evaporator temperature. | ||
| Evaporator temperature sensor, function | GF83.57-P-2102-02A |
