Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04G
Transmission 722.6 without touch shift in models 170, 202, 208, 210 TRANSMISSION 722.6 in MODELS 129, 140
Scheme 280
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04GB
Transmission 722.6 with touch shift in models 170, 202, 208, 210
Scheme 281
Automatic transmission (AT), location of mechanical parts - GF27.10-P-0001-07G
Transmission 722.6
Scheme 282
Automatic transmission (AT), location of electric/electronic components - GF27.10-P-0001-08G
Transmission 722.6
Scheme 283
Parking lock, location / task / design / function - GF27.10-P-5100G
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODELS 129, 140
Scheme 284
| Park pawl, location | The park pawl gear (4) and park pawl mechanism (4b) are located in the rear section of the transmission housing. | ||
|---|---|---|---|
| Park pawl, task | In addition to the parking brake, the park pawl provides extra mechanical security against the vehicle rolling away. | ||
| Park pawl, design | GF27.10-P-5100-03G | ||
| Park pawl, function | GF27.10-P-5100-02G |
Park pawl, location/task/design/function - GF27.10-P-5100GA
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 With tip control
TRANSMISSION 722.6 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230, 240
Scheme 285
| Park pawl, location | The park pawl gear (4) and park pawl mechanism (4a) are located in the rear part of the transmission housing. | ||
|---|---|---|---|
| Park pawl, task | Secures the vehicle mechanically to prevent it from rolling in addition to the parking brake. | ||
| Park pawl, design | GF27.10-P-5100-03GA | ||
| Park pawl, function | GF27.10-P-5100-02GA |
Location / task / design / function of oil pump - GF27.10-P-5103G
TRANSMISSION 722.6
Scheme 286
| Oil pump, location | The oil pump (crescent-type pump) (6) is installed in the torque converter housing behind the torque converter and is driven by the drive flange of the torque converter. | ||
|---|---|---|---|
| Oil pump, task | To produce the necessary oil pressure for the hydraulic sequences. | ||
| Oil pump, design | An external gear (6a) which is mounted eccentrically in the pump housing in located on the internal gear (6b) which is connected to the drive flange (6b). The crescent (6c) drives the external gear (6a). | ||
| Oil pump, function | When the engine is running oil is delivered through the suction gallery (6e) along the top and bottom side of the crescent (6c) to the pressure chamber (6d) of the housing. The meshing of the teeth prevents oil from flowing from the pressure side to the suction side. |
Float, location/function - GF27.10-P-5107G
TRANSMISSION 722.6
Scheme 287
| Float, location | In the electrical control unit (Y3/6). | ||
|---|---|---|---|
| Float, function | GF27.10-P-5107-04G |
Survey of system components, automatic transmission (AT), location / task / design / function - GF27.10-P-9990GB
TRANSMISSION 722.6 in MODEL 170, 202, 208, 210 with touch shift
| Starter lock-out contact, location / task / design / function | GF27.19-P-5106G | ||
|---|---|---|---|
| Torque converter, location / task / design / function | GF27.20-P-5100G | ||
| Wheel speed sensor, location / task / function | GF27.19-P-5127G | ||
| Electric control module, location / task / design / function | GF27.19-P-5104G | ||
| Location / task / design / function of freewheel | GF27.51-P-5102G | ||
| Transmission housing breathing, location/task | GF27.40-P-2007G | ||
| Kick-down switch, location/task/design | GF27.19-P-5141GA | ||
| Location/task/function of command valve | GF27.60-P-5138G | ||
| Multiple-disc brake, location / task / design / function | GF27.51-P-5100G | ||
| Multi-plate clutch, location / task / design / function | GF27.51-P-5101G | ||
| Upshift / downshift solenoid valve, location / task / design / function | GF27.19-P-4006G | ||
| Floor shift, location / task / design / function | GF27.60-P-5100GB | ||
| Location / task / design / function of oil pump | GF27.10-P-5103G | ||
| Parking lock, location / task / design / function | GF27.10-P-5100GA | ||
| Planetary gear set, location / task / design / function | GF27.50-P-5100G | ||
| Position indicator, location/task | GF27.19-P-5139GB | ||
| Location / task / design / function of PWM solenoid valve, torque converter lockup clutch | GF27.19-P-5112G | ||
| Modulating pressure regulating solenoid valve, location / task / design / function | GF27.19-P-5110G | ||
| Shift pressure regulating solenoid valve, location / task / design / function | GF27.19-P-5109G | ||
| Working pressure regulating valve, location/ task/function | GF27.60-P-5131G | ||
| Regulating valve pressure regulating valve, location / task / function | GF27.60-P-5133G | ||
| Shift pressure regulating valve, location / task / function | GF27.60-P-5132G | ||
| Shift valve pressure regulating valve, location/ task/function | GF27.60-P-5134G | ||
| Lubrication pressure regulating valve, location/ task/function | GF27.60-P-5122G | ||
| Overlap regulating valve, location / task / function | GF27.60-P-5137G | ||
| Torque converter lockup clutch regulating valve, location/task/function | GF27.60-P-5123G | ||
| Location / task / design / function of R/P lock | GF27.60-P-5103GB | ||
| Shift detent mechanism, location / task / design / function | GF27.60-P-5101GB | ||
| Holding pressure shift valve, location/task/ function | GF27.60-P-5135G | ||
| Shift pressure shift valve, location / task / function | GF27.60-P-5136G | ||
| Float, location/design / function | GF27.10-P-5107G | ||
| ETC control module, location/task | GF27.19-P-4012G | ||
| Electronic selector lever module control module, location/task/design | GF27.19-P-5138GB | ||
| Temperature sensor, location / task / design / function | GF27.19-P-5108G | ||
| Selector valve, location/task | GF27.60-P-5139G | ||
| Torque converter lock-up clutch, location/task/ design / function | GF27.20-P-5101G | ||
| Automatic transmission (AT), contents, function description | GF27.10-P-0999GB |
Survey of system components, automatic transmission (AT), location / task / design / function - GF27.10-P-9990ZZ
TRANSMISSION 722.6 in MODELS 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODELS 129, 140
| Starter lock-out contact, location / task / design / function | GF27.19-P-5106G | ||
|---|---|---|---|
| Torque converter, location / task / design / function | GF27.20-P-5100G | ||
| Wheel speed sensor, location / task / function | GF27.19-P-5127G | ||
| Electric control module, location / task / design / function | GF27.19-P-5104G | ||
| D-4 shift isolating mechanism, location / task / design / function | GF27.60-P-5102G | ||
| Location / task / design / function of freewheel | GF27.51-P-5102G | ||
| Transmission range recognition switch, location / task / design / function | GF27.19-P-5101G | ||
| Transmission housing breathing, location/task | GF27.40-P-2007G | ||
| Kickdown switch, location / task / design / function | GF27.19-P-5105G | ||
| Location/task/function of command valve | GF27.60-P-5138G | ||
| Multiple-disc brake, location / task / design / function | GF27.51-P-5100G | ||
| Multi-plate clutch, location / task / design / function | GF27.51-P-5101G | ||
| Upshift / downshift solenoid valve, location / task / design / function | GF27.19-P-4006G | ||
| Floor shift, location / task / design / function | GF27.60-P-5100G | ||
| Location / task / design / function of oil pump | GF27.10-P-5103G | ||
| Parking lock, location / task / design / function | GF27.10-P-5100G | ||
| Planetary gear set, location / task / design / function | GF27.50-P-5100G | ||
| Position sensor, location/task/function | GF27.19-P-5129G | ||
| Location / task / design / function of PWM solenoid valve, torque converter lockup clutch | GF27.19-P-5112G | ||
| Modulating pressure regulating solenoid valve, location / task / design / function | GF27.19-P-5110G | ||
| Shift pressure regulating solenoid valve, location / task / design / function | GF27.19-P-5109G | ||
| Working pressure regulating valve, location/ task/function | GF27.60-P-5131G | ||
| Regulating valve pressure regulating valve, location / task / function | GF27.60-P-5133G | ||
| Shift pressure regulating valve, location / task / function | GF27.60-P-5132G | ||
| Shift valve pressure regulating valve, location/ task/function | GF27.60-P-5134G | ||
| Lubrication pressure regulating valve, location/ task/function | GF27.60-P-5122G | ||
| Overlap regulating valve, location / task / function | GF27.60-P-5137G | ||
| Torque converter lockup clutch regulating valve, location/task/function | GF27.60-P-5123G | ||
| Location / task / design / function of R/P lock | GF27.60-P-5103G | ||
| Reverse lamp switch, location / task / function | GF27.19-P-5132G | ||
| Shift detent mechanism, location / task / design / function | GF27.60-P-5101G | ||
| Holding pressure shift valve, location/task/ function | GF27.60-P-5135G | ||
| Shift pressure shift valve, location / task / function | GF27.60-P-5136G | ||
| Float, location/design / function | GF27.10-P-5107G | ||
| ETC control module, location/task | GF27.19-P-4012G | ||
| Temperature sensor, location / task / design / function | GF27.19-P-5108G | ||
| Selector valve, location/task | GF27.60-P-5139G | ||
| Torque converter lock-up clutch, location/task/ design/function | GF27.20-P-5101G | ||
| Automatic transmission (AT), contents, function description | GF27.10-P-0999ZZ |
Electronic transmission control (ETC) location of components - GF27.19-P-0001-01F
Model 210
Scheme 288
Upshift / downshift solenoid valve, location / task / design / function - GF27.19-P-4006G
TRANSMISSION 722.6
Scheme 289
| Upshift/downshift solenoid valve, location | In the shell of the electric control unit and pressed against the shift plate with a spring. | ||
|---|---|---|---|
| Upshift/downshift solenoid valve, task | The shift solenoid valves (Y3/6y3, Y3/6y4, Y3/6y5) introduce the sequence of upshifts and downshifts in the shift plate. | ||
| Upshift/downshift solenoid valve, design | GF27.19-P-4006-03G | ||
| Upshift/downshift solenoid valve, function | GF27.19-P-4006-04G |
ETC control module, location - GF27.19-P-4012-01G
TRANSMISSION 722.6 in MODEL 140, 210, 215, 220
Location
The ETC control module (N15/3) is installed in the control module housing in the right of the engine compartment.
Shows model 220
Scheme 290
ETC control unit, location/task - GF27.19-P-4012G
TRANSMISSION 722.6
Scheme 291
| ETC control unit, location | Model 129, 170, 202, 203, 208, 209, 211, 219, 240 | GF27.19-P-4012-01GG | |
|---|---|---|---|
| Model 163 | GF27.19-P-4012-01GH | ||
| Model 171.4 | GF27.19-P-4012-01SK | ||
| Model 140,210,215,220 | GF27.19-P-4012-01G | ||
| Model 230 | GF27.19-P-4012-01R | ||
| ETC control unit, task | Model 170, 202, 208, 210 without touch shift | GF27.19-P-4012-02G | |
| Model 129, 140 | |||
| Model 170, 202, 208, 210 with touch shift | GF27.19-P-4012-02GB | ||
| Model 163 without touch shift | GF27.19-P-4012-02GH | ||
| Model 163 with touch shift | GF27.19-P-4012-02GI | ||
| Model 171.4 except code (428) steering wheel shift buttons | GF27.19-P-4012-02SK | ||
| Model 171.4 with code (428) steering wheel shift buttons | GF27.19-P-4012-02SKB | ||
| Model 203 (except 203.076/276) except code (428) steering wheel shift buttons | GF27.19-P-4012-02P | ||
| Model 203 with code (428) steering wheel shift buttons | GF27.19-P-4012-02PM | ||
| Type 203.076/276 | |||
| Model 209 up to 31.05.04 | GF27.19-P-4012-02Q | ||
| Model 209 as of 01.06.04 | GF27.19-P-4012-02QX | ||
| Model 211 up to 31.05.04 | GF27.19-P-4012-02T | ||
| Model 211 as of 01.06.04 | GF27.19-P-4012-02TX | ||
| Model 219 | GF27.19-P-4012-02TY | ||
| Model 215, 220 | GF27.19-P-4012-02GA | ||
| Model 230 except code (428) steering wheel shift buttons | GF27.19-P-4012-02R | ||
| Model 230 with code (428) steering wheel shift buttons | GF27.19-P-4012-02RX | ||
| Model 240 | GF27.19-P-4012-02X |
Transmission range recognition switch, location / task / design / function - GF27.19-P-5101G
TRANSMISSION 722.6 in MODEL 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODEL 129, 140
Scheme 292
| Transmission range recognition switch, location | The gear identification switch (S16/10) is located in the floor selector. | ||
|---|---|---|---|
| Transmission range recognition switch, task | To convey the respective position of the selector lever and the program selector switch W/S (S16/10s2)to the ETC control module N15/3). | ||
| Transmission range recognition switch, design | The gear identification switch (S16/10) consists of the shift range contacts for all gears, the W/S program switch (S16/10s2), the reverse lamp switch (S16/10s1) as well as 10 LEDs (70) for the background illumination and the individual position display. | ||
| Transmission range recognition switch, function | The selector lever positions are transferred to the gear identification switch (S16/10) by a plug pin, which is connected to the shift shaft, and processed into a position signal. This signal is passed to the ETC control module (N15/3). |
Electric control module, location / task / design / function - GF27.19-P-5104G
TRANSMISSION 722.6
Scheme 293
| Electric control module, location | Bolted onto the valve housing of shift plate (2a). | ||
|---|---|---|---|
| Electric control module, design | To receive various input signals and to convert the control module information into hydraulic functions. | ||
| Electric control module, design | GF27.19-P-5104-01G | ||
| Electric control module, function | GF27.19-P-5104-02G |
Kickdown switch, location/task/design/function - GF27.19-P-5105G
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODEL 129, 140
Shown in model 202
Scheme 294
| Kickdown switch position | The kickdown switch (S16/6) is located in the footwell behind the accelerator pedal. | ||
|---|---|---|---|
| Kickdown switch task | Influencing the shift program of the electronic transmission control. | ||
| Kickdown switch design | The kickdown switch (S16/6) consists of a spring-tensioned electrical switch contact. | ||
| Kickdown switch function | When the kick-down switch (S16/6) is operated via the accelerator pedal a signal is passed on to the ETC control module (N15/3). Based on this information the ETC control module (N15/3) actuates the solenoid valves so that the upshifts and downshifts take place at higher engine speed. |
Starter lock-out contact, location/task/design/function - GF27.19-P-5106G
TRANSMISSION 722.6
Scheme 295
| Starter lockout contact, location | The starter lockout contact (Y3/6s1) is located in the electrical control unit (Y3/6) and is permanently connected to the conductor tracks. | ||
|---|---|---|---|
| Starter lockout contact, task | To recognize selector valve and selector lever position "P" and "N". | ||
| Starter lockout contact, design | The starter lockout contact (Y3/6s1) consists of: a plunger a permanent magnet a reed contact | ||
| Starter lockout contact, function | GF27.19-P-5106-01G |
Temperature sensor, location / task / design / function - GF27.19-P-5108G
TRANSMISSION 722.6
Scheme 296
| Temperature sensor, location | The transmission oil temperature sensor (Y3/6b1) is located in the electrical control unit (Y3/6) and is permanently connected to the conductor tracks. | ||
|---|---|---|---|
| Temperature sensor, task | To measure the temperature of the transmission oil and pass the temperature to the ETC control unit (N15/3) as an input signal. | ||
| Temperature sensor, design | Temperature-dependent resistor (PTC). | ||
| Temperature sensor, function | GF27.19-P-5108-04G |
Shift pressure regulating solenoid valve, location / task / design / function - GF27.19-P-5109G
TRANSMISSION 722.6
Scheme 297
| Shift pressure regulating solenoid valve, location | In the supporting body of the electrical control unit (Y3/6) and pressed against the valve housing of the shift plate (2a) by means of a leaf spring. | ||
|---|---|---|---|
| Shift pressure regulating solenoid valve, task | To control the shift pressure depending on the constantly changing operating conditions, such as load/gear changes. | ||
| Shift pressure regulating solenoid valve, design | GF27.19-P-5109-03G | ||
| Shift pressure regulating solenoid valve, function | The shift pressure regulating solenoid valve (Y3/6y2) assigns a proportional pressure to the current which is controlled by the ETC control module (N15/3) according to the load. |
Modulating pressure regulating solenoid valve, location / task / design / function - GF27.19-P-5110G
TRANSMISSION 722.6
Scheme 298
| Modulating pressure regulating solenoid valve, location | In the supporting body of the electrical control unit (Y3/6) and pressed against the valve housing of the shift plate (2a) by means of a leaf spring. | ||
|---|---|---|---|
| Modulating pressure regulating solenoid valve, task | To control the modulating pressure depending on the constantly changing operating conditions such as load/gear changes. | ||
| Modulating pressure regulating solenoid valve, design | GF27.19-P-5110-03G | ||
| Modulating pressure regulating solenoid valve, function | The modulating pressure regulating solenoid valve (Y3/6y1) assigns a proportional pressure to the current which is controlled by the ETC control module (N15/3) according to the load. |
Wheel speed sensor, location / task / function - GF27.19-P-5127G
TRANSMISSION 722.6
Scheme 299
| Wheelspeed sensor location | The RPM sensors 2 and 3 (Y3/6n2 and Y3/6n3) are permanently connected with the supporting body of the electrical control unit (Y3/6) via contact tongues. | ||
|---|---|---|---|
| Wheelspeed sensor - Function | The signals from the RPM sensors 2 3 (Y3/6n2, Y3/6n3) are recorded in the ETC control module (N15/3) together with the wheel and engine speeds and other information, and are the input signals for the electronic control system. | ||
| Speed sensor, function | GF27.19-P-5127-04G |
Position sensor, location/task/function - GF27.19-P-5129G
TRANSMISSION 722.6 in MODEL 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODELS 129, 140
Scheme 300
| Shift pattern display, location | The position indicator (72) is located in the floor shift. | ||
|---|---|---|---|
| Shift pattern display, task | To display visually the position of the selector lever and the program selection switch W/S (S16/10s2). | ||
| Shift pattern display, function | The position indicator (72) is actuated via the transmission range recognition switch (S16/10). |
Reverse lamp switch, location / task / function - GF27.19-P-5132G
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODEL 129, 140
Scheme 301
| Backup lamp switch, location | The reverse lamp switch (S16/10s1) is integrated in the transmission range recognition switch (S16/10). | ||
|---|---|---|---|
| Backup lamp switch, task | To switch on the backup lamp. | ||
| Backup lamp switch, function | When reverse gear is engaged the reversing lamp is actuated direct via the reverse lamp switch (S16/10s1). |
Electronic selector lever module control module, location/task/ design - GF27.19-P-5138GB
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 with touch shift
Shown in model 163
Scheme 302
| Electronic selector lever module control module, location | The electronic selector lever module control module (n15/5) is located in the center console of the vehicle | ||
|---|---|---|---|
| Electronic selector lever module control module, task | Model Series 163 | GF27.19-P-5138-02GI | |
| Models 170, 202, 208, 210 | GF27.19-P-5138-02GB | ||
| Electronic selector lever module control module, design | GF27.19-P-5138-03GB |
Position display, location/task - GF27.19-P-5139GB
TRANSMISSION 722.6 in MODEL 170, 202, 208, 210 with touch shift
Scheme 303
| Position display, location | The position display (selector scheme symbols (87)) is accommodated in the floor shift cover. In addition a gear display is located in the instrument cluster (A1). | ||
|---|---|---|---|
| Position display, task | Via the selector scheme symbols (87) the alternative selector lever positions and their sequence are shown symbolically as well as the program selection carried out at the driving program switch (S16/5) displayed visually. |
Kickdown switch, location / task / design - GF27.19-P-5141GA
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 with touch shift
TRANSMISSION 722.6 in MODEL 203, 215, 220, 230 up to 31.5.02
Shown in model 170
Scheme 304
| Kickdown switch position | The kickdown switch (S16/6) is located in the footwell, integrated into the electric accelerator pedal. | ||
|---|---|---|---|
| Kickdown switch task | Influencing the shift program of the electronic transmission control. | ||
| Kickdown switch design | The kickdown switch (S16/6) consists of a spring-tensioned electrical switch contact. |
Transmission housing breather, location/task - GF27.40-P-2007G
TRANSMISSION 722.6
Scheme 305
| Transmission housing breather, location | The inside of the transmission and the breather (72) are connected by a channel which is cast into the torque converter casing. | ||
|---|---|---|---|
| Transmission housing breather, task | The transmission housing vent compensates the pressure in the transmission housing if temperature-related volume changes in the transmission oil and air occur. |
Planetary gear set, location / task / design / function - GF27.50-P-5100G
TRANSMISSION 722.6
Scheme 306
| Planetary gear set, location | Three planetary gear sets are used to produce the different gear ratios. These are located in the mechanical part of the transmission as the front, center and rear planetary gear set (V, M, H) | ||
|---|---|---|---|
| Planetary gear set, task | Power transmission and production of different gear ratios. | ||
| Planetary gear set, design | A planetary gear set consists of the ring gear (1), the planet gears (2) carried in the planet carrier (4) and the sun gear (3). | ||
| Planetary gear set, function | GF27.50-P-5100-01G |
Multiple-disc brake, location / task / design / function - GF27.51-P-5100G
TRANSMISSION 722.6
Scheme 307
| Multiple-disc brake, location | Three multiple-disc brakes arranged as the front, center and rear multiple-disc brake (B1, B3, B2) are located in the planetary gear sets in the transmission housing. | ||
|---|---|---|---|
| Multiple-disc brake, task | Brace the ring gear, sun gear or planet carrier of a planetary gear set against the transmission housing in order to transmit the drive torque. | ||
| Multiple-disc brake, design | A multiple-disc brake consists of a number of internally toothed discs (10) on an internally toothed disc carrier and externally toothed discs (9) on an externally toothed disc carrier, which is rigidly connected to the transmission housing. | ||
| Multiple-disc brake, function | GF27.51-P-5100-04G |
Multi-plate clutch, location / task / design / function - GF27.51-P-5101G
TRANSMISSION 722.6
Scheme 308
| Multi-disk clutch, location | Three multi-plate clutches, the front, middle and rear multi-plate clutches K1, K2 and K3, are located in the planetary gear sets in the transmission housing. | ||
|---|---|---|---|
| Multi-disk clutch, task | Produces a non-positive locking connection between two elements of a planetary gear set or between one element from each of two planetary gear sets in order to transmit the drive torque. | ||
| Multiple-disc clutch, design | A multi-plate clutch consists of a number of internally toothed discs (10) on an internally toothed disc carrier and externally toothed discs (9) on an externally toothed disc carrier. | ||
| Multi-disk clutch, function | GF27.51-P-4000-01G |
Location / task / design / function of freewheel - GF27.51-P-5102G
TRANSMISSION 722.6
Scheme 309
| Freewheel, location | In the front planetary gear set a freewheel (F1, F2) is installed between the front sun gear (V1) and the stator shaft (8) and in the rear planetary gear set between the rear sun gear (H1) and the intermediate shaft (3). | ||
|---|---|---|---|
| Freewheel, task | Optimizes individual gearshifts. Support of the individual elements of a planetary gear set against each other or against the transmission housing in one direction of rotation in order to permit torque transmission. | ||
| Freewheel, design | The freewheels (F1, F2) consist of an outer race (12), an inner race (13), a number of clamping bodies (14) and a clamping body cage (15). | ||
| Freewheel, function | GF27.51-P-5102-04G |
Floor shift, location/task/design/function - GF27.60-P-5100G
TRANSMISSION 722.6 in MODELS 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODELS 129, 140
Shown in model 170
| Floor shift, location | The floor shift is located in the center console of the vehicle. | ||
|---|---|---|---|
| Floor shift, task | The floor shift is the central control for the driver to influence the shift program of the automatic transmission. | ||
| Floor shift, design | GF27.60-P-5100-03G | ||
| Floor shift, function | GF27.60-P-5100-04G |
Floor shift, location/task/design/function - GF27.60-P-5100GB
TRANSMISSION 722.6 in MODEL 170, 202, 208, 210 with touch shift
Shown in model 170
Scheme 310
| Floor shift, location | The floor shift is located in the center console of the vehicle. | ||
|---|---|---|---|
| Floor shift, task | The floor shift is the central control for the driver to influence the shift program of the automatic transmission. | ||
| Floor shift, design | GF27.60-P-5100-03GB | ||
| Floor shift, function | GF27.60-P-5100-04GB |
Shift detent mechanism, location/task/design/function - GF27.60-P-5101G
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODEL 129, 140
Scheme 311
| Shift detent, location | The shift detent is integrated into the floor shift. | ||
|---|---|---|---|
| Shift detent, task | Fixing the selector lever positions "4", "3", "2", "1". | ||
| Shift detent, design | The shift detent consists of a detent (67a) containing a spring-loaded ball and the shift gate (67b) with recesses arranged one under another. | ||
| Shift detent, function | When the selector lever is moved between the selector lever positions "4", "3", "2", "1" the shift detent (67a) locks in position in one of the four recesses in the shift gate (67b). |
Shift detent mechanism, location/task/design/function - GF27.60-P-5101GB
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 with touch shift
Scheme 312
| Shift detent, location | The shift detent (67) is integrated in the electronic selector lever module control module (N15/5). | ||
|---|---|---|---|
| Shift detent, task | Fixes selector lever position "D". | ||
| Shift detent, design | GF27.60-P-5101-03GB | ||
| Shift detent, function | GF27.60-P-5101-04GB |
D-4 shift isolating mechanism, location / task / design / function - GF27.60-P-5102G
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODELS 129, 140
Scheme 313
| Isolating mechanism for D-4 shift, function | The D-4 shift isolating mechanism is integrated into the floor shift. | ||
|---|---|---|---|
| Isolating mechanism for D-4 shift, task | Isolates the shift rod to the transmission from the floor shift. | ||
| Isolating mechanism for D-4 shift, design | The isolating mechanism for D-4 shift consists of: a recess in the intermediate lever (68a) The lock lever (68b) Two straight pins (68c, 68d) | ||
| Isolating mechanism for D-4 shift, function | GF27.60-P-5102-04G |
Location / task / design / function of R/P lock - GF27.60-P-5103G
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 without touch shift
TRANSMISSION 722.6 in MODELS 129, 140
Scheme 314
| R/P lock, location | The R/P lock is located in the floor shift. | ||
|---|---|---|---|
| R/P lock, task | Prevents unintentional shifts to the selector lever positions "R" and "P" at driving speeds in excess of approx. 10 km/h. | ||
| R/P lock, design | The R/P lock consists of: The cam (69b)which is rigidly connected to the shift shaft (66) The lever (69a) The reverse and parking lock solenoid (Y66/1) The support lever (69c) | ||
| R/P lock, function | GF27.60-P-5103-04G |
Location / task / design / function of R/P lock - GF27.60-P-5103GB
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 with touch shift
Scheme 315
| R/P lock, location | The R/P lock is integrated in the electronic selector lever module control module (N15/5). | ||
|---|---|---|---|
| R/P lock, task | Depending on the condition the R/P lock prevents shifting out of selector lever position "P" or changing into selector lever position "R" from "N". | ||
| R/P lock, design | The R/P lock consists of: the locking disc (69) rigidly connected to the selector lever (80) the locking lever (90) the R/P locking solenoid (89) | ||
| R/P lock, function | GF27.60-P-5103-04GB |
Working pressure regulating valve, location/task/function - GF27.60-P-5131G
TRANSMISSION 722.6
Scheme 316
| Working pressure regulating valve, location | 2In the valve housing of the shift plate. | ||
|---|---|---|---|
| Working pressure regulating valve, task | Regulates the primary pressure of the hydraulic system. | ||
| Working pressure regulating valve, function | GF27.60-P-5131-01G |
Shift pressure regulating valve, location / task / function - GF27.60-P-5132G
TRANSMISSION 722.6
Scheme 317
| Shift pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Shift pressure regulating valve, task | Control of shift pressure. | ||
| Shift pressure regulating valve, function | GF27.60-P-5132-04G |
Regulating valve pressure regulating valve, location / task / function - GF27.60-P-5133G
TRANSMISSION 722.6
Scheme 318
| Regulating valve pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Regulating valve pressure regulating valve, task | Controls the regulating valve pressure. | ||
| Regulating valve pressure regulating valve, function | GF27.60-P-5133-04G |
Shift valve pressure regulating valve, location/task/function - GF27.60-P-5134G
TRANSMISSION 722.6
Scheme 319
| Shift valve pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Shift valve pressure regulating valve, task | Control of shift valve pressure. | ||
| Shift valve pressure regulating valve, function | GF27.60-P-5134-04G |
Holding pressure shift valve, location/task/function - GF27.60-P-5135G
TRANSMISSION 722.6
Scheme 320
| Holding pressure shift valve, location | Each shift group is assigned a holding pressure shift valve (28a, 28b, 28c). The holding pressure shift valves 1-2/4-5 (28a) and 2-3 (28b) are installed in the valve housing (2b), the 3-4 holding pressure shift valve (28c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Holding pressure shift valve, task | Allocates the working pressure to one actuator of a shift group. | ||
| Holding pressure shift valve, function | GF27.60-P-5135-04G |
Shift pressure shift valve, location / task / function - GF27.60-P-5136G
TRANSMISSION 722.6
Scheme 321
| Shift pressure shift valve, location | Each shift group possesses one shift pressure shift valve. The 1-2/4-5 shift pressure shift valves (29a) and 2-3 shift pressure shift valve (29b) are installed in the valve housing of the shift plate (2b), the 3-4 shift pressure shift valve (29c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Shift pressure shift valve, task | To assign shift pressure to the engaging shift actuator and to assign the overlap pressure, controlled by the overlap regulating valve, to the disengaging shift actuator. | ||
| Shift pressure shift valve, function | GF27.60-P-5136-04G |
Overlap regulating valve, location / task / function - GF27.60-P-5137G
TRANSMISSION 722.6
Scheme 322
| Overlap regulating valve, location | Each shift group is assigned one overlap regulating valve. The 1-2/4-5 overlap regulating valve (30a) is installed in the valve housing of the shift plate (2b), the 2-3 overlap regulating valve (30b) and 4-5 (30c) are installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Overlap regulating valve, location | The overlap regulating valve regulates the pressure reduction during a shift phase. | ||
| Overlap regulating valve, function | GF27.60-P-5137-04G |
Location/task/function of command valve - GF27.60-P-5138G
TRANSMISSION 722.6
Scheme 323
| Command valve, location | Each shift group possesses one command valve. The 1-2/4-5 command valves (31a) and 2-3 (31b) are installed in the valve housing of the shift plate (2b), the 3-4 command valve (31c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Command valve, task | The command valves switch the shift groups from the stationary phase into the shift phase and back again | ||
| Command valve, function | GF27.60-P-5138-04G |
Selector valve, location/task - GF27.60-P-5139G
TRANSMISSION 722.6
Scheme 324
| Selector valve, location | The selector valve (52) is located in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Selector valve, task | Distributes pressure to the appropriate hydraulic components according to the selector lever position selected by the driver. |
