Engine Controls - Self-Diagnostics with Codes: Overview Mercedes-Benz E-class AMG W210/S210 facelift

Testing & Diagnostics 61 illustrations ~361 words

MODEL IDENTIFICATION

ModelChassis/Model NumberEngine Number
E430210.070113.940

MODEL IDENTIFICATION (1998)

ModelChassis/Model NumberEngine Number
C43202.033113.944
CLK430208.370113.943
E430210.070113.940
E55210.074113.980
ML430163.172113.942
SL500129.068113.961

MODEL IDENTIFICATION (1999)

ModelChassis/Model NumberEngine Number
C43202.033113.944
CLK430 (Coupe)208.370113.943
CLK430 (Cabriolet)208.470113.943
CL500215.375113.960
E430210.070113.940
E430 (4-Matic)210.083113.940
E55210.074113.980
ML430163.172113.942
ML55163.172113.980
S430220.170113.941
S500220.175113.960
SL500129.068113.961

MODEL IDENTIFICATION (2000)

ModelChassis/Model NumberEngine Number
CL500215.375113.960

MODEL IDENTIFICATION (2001-02)

COMPONENT/CIRCUIT IDENTIFICATION

System components and connections are identified by the manufacturer with special designations in diagnostic information. See COMPONENT/CIRCUIT IDENTIFICATION table.

Component/CircuitManufacturer's Designation
Air Pump Relay ModuleK40/4k3
Air Pump Switchover ValveY32
AIR Relay ModuleK17
Base ModuleN16/1
Drive Authorization System (DAS) Control ModuleN54/1
Camshaft (CMP) SensorB6/1
CAN BUS From ESP/SPS Control ModuleN47-5
Crankshaft Position (CKP) SensorL5
Cruise Control SwitchS40/4
Cylinder Shutoff Valve (Right Bank) (Model 215)Y80
Cylinder Shutoff Valve (Left Bank) (Model 215)Y81
EA/CC/ISC ActuatorM16/6
EGR Switchover ValveY27
EGR Valve Vacuum TransducerY31/1
Electronic Ignition Switch (EIS)N73
Engine Control Module (ECM)N3/10
Engine/Climate Control Electric Cooling FanM4/3
Engine/Climate Control Electric Cooling Fan Control ModuleN76
Engine Coolant Temperature (ECT) SensorB11/4
ECM Tachometer SignalTN Signal
EVAP Charcoal Canister Shut-Off ValveY58/4
Fuel Injector(1) Y62y1
Fuel Pump Relay ModuleK27
Fuel Tank Pressure SensorB4/3
Fuse/Relay BoxF1
Ignition Coil(2) T1/1
Ignition/Starter SwitchS2/1
Knock Sensor 1 (Right)A16g1
Knock Sensor 2 (Left)A16g2
Mass Airflow Sensor (MAF)B2/5
Oil SensorB40
Output Ground Circuit Right Component Compartment (Models 208 & 210)W16/6
Output Ground Circuit Component Compartment (Model 163)W16
Output Ground Control Module Box (Model 129)W27
O2S 1 Left (Before TWC)G3/3
O2S 1 Right (Before TWC)G3/4
O2S 2 Left (After TWC)G3/5
O2S 2 Right (After TWC)G3/6
Passenger Side Fuse/Relay Module Box (Models 208 & 210)K40/4
Pedal Value SensorB37
Pressure SensorB28
Purge Control ValveY58/1
Relay ModuleK40
Resonance Intake Manifold Switchover ValveY22/6
Starter Lock-Out Relay Module (Model 129)K38/1
Starter Relay Module (Model 163)F1k8
Stop Light SwitchS9/1
Transmission Control ModuleN15/3
Voltage Supply CircuitCircuit 30
(1) Last number identifies injector number. (2) Last number identifies coil number.
(1)Last number identifies injector number.
(2)Last number identifies coil number.

COMPONENT/CIRCUIT IDENTIFICATION

ECM CONNECTOR IDENTIFICATION

Note. When connecting test equipment, disconnect Engine Control Module (ECM) connector "D" first. When reconnecting connectors, connect connector "D" last.

Scheme 1

Scheme 1: ECM CONNECTOR IDENTIFICATION
Scheme 1: ECM CONNECTOR IDENTIFICATION

DIAGNOSTIC TROUBLE CODE IDENTIFICATION

Note. When connecting test equipment, disconnect Engine Control Module (ECM) connector "D" first. When reconnecting connectors, connect connector "D" last. See ECM CONNECTOR IDENTIFICATION .

Use DTC identification to identify possible cause, see DIAGNOSTIC TROUBLE CODE LIST . Proceed to indicated area under TEST STEP/REMEDY column. Before proceeding with diagnostic testing, see HOW TO READ DIAGNOSTIC INFORMATION . Some diagnostic information is identified by chassis/model number. See MODEL IDENTIFICATION . To further understand DTC diagnosis and/or diagnose intermittent failures, see DTC DESCRIPTION . If vehicle is experiencing a communication failure (no communication at all), perform FUEL INJECTION SYSTEM TESTS , IGNITION SYSTEM TESTS , ELECTRONIC ACCELERATOR TESTS , and CRUISE CONTROL TESTS entirely.

Note. DTC IDENTIFICATION FOR CYLINDER SHUTOFF only applies to CL500 equipped with optional cylinder shutoff. See CYLINDER SHUTOFF TESTS .

DTCDefinitionTest Step/Remedy
P0100MAF Circuit Malfunction4, Fuel Injection System Test (Steps 3.0-4.0)
P0105 Only USA vehicles with cylinder shutoffMAP Circuit Malfunction6, see Fuel Injection System Test (Step 6.0)
P0110IAT Circuit Malfunction5, see FUEL INJECTION SYSTEM TEST (STEPS 5.0 & 5.1)
P0115ECT Circuit Malfunction8, see FUEL INJECTION SYSTEM TEST (STEPS 8.0 & 8.1)
P0120Throttle Position Circuit Malfunction3, see ELECTRONIC ACCELERATOR TEST (STEPS 3.0 & 3.1)
P0130O2S-1 Circuit Malfunction11, see Fuel Injection System Test (Steps 11.0-12.0)
P0133O2S-1 Circuit Slow Response11, see Fuel Injection System Test (Steps 11.0-12.0)
P0135O2S-1 Heater Circuit Malfunction13, see FUEL INJECTION SYSTEM TEST (STEPS 13.0 & 14.0)
P0136 Only USAO2S-2 Circuit Malfunction15, see FUEL INJECTION SYSTEM TEST (STEPS 15.0 & 16.0)
P0140O2S-2 Heater Circuit Malfunction11, see Fuel Injection System Test (Steps 11.0-12.0)
P0141 Only USAO2S-2 Heater Circuit Malfunction17, see FUEL INJECTION SYSTEM TEST (STEPS 17.0 & 18.0)
P0150O2S-1 Circuit Malfunction10, see Fuel Injection System Test (Steps 8.2-10.0)
P0153O2S-1 Circuit Slow Response10, see Fuel Injection System Test (Steps 8.2-10.0)
P0155O2S-2 Circuit Malfunction12, see Fuel Injection System Test (Steps 11.0-12.0)
P0156 Only USAO2S-2 Circuit Malfunction14, see FUEL INJECTION SYSTEM TEST (STEPS 13.0 & 14.0)
P0160O2S Heater Circuit Malfunction10, see Fuel Injection System Test (Steps 8.2-10.0)
P0161 Only USAO2S-2 Heater Circuit Malfunction16, see FUEL INJECTION SYSTEM TEST (STEPS 15.0 & 16.0)
P0170Fuel Trim MalfunctionIntake air leak, injectors, diaphragm pressure regulator, engine wear
P0173Fuel Trim MalfunctionIntake air leak, injectors, diaphragm pressure regulator, engine wear
P0201Injector Circuit Malfunction Cyl. 118, see FUEL INJECTION SYSTEM TEST (STEPS 17.0 & 18.0)
P0202Injector Circuit Malfunction Cyl. 219, see Fuel Injection System Test (Step 19.0)
P0203Injector Circuit Malfunction Cyl. 320, see Fuel Injection System Test (Step 20.0)
P0204Injector Circuit Malfunction Cyl. 421, see Fuel Injection System Test (Step 21.0)
P0205Injector Circuit Malfunction Cyl. 522, see Fuel Injection System Test (Step 22.0)
P0206Injector Circuit Malfunction Cyl. 623, see Fuel Injection System Test (Step 23.0)
P0207Injector Circuit Malfunction Cyl. 724, see Fuel Injection System Test (Step 24.0)
P0208Injector Circuit Malfunction Cyl. 825, see Fuel Injection System Test (Step 25.0)
P0300Random Misfire Detected13-21, see Ignition System Test (Steps 13.0-14.0) - Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0301Cylinder 1 Misfire Detected13, see Ignition System Test (Steps 13.0-14.0) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0302Cylinder 2 Misfire Detected14, see Ignition System Test (Steps 13.0-14.0) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0303Cylinder 3 Misfire Detected15, see Ignition System Test (Steps 14.1-15.1) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0304Cylinder 4 Misfire Detected16, see Ignition System Test (Steps 16.0-17.0) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0305Cylinder 5 Misfire Detected17, see Ignition System Test (Steps 16.0-17.0) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0306Cylinder 6 Misfire Detected18, see Ignition System Test (Steps 17.1-18.1) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0307Cylinder 7 Misfire Detected19, see Ignition System Test (Steps 19.0-19.1) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0308Cylinder 8 Misfire Detected20, see Ignition System Test (Steps 20.0-20.1) ; 21, see Ignition System Test (Step 21.0) 1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2) Compression pressure
P0325Right KS 1 Circuit MalfunctionWiring, connector, A16g1
P0330Left KS 2 Circuit MalfunctionWiring, connector, A16g2
P0335CKP Sensor Circuit Malfunction11, see IGNITION SYSTEM TEST (STEPS 11.0 & 11.1)
P0341CMP Sensor Circuit Range/Performance12, see IGNITION SYSTEM TEST (STEPS 12.0 & 12.1)
P0370Angle Deviation Between Camshaft & CrankshaftCheck basic adjustment of camshaft
P0400Exhaust Gas Recirculation Flow Malfunction29, see Fuel Injection System Test (Step 29.0)
P0410 Only USAAir Injection System Malfunction26-28, see FUEL INJECTION SYSTEM TEST (STEPS 26.0 & 27.0) & Fuel Injection System Test (Step 28.0)
P0422TWC (Right) Efficiency Below ThresholdReplace Right TWC
P0432TWC (Left) Efficiency Below ThresholdReplace left TWC
P0440EVAP System Malfunction32 & 33, see FUEL INJECTION SYSTEM TEST (STEPS 32.0 & 33.0)
P0441EVAP System Malfunction (Leak) - Logic Chain31, see FUEL INJECTION SYSTEM TEST (STEPS 30.0 & 31.0) ; 32, see FUEL INJECTION SYSTEM TEST (STEPS 32.0 & 33.0)
P0442EVAP System Leak Detected (Small Leak)33, see FUEL INJECTION SYSTEM TEST (STEPS 32.0 & 33.0)
P0443EVAP System Purge Control Valve Circuit Malfunction31, see FUEL INJECTION SYSTEM TEST (STEPS 30.0 & 31.0)
P0446 Only USAEVAP System Vent Control MalfunctionA. Activated charcoal canister shut-off valve (Y58/4) 34 & 35, see Fuel Injection System Test (Steps 34.0-35.1) B. End stage activated charcoal canister shut-off valve (Y58/4) within N3/10 N3/10
P0450 Only USAEVAP System Leak Detected (Large Leak)A. Fuel tank pressure sensor (B4/3) electrical fault 35, see Fuel Injection System Test (Steps 34.0-35.1) B. Fuel tank pressure sensor (B4/3) electrical fluctuations Charcoal canister plugged
P0455 Only USAEVAP System Leak Detected (Large Leak)EVAP system, large leak 33, see FUEL INJECTION SYSTEM TEST (STEPS 32.0 & 33.0) Fuel tank pressure sensor (B4/3) (voltage supply) 35, see Fuel Injection System Test (Steps 34.0-35.1)
P0460Fuel Level Sensor Circuit Low InputFill fuel tank
P0500VSS Sensor MalfunctionTest ASR/ESP. See TRACTION CONTROL in BRAKES
P0507ISC RPM Higher Than Expected1-3, see Electronic Accelerator Test (Steps 1.0-2.0) & ELECTRONIC ACCELERATOR TEST (STEPS 3.0 & 3.1)
P0560System Voltage Malfunction1 & 2, see Fuel Injection System Test (Steps 1.0-1.2) & Fuel Injection System Test (Steps 2.0-2.2)
P0565Cruise Control Switch1, see CRUISE CONTROL TESTS
P0600Serial Communication Link Malfunction36, see Fuel Injection System Test (Steps 36.0-36.2)
P0604Internal Control Module Random Access Memory (RAM) ErrorN3/10
P0605Internal Control Module Read Only Memory (ROM) ErrorN3/10
P0700Transmission Control System Malfunction, Gear Unplausi, Transmission Leak, Command Sleeve Stuck In Pressure Pos.See appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0702Transmission Control System Electrical, Voltage Supply To Solenoid ValvesSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0715Input/Turbine Speed Sensor Circuit Malfunction, RPM Sensor Voltage Supply & FunctionSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0720Output Speed Sensor Circuit Malfunction, CAN Fault RecognitionSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0730Incorrect Gear Ratio, Ratio Comparison Negative (Numerous)See appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0740Torque Converter Clutch Circuit MalfunctionSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0743Torque Converter Clutch Circuit ElectricalSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0748Pressure Control Solenoid Electrical, Pressure Control Valve Modulation Press., Pressure Control Valve Shift PressureSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0753Shift Solenoid A Electrical, 1-2/4-5 Solenoid Shift ValveSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0758Shift Solenoid B Electrical, 2-3 Solenoid Shift ValveSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0763Shift Solenoid C ElectricalSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P0801Engine/Climate Control Electric Cooling Fan Malfunction38, see Fuel Injection System Test (Steps 38.0-40.0)
P0802Resonance Intake Manifold Switchover Valve Malfunction30, see FUEL INJECTION SYSTEM TEST (STEPS 30.0 & 31.0)
P0809Angle Deviation Between Camshaft & CrankshaftCheck basic adjustment of camshaft
P0811CAN From Electronic Ignition Lock36, see Fuel Injection System Test (Steps 36.0-36.2)
P1031O2 Sensor (G3/3, G3/4) ReversedCheck proper connection of O2 sensors in ETM
P1177Oil Sensor (level, temperature, quality) (B40) Oil temperature implausible37, see FUEL INJECTION SYSTEM TEST (STEPS 37.0 & 31.1)
P1178Oil Sensor (level, temperature, quality) (B40) Oil level implausible37, see FUEL INJECTION SYSTEM TEST (STEPS 37.0 & 31.1)
P1179Oil Sensor (level, temperature, quality) (B40) Oil quality implausible37, see FUEL INJECTION SYSTEM TEST (STEPS 37.0 & 31.1)
P1180Oil Sensor (level, temperature, quality) (B40) Oil temperature too high37, see FUEL INJECTION SYSTEM TEST (STEPS 37.0 & 31.1)
P1181Engine/Climate Control Electric Cooling Fan38, see Fuel Injection System Test (Steps 38.0-40.0)
P1185Oil Sensor (level, temperature, quality) (B40) water in oil37, see FUEL INJECTION SYSTEM TEST (STEPS 37.0 & 31.1)
P1186Fuel Safety Shut Off Recognized3 & 4, see ELECTRONIC ACCELERATOR TEST (STEPS 3.0 & 3.1) & ELECTRONIC ACCELERATOR TEST (STEPS 4.0 & 5.0)
P1225Resonance Intake Manifold Switchover Valve Malfunction30, see FUEL INJECTION SYSTEM TEST (STEPS 30.0 & 31.0)
P1233EA/CC/ISC Actuator (M16/6) Icing ProblemActuator
P1386Knock Sensor Control From ECM (N3/10) At End StopIncreased knock tendency due to bad fuel, carbon in combustion chamber or mechanical damage
P1400EGR Valve Vacuum Transducer29, see Fuel Injection System Test (Step 29.0)
P1420 Only USAAIR Pump Switchover Valve27, see FUEL INJECTION SYSTEM TEST (STEPS 26.0 & 27.0)
P1453 Only USAAIR Relay Module, AIR Pump26, see FUEL INJECTION SYSTEM TEST (STEPS 26.0 & 27.0)
P1491Refrigerant pressure in A/C system too highCheck automatic A/C system
P1542Pedal Value Sensor1 & 2, see Electronic Accelerator Test (Steps 1.0-2.0)
P1570CAN Signal From DAS Control Module To Engine Control ModuleA. Start attempted with "locked" DAS User Error B. CAN signal from DAS control module (N54/1) to engine control module (N3/10) interrupted Check operation of DAS C. Engine control module (ME-SFI) and DAS control module are not compatible Step 36, see Fuel Injection System Test (Steps 36.0-36.2) , check control modules and part no.
P1580EA/CC/ISC Actuator (M16/1)3 & 4, see ELECTRONIC ACCELERATOR TEST (STEPS 3.0 & 3.1) & ELECTRONIC ACCELERATOR TEST (STEPS 4.0 & 5.0)
P1584Stop Lamp SwitchTest ETS/ASR. See TRACTION CONTROL in BRAKES
P1603CAN From EIS36, see Fuel Injection System Test (Steps 36.0-36.2)
P1605Test ETS/ASR. See TRACTION CONTROL in BRAKES
P1642Engine Control ModuleCheck engine control module for correct version code
P1644Transmission version cannot be checked due to low voltage of transmission control module (N15/3)See appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES
P1681Crash Signal Unplausible40, see Fuel Injection System Test (Steps 38.0-40.0)
P1747CAN Signal From ETCA. CAN failure: Transmission protection malfunction from transmission control module (N15/3) See appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES B. CAN failure: Instrument cluster Test instrument cluster (A1)
P0520Cylinder Shutoff Oil Pressure Sensor Fault Code DescriptionSee DTC P0520 Test
P1183Cylinder Shutoff Valve For Right Bank Of Cylinders (Y80), Fault Code DescriptionSee DTC P1183 & P1184 Test
P1184Cylinder Shutoff Valve For Left Bank Of Cylinders (Y81), Fault Code DescriptionSee DTC P1183 & P1184 Test
P1355Cylinder Shutoff Valve For Right Bank Of Cylinders (Y80), Fault Code DescriptionSee DTC P1355 & P1356 Test
P1356Cylinder Shutoff Valve For Left Bank Of Cylinders (Y81), Fault Code DescriptionSee DTC P1355 & P1356 Test
P1357Cylinder Shutoff ON: No. 2, 3, 5 Or 8 Cylinder Inlet Valve Still Being Activated, Fault Code DescriptionSee DTC P1357, P1358, P1359, P1360 & P1361 Test
P1358Cylinder Shutoff OFF: No. 5 Cylinder Outlet Valve Not Being Activated, Fault Code DescriptionSee DTC P1357, P1358, P1359, P1360 & P1361 Test
P1359Cylinder Shutoff OFF: No. 2 Cylinder Outlet Valve Not Being Activated, Fault Code DescriptionSee DTC P1357, P1358, P1359, P1360 & P1361 Test
P1360Cylinder Shutoff OFF: No. 3 Cylinder Outlet Valve Not Being Activated, Fault Code DescriptionSee DTC P1357, P1358, P1359, P1360 & P1361 Test
P1361Cylinder Shutoff OFF: No. 8 Cylinder Outlet Valve Not Being Activated, Fault Code DescriptionSee DTC P1357, P1358, P1359, P1360 & P1361 Test
P1366Exhaust Valve Changeover Valve, Fault Code DescriptionSee DTC P1366 Test
P1380A Cylinder Inlet Valve Is Not Being Activated With Cylinder Shutoff OFF, Fault Code DescriptionSee DTC P1380 Test
P1666Cylinder Shutoff Valve Opens With Cylinder Shutoff ON, Fault Code DescriptionSee DTC P1666 Test

DIAGNOSTIC TROUBLE CODE LIST

DTC DESCRIPTION

Note. Use this information to further understand DTC diagnosis and/or diagnose intermittent failures.

Scheme 2

Scheme 2: DTC DESCRIPTION
Scheme 2: DTC DESCRIPTION

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

SIGNAL PATTERN IDENTIFICATION

Note. The following graphics identify normal signal patterns. (Scheme 56)- see scheme 126

Scheme 55

Scheme 55: SIGNAL PATTERN IDENTIFICATION
Scheme 55: SIGNAL PATTERN IDENTIFICATION

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

More articles — Engine Controls - Self-Diagnostics with Codes
