Computer data lines — Data link connector circuit Mercedes-Benz CLA-class C117/X117 facelift
All systems — 35 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines 2
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering 2
- Electronic suspension
- Engine accessories
- Engine performance 2.0l turbo
- Engine performance 2.0l turbo flex
- Exterior lights 3
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster 3
- Interior lights 2
- Memory systems 3
- Navigation 9
- Power distribution
- Power door locks 2
- Power mirrors
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 6
- Shift interlock
- Starting/charging 2
- Supplemental restraints 2
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 11
Click a component to highlight it on every diagram it appears on.
