Shift point retard, location/task/design/function - GF27.00-P-7000A
TRANSMISSION 722 with ENGINE 104, 111 with CODE (620a) Vehicles with catalytic converters
Task
Scheme 17
- To heat up the catalytic converter to its operating temperature more quickly after the engine is started. (Scheme 17): Catalytic Converter - Shift Point Retard Function Diagram
Function
The engine control module HFM (N3/4) positively actuates the upshift delay switchover valve (Y3/3) for a maximum of 80 seconds so that the catalytic vikas vir converter reaches its operating temperature more quickly once the engine has been turned on if
- the coolant temperature when the engine is started is < 50°C
- the speed is > 10 km/h and < 45 km/h
This creates a vacuum for the shift point retard vacuum element (8) via the control pressure cable and the pressure control cable is lifted up. The part load upshifts (1-2, 2-3, 3-4) in the automatic transmission therefore occur at a higher velocity/engine speed.
Automatic transmission overload protection, location/task/ function - GF27.00-P-7002A
TRANSMISSION 722 with ENGINE 104, 111
Task
To protect the shift elements of the automatic transmission against thermal overload during load shifts.
During load shifts (1-2-1, 2-3-2) the ignition angle is briefly adjusted towards "retarded" and thus the engine torque reduced when
- the engine speed > 4000 rpm
- The air mass and throttle valve angle exceed set values
- Signal from transmission overload protection switch (S65) (load shifts 1-2-1, 2-3-2).
The transmission overload protection switch (S65) is a hydraulic pressure switch, connected in parallel with the brake band B1 and which closes at a pressure >1.8 bar.
Identifying Transmission Overload Protection Switch (S65). Scheme 18
| PEC control module, location/design/function | GF07.52-P-3000A |
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04NP
Transmission 722.9 in model 203 except code (428) steering wheel shift buttons
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04NPL
Transmission 722.9 in model 203 with code (428) steering wheel shift buttons
Automatic transmission (AT) location of components, floor shift - GF27.10-P-0001-04P
Transmission 722.6 in models 203, 209.3 up to 31.05.03, 211 up to 31.08.03
Shown on Model 203
Floor Shift Components - Shown On Model 203. Scheme 21
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04PZ
Transmission 722.6 in models 203, 209.3 as of 01.06.03, 209.4, 211 as of 01.09.03, 219.376
Shown on model 203.061
Floor Shift Components - Shown On Model 203.061. Scheme 22
Automatic transmission (AT), location of mechanical parts - GF27.10-P-0001-07G
Transmission 722.6
Kick-Down Function Diagram - Transmission 722.6 In Model 203 As Of 1.6.02. Scheme 23
Automatic transmission (AT), location of mechanical parts - GF27.10-P-0001-07N
Transmission 722.9 in model 171.4, 203, 209, 211, 215, 219, 220, 230, 463.303/340/341
Identifying Ignition Lock Interlock - Shown On Floor Shift In Models 215, 220. Scheme 24
Automatic transmission (AT), location of electric/electronic components - GF27.10-P-0001-08G
Transmission 722.6
Identifying Automatic Transmission Electric/Electronic Components Location (Transmission 722.6). Scheme 25
Automatic transmission (AT), location of electric/electronic components - GF27.10-P-0001-08N
Transmission 722.9 in model 171.4, 203, 209, 211, 215, 219, 220, 230, 463.303/340/341
Identifying Ignition Switch Lock Function Diagram - Selector Lever Position "D", "R", "N". Scheme 26
Automatic transmission (AT), location of hydraulic components - GF27.10-P-0001-09N
Transmission 722.9 in model 171.4, 203, 209, 211, 215, 219, 220, 230, 463.303/340/341
Valve housing
Identifying Valve Housing Hydraulic Components (Transmission 722.9). Scheme 27
Valve body
Power Flow In 1st Gear Function Diagram - Transmission 722.9. Scheme 28
Park pawl, location/task/design/function - GF27.10-P-5100GA
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 With Touchcontrol
TRANSMISSION 722.6 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230, 240
| Park pawl, location | The park pawl gear (4) and park pawl mechanism (4a) are located in the rear part of the transmission housing. | ||
|---|---|---|---|
| Park pawl, task | Secures the vehicle mechanically to prevent it from rolling in addition to the parking brake. | ||
| Park pawl, design | GF27.10-P-5100-03GA | ||
| Park pawl, function | GF27.10-P-5100-02GA |
Parking lock, location / task / design / function - GF27.10-P-5100N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Parking Pawl Gear And Park Pawl Mechanism - Transmission 722.9. Scheme 29
| Park pawl, location | The park pawl gear (4) and park pawl mechanism (4a) are located in the rear area of the transmission housing. | ||
|---|---|---|---|
| Park pawl, task | Secures the vehicle mechanically to prevent it from rolling in addition to the parking brake. | ||
| Park pawl, design | GF27.10-P-5100-03N | ||
| Park pawl, function | GF27.10-P-5100-02N |
Location / task / design / function of oil pump - GF27.10-P-5103G
TRANSMISSION 722.6
Identifying Oil Pump Location - Transmission 722.6. Scheme 30
| Oil pump, location | The oil pump (crescent-type pump) (6) is installed in the torque converter housing behind the torque converter and is driven by the drive flange of the torque converter. | ||
|---|---|---|---|
| Oil pump, task | To produce the necessary oil pressure for the hydraulic sequences. | ||
| Oil pump, design | An external gear (6a) which is mounted eccentrically in the pump housing in located on the internal gear (6b) which is connected to the drive flange (6b). The crescent (6c) drives the external gear (6a). | ||
| Oil pump, function | When the engine is running oil is delivered through the suction gallery (6e) along the top and bottom side of the crescent (6c) to the pressure chamber (6d) of the housing. The meshing of the teeth prevents oil from flowing from the pressure side to the suction side. |
Location / task / design / function of oil pump - GF27.10-P-5103N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Oil Pump Location - Transmission 722.9. Scheme 31
| Oil pump, location | The oil pump (crescent-type pump) (6) is installed in the torque converter housing behind the torque converter and is driven by the drive flange of the torque converter. | ||
|---|---|---|---|
| Oil pump, task | To produce the oil pressure required for the hydraulic sequences | ||
| Oil pump, design | An external gear (6a) which is mounted eccentrically in the pump housing in located on the internal gear (6b) which is connected to the drive flange (6b). The crescent (6c) drives the external gear (6a). | ||
| Oil pump, function | When the engine is running oil is delivered through the suction gallery (6e) along the top and bottom side of the crescent (6c) to the pressure chamber (6d) of the housing. The meshing of the teeth prevents oil from flowing from the pressure side to the suction side. |
Float, location/function - GF27.10-P-5107G
TRANSMISSION 722.6
Identifying Float And Electrical Control Unit (Y3/6) - Transmission 722.6. Scheme 32
| Float, location | In the electrical control unit (Y3/6). | ||
|---|---|---|---|
| Float, function | GF27.10-P-5107-04G |
Float, location/function - GF27.10-P-5107N
TRANSMISSION 722.9 in MODEL 171.4
TRANSMISSION 722.9 in MODEL 463.30
Identifying Float 1, Float 2 And Electrical Control Unit Location - Transmission 722.9. Scheme 33
| Float, location | Float 1 (31) and float 2 (32) are accommodated in the electric control unit (VGS) (Y3/8). | ||
|---|---|---|---|
| Float, function | As the oil level rises, float 1 (31) and float 2 (32) seal the openings between the oil chamber and the gear set chamber. |
Kickdown simulator, location/task - GF27.10-P-5108N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Illustrated on model 230
Identifying Kickdown Simulator (Transmission 722.9) - Illustrated On Model 230. Scheme 34
| Kick-down simulator, location | The kick-down simulator (100) is located in the footwell, installed in the electronic accelerator. | ||
|---|---|---|---|
| Kick-down simulator, task | The kick-down simulator (100) enables the driver to detect the use of the kick-down function with his foot. |
Kick-down simulator, location/task - GF27.10-P-5108T
TRANSMISSION 722.6 in model 203 as of 1.6.02, 209, 211, 215 as of 1.6.02, 219, 220, 230 as of 1.6.02, 240
Illustrated on Model 230
Identifying Kickdown Simulator (Transmission 722.6) - Illustrated On Model 230. Scheme 35
| Kick-down simulator, location | The kick-down simulator (100) is located in the footwell, installed in the electronic accelerator. | ||
|---|---|---|---|
| Kick-down simulator, task | The kick-down simulator (100) enables the driver to detect with his foot that kick-down function is used. |
Upshift / downshift solenoid valve, location / task / design /function - GF27.19-P-4006G
TRANSMISSION 722.6
Identifying Shift Solenoid Valve Location - Transmission 722.6. Scheme 36
| Upshift/downshift solenoid valve, location | In the shell of the electric control unit and pressed against the shift plate with a spring. | ||
|---|---|---|---|
| Upshift/downshift solenoid valve, task | The shift solenoid valves (Y3/6y3, Y3/6y4, Y3/6y5) introduce the sequence of upshifts and downshifts in the shift plate. | ||
| Upshift/downshift solenoid valve, design | GF27.19-P-4006-03G | ||
| Upshift/downshift solenoid valve, function | GF27.19-P-4006-04G |
ETC control unit, location - GF27.19-P-4012-01GG
Transmission 722.6 in models 129, 170, 202, 203, 208, 209, 211, 219, 240
Shown on MODEL 170
Location
The ETC control unit (N15/3) is installed under the tread plate in the front passenger footwell.
ETC Control Unit - Shown On Model 170. Scheme 37
ETC control unit, location/task - GF27.19-P-4012G
TRANSMISSION 722.6
Identifying ETC Control Unit - Transmission 722.6. Scheme 38
| ETC control unit, location | Model 129, 170, 202, 203, 208, 209, 211, 219, 240 | GF27.19-P-4012-01GG | |
|---|---|---|---|
| Model 163 | GF27.19-P-4012-01GH | ||
| Model 171.4 | GF27.19-P-4012-01SK | ||
| Model 140, 210, 215, 220 | GF27.19-P-4012-01G | ||
| Model 230 | GF27.19-P-4012-01R | ||
| ETC control unit, task | Model 170, 202, 208, 210 without touch shift Model 129, 140 | GF27.19-P-4012-02G | |
| Model 170, 202, 208, 210 with touch shift | GF27.19-P-4012-02GB | ||
| Model 163 without touch shift | GF27.19-P-4012-02GH | ||
| Model 163 with touch shift | GF27.19-P-4012-02GI | ||
| Model 171.4 except code (428) steering wheel shift buttons | GF27.19-P-4012-02SK | ||
| Model 171.4 with code (428) steering wheel shift buttons | GF27.19-P-4012-02SKB | ||
| Model 203 (except 203.076/276) except code (428) steering wheel shift buttons | GF27.19-P-4012-02P | ||
| Model 203 with code (428) steering wheel shift buttons Type 203.076/276 | GF27.19-P-4012-02PM | ||
| Model 209 up to 31.05.04 | GF27.19-P-4012-02Q | ||
| Model 209 as of 01.06.04 | GF27.19-P-4012-02QX | ||
| Model 211 up to 31.05.04 | GF27.19-P-4012-02T | ||
| Model 211 as of 01.06.04 | GF27.19-P-4012-02TX | ||
| Model 219 | GF27.19-P-4012-02TY | ||
| Model 215, 220 | GF27.19-P-4012-02GA | ||
| Model 230 except code (428) steering wheel shift buttons | GF27.19-P-4012-02R | ||
| Model 230 with code (428) steering wheel shift buttons | GF27.19-P-4012-02RX | ||
| Model 240 | GF27.19-P-4012-02X |
VGS control unit, location/task - GF27.19-P-4013N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying VGS Control Unit Location - Transmission 722.9. Scheme 39
| VGS control unit, location | The fully integrated transmission control (VGS) control unit (Y3/8n4) is integrated into the electric controller unit (VGS) (Y3/8). | ||
|---|---|---|---|
| VGS [fully integrated transmission control], task | Model 171.4 (except model 171.473/44) except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NK | |
| Model 171.4 with code (428) Steering wheel shift buttons Model 171.473 | GF27.19-P-4013-02NKL | ||
| Model 203 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NP | ||
| Model 203 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NPL | ||
| Model 209 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NQ | ||
| Model 209 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NQL | ||
| Model 211, except code (428) Steering wheel shift buttons 463.303/340/341 | GF27.19-P-4013-02NT | ||
| Model 211 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NTL | ||
| Model 219 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02TX | ||
| Model 219 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02TXL | ||
| Model 215, 220 | GF27.19-P-4013-02N | ||
| Model 230 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NR | ||
| Model 230 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NRL |
Transmission oil temperature sensor, location/task/design - GF27.19-P-4014N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Transmission Oil Temperature Sensor Location - Transmission 722.9. Scheme 40
| Transmission oil temperature sensor, location | The transmission oil temperature sensor (VGS) (Y3/8s2) is integrated in the fully integrated transmission control (VGS) control unit (Y3/8n4). | ||
|---|---|---|---|
| Transmission oil temperature sensor, task | The transmission oil temperature sensor (VGS) (Y3/8s2) detects the transmission oil temperature and passes this on as an input parameter to the fully integrated transmission control (VGS) control unit (Y3/8n4). | ||
| Transmission oil temperature sensor, design | Temperature-dependent resistor |
AT control module, location / task / design / function - GF27.19-P-5103GF
TRANSMISSION 722.7
AT Control Module Function Diagram - Input And Output Signals. Scheme 41
CAN data bus
AT Control Module Function Diagram - CAN Data Bus. Scheme 42
Location
The front-wheel-drive transmission control (FTC) control module (Y3/7n2) is integrated into the electric FTC control module (Y3/7).
Task
The front-wheel-drive transmission control (FTC) control module (Y3/7n2) determines the instantaneous operating condition of the vehicle and controls all gearshift sequences taking into account the ease of shifting and the driving situation.
It receives operating data in the form of input signals from
- Transmission output shaft rpm sensor (Y3/7n1)
- Starter lockout contact (Y3/7s1)
- Transmission fluid temperature sensor (integrated into the front- wheel-drive transmission control (FTC) control module (Y3/7n2))
It is also linked over the engine compartment bus with
- Instrument cluster (A1)
- Transmission range recognition module (A61)
- ECM control module (N3/5)
- Traction systems control module (N47)
- Air conditioning push-button control module (N19)
The PWM solenoid valves 14 (Y3/7y1), 3 (Y3/7y2) 25R (Y3/7y3) and the torque converter lockup clutch (Y3/7y4) and the shift pressure solenoid valve (Y3/7y5) are actuated by the front-wheel-drive transmission control (FTC) control module (Y3/7n2).
Any faults detected can be called up and reset via the data link connector (X11/4).
Function
The necessary pressure in relation to the torque to be transmitted, is computed from all the input signals. This involves the processing of the following data from other systems
ECM control module (N3/5)
- Engine torque
- Engine speed
- Accelerator pedal position
- Shift offset
- Engine status
Transmission range recognition module (A61)
- Kickdown switch (S16/6)
- Selector lever position
- W/S program switch
Traction systems control module (N47)
- Wheel speeds
- Shift offset
- Traction status
Air conditioning push-button control module (N19)
- A/C compressor torque
The following information is output over CAN-C
Instrument cluster (A1)
- Detected faults
Traction systems control module (N47)
- Transmission ratio
- Wheel speeds
ECM control module (N3/5)
- Kickdown switch (S16/6)
- Engaged drive mode
- Selector lever position "P"/"N"
| Starter lockout contact, location / task / design / function | GF27.19-P-5106GF | ||
|---|---|---|---|
| Torque converter lockup clutch PWM solenoid valve, location / task / design / function | GF27.19-P-5112GF | ||
| Shift valve, location / task / design / function | GF27.19-P-5113GF | ||
| Transmission range recognition module, location / task / design / function | GF27.19-P-5114GF | ||
| Wheel speed sensor, location / task / function | GF27.19-P-5127GF | ||
| Shift PWM solenoid valve, location / task / design / function | GF27.19-P-5116GF |
Electric control module, location / task / design / function - GF27.19-P-5104G
TRANSMISSION 722.6
Identifying Valve Housing Of Shift Plate And Electric Control Unit - Transmission 722.6. Scheme 43
| Electric control module, location | Bolted onto the valve housing of shift plate (2a). | ||
|---|---|---|---|
| Electric control module, design | To receive various input signals and to convert the control module information into hydraulic functions. | ||
| Electric control module, design | GF27.19-P-5104-01G | ||
| Electric control module, function | GF27.19-P-5104-02G |
Electric control unit, location/task/design/function - GF27.19-P-5104N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Locations
Identifying Electric Control Unit Location - Transmission 722.9. Scheme 44
| Electric control unit, location | The electric control unit (VGS) (Y3/8), valve body (21b), intermediate panel (21c) and valve body (21d) are connected to each other by bolts and are mounted under the transmission housing. | ||
|---|---|---|---|
| Electric control unit, design | Recording various input signals and converting control unit information into hydraulic functions | ||
| Electric control unit, design | GF27.19-P-5104-01N | ||
| Electric control unit, function | GF27.19-P-5104-02N |
Starter lock-out contact, location/task/design/function - GF27.19-P-5106G
TRANSMISSION 722.6
Identifying Starter Lock-Out Contact Location - Transmission 722.6. Scheme 45
| Starter lockout contact, location | The starter lockout contact (Y3/6s1) is located in the electrical control unit (Y3/6) and is permanently connected to the conductor tracks. | ||
|---|---|---|---|
| Starter lockout contact, task | To recognize selector valve and selector lever position "P" and "N". | ||
| Starter lockout contact, design | The starter lockout contact (Y3/6s1) consists of: a plunger a permanent magnet a reed contact | ||
| Starter lockout contact, function | GF27.19-P-5106-01G |
Starter lockout contact, location / task / design / function - GF27.19-P-5106GF
TRANSMISSION 722.7
Starter Lockout Contact Function Diagram - Transmission 722.7. Scheme 46
Location
The starter lockout contact (Y3/7s1) is located in the substrate of the electric FTC control module (Y3/7) and is permanently connected to the conductor tracks.
Task
Identifies the selector valve and selector lever positions "P" and "N".
Design
The starter lockout contact consists of
- The spring-loaded slide valve (83a)
- The contact (83c)
Function
The rotary movement of the selector valve during a gearchange causes the cam track (51a) on the selector valve to turn.
In selector valve positions "D" and "R" the spring-loaded slide valve (83a) is moved by the cams against the force of the spring (83b), thus opening the contacts (83c) in the starter lockout contact (Y3/7s1). The engine can no longer be started in drive modes "D" and "R".
Remark
The engine can only be started in selector lever positions "P" and "N" if these positions are recognized in the transmission range recognition module (A61).
| Automatic transmission (AT), location of electrical / electronic components | GF27.10-P-0001-08GF | ||
|---|---|---|---|
| Transmission range recognition module, location / task / design / function | GF27.19-P-5114GF |
Temperature sensor, location / task / design / function - GF27.19-P-5108G
TRANSMISSION 722.6
Identifying Transmission Oil Temperature Sensor Location - Transmission 722.6. Scheme 47
| Temperature sensor, location | The transmission oil temperature sensor (Y3/6b1) is located in the electrical control unit (Y3/6) and is permanently connected to the conductor tracks. | ||
|---|---|---|---|
| Temperature sensor, task | To measure the temperature of the transmission oil and pass the temperature to the ETC control unit (N15/3) as an input signal. | ||
| Temperature sensor, design | Temperature-dependent resistor (PTC). | ||
| Temperature sensor, function | GF27.19-P-5108-04G |
Shift pressure regulating solenoid valve, location / task / design / function - GF27.19-P-5109G
TRANSMISSION 722.6
Identifying Shift Pressure Control Solenoid Valve - Transmission 722.6. Scheme 48
| Shift pressure regulating solenoid valve, location | In the supporting body of the electrical control unit (Y3/6) and pressed against the valve housing of the shift plate (2a) by means of a leaf spring. | ||
|---|---|---|---|
| Shift pressure regulating solenoid valve, task | To control the shift pressure depending on the constantly changing operating conditions, such as load/gear changes. | ||
| Shift pressure regulating solenoid valve, design | GF27.19-P-5109-03G | ||
| Shift pressure regulating solenoid valve, function | The shift pressure regulating solenoid valve (Y3/6y2) assigns a proportional pressure to the current which is controlled by the ETC control module (N15/3) according to the load. |
Modulating pressure regulating solenoid valve, location / task / design / function - GF27.19-P-5110G
TRANSMISSION 722.6
Identifying Modulating Pressure Control Solenoid Valve Location - Transmission 722.6. Scheme 49
| Modulating pressure regulating solenoid valve, location | In the supporting body of the electrical control unit (Y3/6) and pressed against the valve housing of the shift plate (2a) by means of a leaf spring. | ||
|---|---|---|---|
| Modulating pressure regulating solenoid valve, task | To control the modulating pressure depending on the constantly changing operating conditions such as load/gear changes. | ||
| Modulating pressure regulating solenoid valve, design | GF27.19-P-5110-03G | ||
| Modulating pressure regulating solenoid valve, function | The modulating pressure regulating solenoid valve (Y3/6y1) assigns a proportional pressure to the current which is controlled by the ETC control module (N15/3) according to the load. |
Control solenoid valve, location/task/design/function - GF27.19-P-5111N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Control Solenoid Valve - Transmission 722.9. Scheme 50
| Control solenoid valve, location | The control solenoid valves are mounted on the electric control unit (VGS) (Y3/8). | ||
|---|---|---|---|
| Control solenoid valve, task | Working pressure control solenoid valve | GF27.19-P-5111-01A | |
| Clutch control solenoid valve K1 | GF27.19-P-5111-01B | ||
| Clutch control solenoid valve K2 | GF27.19-P-5111-01C | ||
| Clutch control solenoid valve K3 | GF27.19-P-5111-01D | ||
| Brake control solenoid valve B1 | GF27.19-P-5111-01E | ||
| Brake control solenoid valve B2 | GF27.19-P-5111-01F | ||
| Brake control solenoid valve B3 | GF27.19-P-5111-01G | ||
| Torque converter lockup clutch control solenoid valve | GF27.19-P-5111-01H | ||
| Control solenoid valve, design | With the control solenoid valves used the proportional solenoids convert the electric signals of the fully integrated transmission control (VGS) control unit (Y3/8n4). The float needles can also be moved into intermediate positions as a result. | ||
| Control solenoid valve, function | The control solenoid valves assign a proportional pressure to a current regulated by the fully integrated transmission control (VGS) control unit (Y3/8n4). |
Shift valve, location / task / design / function - GF27.19-P-5113GF
TRANSMISSION 722.7
Shift Valve Function Diagram - Transmission 722.7. Scheme 51
Location
In the substrate of the electric control module and pressed against the shift valve housing by a leaf spring.
Task
The shift pressure solenoid valve (Y3/7y5) actuates the shift valves 14 and 25.
Design
The shift pressure solenoid valve (Y3/7y5) is sealed to the valve housing by two O-rings (52a, 52b). The contacts (54) on the solenoid valve engage in a slot in the conductor tracks.
Function
The shift pressure solenoid valve (Y3/7y5) is a 3/2-way valve with falling characteristic. When de-energized it delivers the shift valve pressure (p-V) with which the shift valves 14 and 25 are actuated. When actuated by the front-wheel-drive transmission control (FTC) control module (Y3/7n2), it seals off the supply pressure (p-VD).
| Automatic transmission (AT), location of electrical / electronic components | GF27.10-P-0001-08GF | ||
|---|---|---|---|
| AT control module, location / task / design / function | GF27.19-P-5103GF | ||
| Energizing of solenoid valves, production details | GF27.60-P-1000GF | ||
| Valve pressure, function | GF27.60-P-3020GF | ||
| Supply pressure, function | GF27.60-P-3021GF | ||
| 1st and 4th gear shift valve, location / task / function | GF27.60-P-5128GF | ||
| 2nd and 5th gear shift valve, location / task / function | GF27.60-P-5129GF | ||
| Supply pressure regulating valve, location / task / function | GF27.60-P-5130GF |
Transmission range recognition module, location/task/design/function - GF27.19-P-5114GF
TRANSMISSION 722.7
Identifying Transmission Range Recognition Module - Transmission 722.7. Scheme 52
| Gear recognition module, location | The transmission range recognition module (A61) is located in the floor shift. | ||
|---|---|---|---|
| Gear recognition module, task | To detect the respective position of the selector lever and program selector switch as well as convey the touch shifts carried out to the front wheel drive transmission control (FGS) control unit (Y3/7n2) and the instrument cluster (A1). | ||
| Gear recognition module, design | The gear recognition module (A61) consists of a printed circuit board with 6 optoelectronic switches. 3 switches for gear recognition, 2 switches for determining the touch shifts carried out and 1 switch for recognizing the position of the program selector switch. | ||
| Gear recognition module, function | In the switches a photoelectric barrier is closed or penetrated when operated. The gear recognition module (A61) converts these pulses and conveys them to the instrument cluster (A1) and front wheel drive transmission control (FGS) control unit (Y3/7n2). |
Shift PWM solenoid valve, location / task / design / function - GF27.19-P-5116GF
TRANSMISSION 722.7
Shift PWM Solenoid Valve Function Diagram - Transmission 722.7. Scheme 53
Location
In the substrate of the electric control module and pressed against the shift valve housing by a leaf spring.
Task
The pulse-width-modulated solenoid valves (PWM solenoid valves) (Y3/7y1, Y3/7y2, Y3/7y3) actuate the connected regulating valves
- PWM solenoid valve 14 (Y3/7y1) --> Regulating valve 14
- PWM solenoid valve 3 (Y3/7y2) --> Regulating valve 3
- PWM solenoid valve 25R (Y3/7y3) --> Regulating valve 25R
Design
The PWM solenoid valves (Y3/7y1, Y3/7y2, Y3/7y3) are sealed to the valve housing by two O-rings (52a, 52b).
The contacts (54) on the PWM solenoid valve engage in a slot in the conductor tracks.
Function
The PWM solenoid valves convert a pulse-width-modulated current actuated by the FTC transmission control module (Y3/7n2) into a corresponding hydraulic valve pressure (p-V). The PWM solenoid valves are 3/2-way valves with rising characteristic. When de-energized they deliver no valve pressure (p-V).
| Automatic transmission (AT), location of electrical / electronic components | GF27.10-P-0001-08GF | ||
|---|---|---|---|
| AT control module, location / task / design / function | GF27.19-P-5103GF | ||
| Energizing of solenoid valves, production details | GF27.60-P-1000GF | ||
| Valve pressure, function | GF27.60-P-3020GF | ||
| Supply pressure, function | GF27.60-P-3021GF | ||
| 1st and 4th gear regulating valve, location / task / function | GF27.60-P-5124GF | ||
| 3rd gear regulating valve, location / task / function | GF27.60-P-5125GF | ||
| 2nd, 5th and R gear regulating valve, location / task / function | GF27.60-P-5126GF | ||
| Supply pressure regulating valve, location / task / function | GF27.60-P-5130GF |
Wheel speed sensor, location / task / function - GF27.19-P-5127G
TRANSMISSION 722.6
Identifying RPM Sensors 2 And 3 - Transmission 722.6. Scheme 54
| Wheel speed sensor location | The RPM sensors 2 and 3 (Y3/6n2 and Y3/6n3) are permanently connected with the supporting body of the electrical control unit (Y3/6) via contact tongues. | ||
|---|---|---|---|
| Wheel speed sensor - Function | The signals from the RPM sensors 2 3 (Y3/6n2, Y3/6n3) are recorded in the ETC control module (N15/3) together with the wheel and engine speeds and other information, and are the input signals for the electronic control system. | ||
| Speed sensor, function | GF27.19-P-5127-04G |
Rpm sensor, location / task / function - GF27.19-P-5127GF
TRANSMISSION 722.7
Identifying Transmission Output Shaft RPM Sensor - Transmission 722.7. Scheme 55
Location
The transmission output shaft rpm sensor (Y3/7n1) is integrated into the substrate of the electric FTC control module (Y3/7). In the installed state it is carried by the transmission housing (1) and lies directly below the 5th gear wheel drive gear (5a), which is permanently connected with the input shaft (5).
Task
The signals from the transmission output shaft rpm sensor (Y3/7n1) are received and transformed in the front-wheel-drive transmission control (FTC) control module (Y3/7n2).
Function
The transmission output shaft rpm sensor (Y3/7n1) is a Hall sensor which senses the speed of the 5th gear wheel drive gear (5a). Per tooth of the rotating 5th gear wheel drive gear (5a) it transmits one pulse to the front-wheel-drive transmission control (FTC) control module (Y3/7n2).
| Automatic transmission (AT), location of electrical / electronic components | GF27.10-P-0001-08GF |
Speed sensor, location/task/function - GF27.19-P-5127N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Speed Sensor Location - Transmission 722.9. Scheme 56
| Speed sensor, location | The turbine speed sensor (VGS) (Y3/8n1), the internal speed sensor (VGS) (Y3/8n2) and output speed sensor (VGS) (Y3/8n3) are permanently connected to the electric control unit (VGS) (Y3/8) and cannot be replaced individually. | ||
|---|---|---|---|
| Speed sensor, task | Turbine speed sensor | GF27.19-P-5127-02N | |
| Internal rpm sensor | GF27.19-P-5127-02P | ||
| Output speed sensor | GF27.19-P-5127-02O | ||
| Speed sensor, function | Turbine speed sensor | GF27.19-P-5127-04N | |
| Internal rpm sensor | GF27.19-P-5127-04P | ||
| Output speed sensor | GF27.19-P-5127-04O |
Location / task / function of position indicator - GF27.19-P-5129P
TRANSMISSION 722.6 in MODEL 203, 209.3 (except, 209.376) up to 31.5.03, 215, 220 up to 31.8.02
Shown in model 203.0
Identifying Shift Pattern Display And Transmission Mode Switch (Transmission 722.6 Model 203, 209.3 Up To 31.5.03) - Shown In Model 203. Scheme 57
| Position display, location | The position display (shift pattern display (87)) is housed in the cover of the center shifter console. In addition a gear display and transmission mode display is located in the instrument cluster (A1). | ||
|---|---|---|---|
| Position display, task | GF27.19-P-5129-02P | ||
| Position display, function | Models 203, 215, 220 | GF27.19-P-5129-03P | |
| Model 209 | GF27.19-P-5129-03Q |
Location / task / function of position display - GF27.19-P-5129PZ
TRANSMISSION 722.6 in MODEL 203 as of 1.6.03 up to 23.4.04, 215, 220 (except 215.374 /379, 220.074 /174 /179) as of 1.9.02
TRANSMISSION 722.6 in MODEL 209.3 (except 209.376) as of 1.6.03, 209.4 (except 209.476)
Illustrated on model 203.0
Identifying Shift Pattern Display And Transmission Mode Switch - Illustrated On Model 203.0. Scheme 58
| Position display, location | The position display is accommodated in the center shift console cover. | ||
|---|---|---|---|
| Position display, task | GF27.19-P-5129-02PZ | ||
| Shift pattern display, function | Models 203, 215, 220 | GF27.19-P-5129-03PZ | |
| Model 209 | GF27.19-P-5129-03QZ |
Position sensor, location/task/function - GF27.19-P-5129RMZ
TRANSMISSION 722.6 in model 209.376 as of 1.6.03, 209.476, 211.076 as of 1.9.03, 211.276, 215.374 /379, 219.376, 220.074 /174 /179, 230.474 as of 1.9.03, 230.479
TRANSMISSION 722.6 in MODEL 209, 211, 230 with CODE (428) Steering wheel shift buttons
Illustrated on model 230.474
Identifying Shift Pattern Display And Transmission Mode Switch - Illustrated On Model 230.474. Scheme 59
| Position display, location | The position display is accommodated in the center shift console cover. In addition a gear/ driving program display is located in the instrument cluster (A1). | ||
|---|---|---|---|
| Position display, task | GF27.19-P-5129-02RMZ | ||
| Shift pattern display, function | Model 209, 211, 219, 230 | GF27.19-P-5129-03RMZ | |
| Model 215, 220 | GF27.19-P-5129-03GAZ |
Steering wheel gear shifter, location/task/function - GF27.19-P-5137NP
TRANSMISSION 722.9 in MODEL 203 up to 31.5.06 with CODE (428) Steering wheel shift buttons
Identifying Steering Wheel Gear Shifter - Transmission 722.9. Scheme 60
| Steering wheel gear shifter, location | The left steering wheel gear shifter (S110/2) is located on the left, the right steering wheel gear shifter (S111/2) is located on the right on the rear of the multifunction steering wheel (MFL). | ||
|---|---|---|---|
| Steering wheel gear shifter, task | Shifting range preselection Shifting into a gear from which the vehicle can be favorably accelerated or decelerated. Direct shifting of all forward gears | ||
| Steering wheel gear shifter, function | GF27.19-P-5137-04NP |
Steering wheel gear shifter, location/task/function - GF27.19-P-5137PMA
TRANSMISSION 722.6 in MODEL 203, 209, 211 up to 31.5.06 with CODE (428) Steering wheel shift buttons
Illustrated on model 203
Identifying Steering Wheel Gear Shifter (Transmission 722.6) - Illustrated On Model 203. Scheme 61
| Steering wheel gear shifter, location | The left steering wheel gear shifter (S110/2) is located on the left, the right steering wheel gear shifter (S111/2) is located on the right on the rear of the multifunction steering wheel (MFL). | ||
|---|---|---|---|
| Steering wheel gear shifter, task | Shifting range preselection Shifting into a gear from which the vehicle can be favorably accelerated or decelerated. Direct shifting of all forward gears | ||
| Steering wheel gear shifter, function | GF27.19-P-5137-04PMA |
Steering wheel gear shifter, location/task/function - GF27.19-P-5137PMB
TRANSMISSION 722.6 in model 203.076 /276, 209.376 /476, 211.076 /276 as of 1.6.04, 219.376
Shown on model 203
Identifying Steering Wheel Gear Shifter (Transmission 722.6) - Shown On Model 203. Scheme 62
| Steering wheel gear shifter, location | The steering wheel gear shifter MINUS (S110/1) is located on the left, the steering wheel gear shifter PLUS (S111/1) is located on the right on the back of the multifunction steering wheel (MFL). | ||
|---|---|---|---|
| Steering wheel gear shifter, task | Preselection of shift range. Shifting into a gear from which the vehicle can be favorably accelerated or decelerated. Direct shifting of all forward gears. | ||
| Steering wheel gear shifter, function | GF27.19-P-5137-04PMB |
Electronic selector lever module control unit, location/task/design - GF27.19-P-5138P
TRANSMISSION 722.6 in model 203 up to 23.4.04, 209, 211, 219
Illustrated on model 203.0
Identifying Electronic Selector Lever Module Control Unit (Transmission 722.6) - Illustrated On Model 203.0. Scheme 63
| Control unit for electronic selector lever module, location | The control unit for the electronic selector lever module (N15/5) is located in the center console of the vehicle. | ||
|---|---|---|---|
| Control unit for electronic selector lever module, task | Model 203 | GF27.19-P-5138-02P | |
| Model 209 up to 31.05.04 | GF27.19-P-5138-02Q | ||
| Model 209 as of 01.06.04 | GF27.19-P-5138-02QX | ||
| Model 211 up to 31.05.04 | GF27.19-P-5138-02T | ||
| Model 211 as of 01.06.04 Model 219 | GF27.19-P-5138-02TX | ||
| Electronic selector lever module control unit, design | GF27.19-P-5138-03P |
Electronic selector lever module control unit, location/task/design - GF27.19-P-5138PM
TRANSMISSION 722.6 in MODEL 203 (except 203.02 /05 /076 /22 /25 /276) as of 24.4.04 except CODE (428a) Steering wheel shift buttons
Identifying Electronic Selector Lever Module Control Unit - Transmission 722.6. Scheme 64
| Electronic selector lever module control unit, location | The control unit for the electronic selector lever module (N15/5) is located in the center console of the vehicle. | ||
|---|---|---|---|
| Control unit for electronic selector lever module, task | GF27.19-P-5138-02PM | ||
| Electronic selector lever module control unit, design | GF27.19-P-5138-03P |
Electronic selector lever module control unit, location/task/design - GF27.19-P-5138PMZ
TRANSMISSION 722.6 in MODEL 203 with CODE (428a) Steering wheel shift buttons
TRANSMISSION 722.6 in MODELS 203.076 /276
Identifying Electronic Selector Lever Module Control Unit - Transmission 722.6. Scheme 65
| Electronic selector lever module control unit, location | The control unit for the electronic selector lever module (N15/5) is located in the center console of the vehicle. | ||
|---|---|---|---|
| Control unit for electronic selector lever module, task | GF27.19-P-5138-02PMZ | ||
| Electronic selector lever module control unit, design | GF27.19-P-5138-03P |
Electronic selector lever module control unit, location/task - GF27.19-P-5140NP
TRANSMISSION 722.9 in MODEL 203
Identifying Electronic Selector Lever Module Control Unit - Transmission 722.9. Scheme 66
| Control unit for electronic selector lever module, location | The control unit for the electronic selector lever module (N15/5) is located in the center console of the vehicle. | ||
|---|---|---|---|
| Control unit for electronic selector lever module, task | Except code (428) steering wheel shift buttons | GF27.19-P-5138-02NP | |
| With code (428) steering wheel shift buttons | GF27.19-P-5138-02NPL |
Kickdown switch, location / task / design - GF27.19-P-5141GA
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 with touch shift
TRANSMISSION 722.6 in MODEL 203, 215, 220, 230 up to 31.5.02
Shown in model 170
Scheme 67
| Kickdown switch position | The kickdown switch (S16/6) is located in the footwell, integrated into the electric accelerator pedal. | ||
|---|---|---|---|
| Kickdown switch task | Influencing the shift program of the electronic transmission control. | ||
| Kickdown switch design | The kickdown switch (S16/6) consists of a spring-tensioned electrical switch contact. |
Selection range sensor, location/task - GF27.19-P-5142N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Scheme 68
| Selection range sensor, location | The selection range sensor (VGS) (Y3/8s1) is integrated in the electric control unit (VGS) (Y3/8). | ||
|---|---|---|---|
| Selection range sensor, task | The task of the selection range sensor (VGS) (Y3/8s1) is to detect the selection ranges "P", "R", "N", "D" and the intermediate position. |
Transmission housing breather, location/task - GF27.40-P-2007G
TRANSMISSION 722.6
Identifying Transmission Housing Breather Location - Transmission 722.6. Scheme 69
| Transmission housing breather, location | The inside of the transmission and the breather (72) are connected by a channel which is cast into the torque converter casing. | ||
|---|---|---|---|
| Transmission housing breather, task | The transmission housing vent compensates the pressure in the transmission housing if temperature-related volume changes in the transmission oil and air occur. |
Transmission housing vent, location/task - GF27.40-P-2007N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Transmission Housing Breather Location - Transmission 722.9. Scheme 70
| Transmission housing breather, location | The inside of the transmission and the breather (72) are connected by a channel which is cast into the torque converter housing. | ||
|---|---|---|---|
| Transmission housing breather, task | The transmission housing breather ensures that a pressure equilibrium is maintained in the event of temperature-related volume changes in the transmission fluid and air in the transmission housing. |
Planetary gear set, location / task / design / function - GF27.50-P-5100G
TRANSMISSION 722.6
Identifying Planetary Gear Set - Transmission 722.6. Scheme 71
| Planetary gear set, location | Three planetary gear sets are used to produce the different gear ratios. These are located in the mechanical part of the transmission as the front, center and rear planetary gear set (V, M, H) | ||
|---|---|---|---|
| Planetary gear set, task | Power transmission and production of different gear ratios. | ||
| Planetary gear set, design | A planetary gear set consists of the ring gear (1), the planet gears (2) carried in the planet carrier (4) and the sun gear (3). | ||
| Planetary gear set, function | GF27.50-P-5100-01G |
Planetary gear set, location/task/design/function - GF27.50-P-5100N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230 Ravigneaux gear set
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Planetary Gear Set - Transmission 722.9. Scheme 72
| Planetary gear set, location | The Ravigneaux gear set (9) is located in the mechanical part of the transmission. | ||
|---|---|---|---|
| Planetary gear set, task | Power transmission and production of different gear ratios. | ||
| Planetary gear set, design | The Ravigneaux gear set (9) used consists of 2 ring gears, a planet carrier, a sun gear as well as short and long planetary gears. | ||
| Planetary gear set, function | GF27.50-P-5100-01N |
Planetary gear set, location/task/design/function - GF27.50-P-5100NN
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230 Single planetary gear set
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Shift From 1 To 2 Function Diagram, 2nd Gear Engaged - Transmission 722.6. Scheme 73
| Planetary gear set, location | The front single planetary gear set (12a) and the rear single planetary gear set (12b) are located in the mechanical part of the transmission. | ||
|---|---|---|---|
| Planetary gear set, task | Power transmission and production of different gear ratios. | ||
| Planetary gear set, design | A single planetary gear system consists of a ring gear, the planetary gears mounted in the planet carrier and a sun gear | ||
| Planetary gear set, function | GF27.50-P-5100-01NN |
Multiple-disc brake, location / task / design / function - GF27.51-P-5100G
TRANSMISSION 722.6
Identifying Multiple-Disc Brake - Transmission 722.6. Scheme 74
| Multiple-disc brake, location | Three multiple-disc brakes arranged as the front, center and rear multiple-disc brake (B1, B3, B2) are located in the planetary gear sets in the transmission housing. | ||
|---|---|---|---|
| Multiple-disc brake, task | Brace the ring gear, sun gear or planet carrier of a planetary gear set against the transmission housing in order to transmit the drive torque. | ||
| Multiple-disc brake, design | A multiple-disc brake consists of a number of internally toothed discs (10) on an internally toothed disc carrier and externally toothed discs (9) on an externally toothed disc carrier, which is rigidly connected to the transmission housing. | ||
| Multiple-disc brake, function | GF27.51-P-5100-04G |
Multi-plate clutch, location / task / design / function - GF27.51-P-5101G
TRANSMISSION 722.6
Identifying Multi-Plate Clutch Location - Transmission 722.6. Scheme 75
| Multi-disk clutch, location | Three multi-plate clutches, the front, middle and rear multi-plate clutches K1, K2 and K3, are located in the planetary gear sets in the transmission housing. | ||
|---|---|---|---|
| Multi-disk clutch, task | Produces a non-positive locking connection between two elements of a planetary gear set or between one element from each of two planetary gear sets in order to transmit the drive torque. | ||
| Multiple-disc clutch, design | A multi-plate clutch consists of a number of internally toothed discs (10) on an internally toothed disc carrier and externally toothed discs (9) on an externally toothed disc carrier. | ||
| Multi-disk clutch, function | GF27.51-P-4000-01G |
Location / task / design / function of freewheel - GF27.51-P-5102G
TRANSMISSION 722.6
Identifying Freewheel Function - Transmission 722.6. Scheme 76
| Freewheel, location | In the front planetary gear set a freewheel (F1, F2) is installed between the front sun gear (V1) and the stator shaft (8) and in the rear planetary gear set between the rear sun gear (H1) and the intermediate shaft (3). | ||
|---|---|---|---|
| Freewheel, task | Optimizes individual gearshifts. Support of the individual elements of a planetary gear set against each other or against the transmission housing in one direction of rotation in order to permit torque transmission. | ||
| Freewheel, design | The freewheels (F1, F2) consist of an outer race (12), an inner race (13), a number of clamping bodies (14) and a clamping body cage (15). | ||
| Freewheel, function | GF27.51-P-5102-04G |
Multi-disk clutch, location/task/design - GF27.51-P-5103N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Multi-Disk Clutch - Transmission 722. Scheme 77
| Multi-disk clutch, location | 3 multi-disk clutches made up of multi-disk clutch K1 (8), multi-disk clutch K2 (11) and multi-disk clutch K3 (14) are arranged in planetary gear systems in the transmission housing. | ||
|---|---|---|---|
| Multi-disk clutch, task | To produce a friction connection between 2 elements of a planetary gear set or one element each from 2 planetary gear sets, for transferring the drive torque. | ||
| Multi-disk clutch, design | GF27.51-P-5103-03N |
Multi-disk brake, location/task/design - GF27.51-P-5104N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Center Shifter Console - Illustrated On Model 203.061. Scheme 78
| Multi-disk brake, location | 4 multi-disk brakes made up of multi-disk brake B1 (7), multi-disk brake B3 (10), multi-disk brake BR (13) and multi-disk brake B2 (15) are arranged in the planetary gear systems in the transmission housing. | ||
|---|---|---|---|
| Multi-disk brake, task | To support the ring gear, sun gear or planet carrier of a planetary gear set relative to the transmission housing, to transmit the drive torque. | ||
| Multi-disk brake, design | GF27.51-P-5104-03N |
Center shifter console, location/task/design/function - GF27.60-P-5100NP
TRANSMISSION 722.9 in MODEL 203
Identifying Center Shifter Console Location. Scheme 79
| Center shifter console, location | The floor shift is located in the center console of the vehicle. | ||
|---|---|---|---|
| Center shifter console, task | The floor shift is the central control for the driver to influence the shift program of the automatic transmission. | ||
| Center shifter console, design | Except code (428) Steering wheel shift buttons | GF27.60-P-5100-03NP | |
| With code (428) Steering wheel shift buttons | GF27.60-P-5100-03NPL | ||
| Center shifter console, function | GF27.60-P-5100-04NP |
Center shifter console, location/task/design/function - GF27.60-P-5100P
TRANSMISSION 722.6 in MODEL 203, 209, 211, 219
Identifying Shift Valve Pressure Regulating Valve Location - Transmission 722.6. Scheme 80
Shown on model 203.061
| Center shifter console, location | The floor shift is located in the center console of the vehicle. | ||
|---|---|---|---|
| Center shifter console, task | The floor shift is the central control for the driver to influence the shift program of the automatic transmission. | ||
| Center shifter console, design | Models 203, 209 up to 31.05.03, 211 to 31.08.03 | GF27.60-P-5100-03P | |
| Model 203, 209 as of 01.06.03, 211 after 01.09.03 | GF27.60-P-5100-03PZ | ||
| Model 219 | |||
| Center shifter console, function | GF27.60-P-5100-04P |
Shift detent, location/task/design/function - GF27.60-P-5101NT
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 219
Identifying Holding Pressure Shift Valve Location - Transmission 722.6. Scheme 81
| Shift detent, location | The shift detent is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| Shift detent, task | Locating the selector lever positions "R", "N" and "D" | ||
| Shift detent, design | The shift detent consists of the locking lever (69) permanently connected with the selector lever (80), a leaf spring (85) clamped in the basic housing and a roller (84) inserted in the leaf spring (85). | ||
| Shift detent, function | GF27.60-P-5101-04NT |
Location / task / design / function of shift detent - GF27.60-P-5101P
TRANSMISSION 722.6 in MODEL 171.4, 203, 209, 211, 219
Identifying Shift Detent Location - Transmission 722.6 In Model 171.4, 203, 209, 211, 219. Scheme 82
| Shift detent, location | The shift detent is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| Shift detent, task | Fixing the selector lever positions "R", "N" and "D". | ||
| Shift detent, design | The shift detent consists of: the locking lever (69) rigidly connected to the selector lever (80). a leaf spring clamped in the base body (85). a roller (84) inserted in the leaf spring (85) (84). | ||
| Shift detent, function | GF27.60-P-5101-04P |
R/P lock, location/task/design/function - GF27.60-P-5103NT
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 219
Identifying R/P Lock Location - Transmission 722.9 In Model 171.4, 203, 209, 211, 219. Scheme 83
| R/P lock, location | The R/P lock is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| R/P lock, task | Depending on the condition the R/P lock prevents shifting out of selector lever position "P" or changing into selector lever position "R" from "N". | ||
| R/P lock, design | The R/P lock consists of: Locking lever (69) R/P locking solenoid (89) Rocker (100) Leaf spring of rocker (101) Rocker arm (102) Leaf spring of rocker arm (103) | ||
| R/P lock, function | GF27.60-P-5103-04NT |
R/P lock, location/task/design/function - GF27.60-P-5103P
TRANSMISSION 722.6 in MODEL 171.4, 203, 209, 211, 219
Identifying R/P Lock Location - Transmission 722.6 In Model 171.4, 203, 209, 211, 219. Scheme 84
| R/P lock, location | The R/P lock is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| R/P lock, task | Depending on the prerequisite, the R/P-lockout prevents a shift out of selector lever position "P" or a changeover to selector lever position "R" from "N". | ||
| R/P lock, design | The R/P lock consists of: Locking lever (69) R/P locking solenoid (89) Rocker (100) Leaf spring of rocker (101) Rocker arm (102) Leaf spring of rocker arm (103) | ||
| R/P lock, function | GF27.60-P-5103-04P |
Working pressure regulating valve, location/task/function - GF27.60-P-5131G
TRANSMISSION 722.6
Identifying Working Pressure Regulating Valve Location - Transmission 722.6. Scheme 85
| Working pressure regulating valve, location | 2In the valve housing of the shift plate. | ||
|---|---|---|---|
| Working pressure regulating valve, task | Regulates the primary pressure of the hydraulic system. | ||
| Working pressure regulating valve, function | GF27.60-P-5131-01G |
Shift pressure regulating valve, location / task / function - GF27.60-P-5132G
TRANSMISSION 722.6
Identifying Shift Pressure Regulating Valve Location - Transmission 722.6. Scheme 86
| Shift pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Shift pressure regulating valve, task | Control of shift pressure. | ||
| Shift pressure regulating valve, function | GF27.60-P-5132-04G |
Regulating valve pressure regulating valve, location / task /function - GF27.60-P-5133G
TRANSMISSION 722.6
Identifying Regulating Valve Pressure Regulating Valve Location - Transmission 722.6. Scheme 87
| Regulating valve pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Regulating valve pressure regulating valve, task | Controls the regulating valve pressure. | ||
| Regulating valve pressure regulating valve, function | GF27.60-P-5133-04G |
Shift valve pressure regulating valve, location/task/function - GF27.60-P-5134G
TRANSMISSION 722.6
| Shift valve pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Shift valve pressure regulating valve, task | Control of shift valve pressure. | ||
| Shift valve pressure regulating valve, function | GF27.60-P-5134-04G |
Holding pressure shift valve, location/task/function - GF27.60-P-5135G
TRANSMISSION 722.6
| Holding pressure shift valve, location | Each shift group is assigned a holding pressure shift valve (28a, 28b, 28c). The holding pressure shift valves 1-2/4-5 (28a) and 2-3 (28b) are installed in the valve housing (2b), the 3-4 holding pressure shift valve (28c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Holding pressure shift valve, task | Allocates the working pressure to one actuator of a shift group. | ||
| Holding pressure shift valve, function | GF27.60-P-5135-04G |
Shift pressure shift valve, location / task / function - GF27.60-P-5136G
TRANSMISSION 722.6
Identifying Shift Pressure Shift Valve - Transmission 722.6. Scheme 88
| Shift pressure shift valve, location | Each shift group possesses one shift pressure shift valve. The 1-2/4-5 shift pressure shift valves (29a) and 2-3 shift pressure shift valve (29b) are installed in the valve housing of the shift plate (2b), the 3-4 shift pressure shift valve (29c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Shift pressure shift valve, task | To assign shift pressure to the engaging shift actuator and to assign the overlap pressure, controlled by the overlap regulating valve, to the disengaging shift actuator. | ||
| Shift pressure shift valve, function | GF27.60-P-5136-04G |
Overlap regulating valve, location / task / function - GF27.60-P-5137G
TRANSMISSION 722.6
Identifying Overlap Regulating Valve Location - Transmission 722.6. Scheme 89
| Overlap regulating valve, location | Each shift group is assigned one overlap regulating valve. The 1-2/4-5 overlap regulating valve (30a) is installed in the valve housing of the shift plate (2b), the 2-3 overlap regulating valve (30b) and 4-5 (30c) are installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Overlap regulating valve, location | The overlap regulating valve regulates the pressure reduction during a shift phase. | ||
| Overlap regulating valve, function | GF27.60-P-5137-04G |
Location/task/function of command valve - GF27.60-P-5138G
TRANSMISSION 722.6
Identifying Command Valve Location - Transmission 722.6. Scheme 90
| Command valve, location | Each shift group possesses one command valve. The 1-2/4-5 command valves (31a) and 2-3 (31b) are installed in the valve housing of the shift plate (2b), the 3-4 command valve (31c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Command valve, task | The command valves switch the shift groups from the stationary phase into the shift phase and back again | ||
| Command valve, function | GF27.60-P-5138-04G |
Selector valve, location/task - GF27.60-P-5139G
TRANSMISSION 722.6
Identifying Selector Valve Location - Transmission 722.6. Scheme 91
| Selector valve, location | The selector valve (52) is located in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Selector valve, task | Distributes pressure to the appropriate hydraulic components according to the selector lever position selected by the driver. |
