Scheme 109
Note. When installing a new HVAC module on vehicles equipped with Electronic Manual Temperature Control (EMTC), the Programmable Module Installation (PMI) procedure must be carried out to configure the new module to the vehicle. See PROGRAMMABLE MODULE INSTALLATION (PMI) .
- Remove the middle center instrument panel finish panel. See «INSTRUMENT PANEL CENTER FINISH PANEL - MIDDLE REMOVAL/INSTALLATION»(ref-373121-S18177376182010100600000) .
- Remove the 4 climate control module screws.
- Remove the climate control module.
- To install, reverse the removal procedure.
Scheme 110
Note. The LH temperature blend door actuator is present on dual-zone dual automatic temperature control (DATC) vehicles to control the LH temperature blend door only.
- Disconnect the LH temperature blend door actuator electrical connector.
- Remove the 2 LH temperature blend door actuator screws. To install, tighten to 3 N.m {0.3 kgf.m, 27 in.lbf}.
- Remove the LH temperature blend door actuator.
- To install, reverse the removal procedure.
Scheme 111
Note. Vehicle equipped with electronic manual temperature control (EMTC), the RH temperature blend door actuator is used to control the single temperature blend door for both sides of the vehicle.
Scheme 112
Scheme 113
Scheme 114
Scheme 115
- Remove the upper center instrument panel finish panel.
- Remove the passenger air bag module. See «PASSENGER AIR BAG MODULE REMOVAL/INSTALLATION»(ref-373086-S41914677292010100600000)
- Working through the passenger air bag module opening, remove the RH panel duct screw.
- Working through the passenger air bag module opening, remove the upper RH center panel duct screw.
- Remove the lower RH center panel duct screw. Detach the wire harness pin-type retainer. Remove the lower RH center panel duct screw. NOTE: The lower RH center panel duct screw is located just below the RH lower rear corner of the audio unit.
- Working through the glove compartment opening, detach the wire harness pin-type retainer above the evaporator discharge air temperature sensor.
- Disconnect the RH temperature blend door actuator electrical connector. CAUTION: Use care to avoid dropping the RH temperature blend door actuator screws into the plenum chamber when removing the screws. If a screw is dropped into the plenum chamber, it may cause the airflow mode doors to jam, or may cause noise concerns.
- Remove the 2 RH temperature blend door actuator screws. To install, tighten to 3 N.m {0.3 kgf.m, 27 in.lbf}.
- Remove the RH temperature blend door actuator. NOTE: The RH center instrument panel duct must be slightly repositioned to allow access to the RH temperature blend door actuator screws.
- To install, reverse the removal procedure.
Scheme 116
- Remove the heater core and evaporator core housing. See «HEATER CORE AND EVAPORATOR CORE HOUSING REMOVAL/INSTALLATION»(ref-373116-S20029036572010100600000) .
- Disconnect the air inlet mode door actuator electrical connector.
- Remove the 2 air inlet mode door actuator screws. To install, tighten to 3 N.m {0.3 kgf.m, 27 in.lbf}.
- Remove the air inlet mode door actuator.
- To install, reverse the removal procedure.
Scheme 117
Note. The defrost/panel/floor mode door actuator can be accessed from below the LH side of the instrument panel.
- Disconnect the defrost/panel/floor mode door actuator electrical connector.
- Remove the 2 defrost/panel/floor mode door actuator screws. To install, tighten to 3 N.m {0.3 kgf.m, 27 in.lbf}.
- Remove the defrost/panel/floor mode door actuator.
- To install, reverse the removal procedure.
Scheme 118
- Disconnect the blower motor electrical connector.
- Release the 2 blower motor vent tube clips and pull the vent tube down until it is disengaged from the heater core and evaporator core housing.
- Rotate the blower motor counterclockwise to disengage it from the housing and remove the blower motor. NOTE: The carpet below the blower motor must be slightly repositioned to remove the blower motor.
- To install, reverse the removal procedure.
