WIPERS AND WASHERS

Refer to the WIPER/WASHER Wiring Diagram for schematic information.

Rear Window Wiper Washer

The generic electronic module (GEM) allows operation of the rear window wiper functions when the ignition switch is in the RUN or ACC position only. The GEM controls the cycling of the rear window wiper motor through a single relay (rear window wiper relay).

There are four modes of operation: off mode, interval mode, on mode and wash mode.

Note. The GEM does not control the rear window washer, only the rear window wiper.

In the off mode, there is no liftgate wiper motor activity and the liftgate wiper motor will be in the PARK position. When the wiper/washer switch is placed in the interval position, the GEM will activate the rear window wipe cycle of the rear window wiper motor. Once the wiper cycle has reaches the LO position, after the initial wipe, the GEM will start a cyclical timing function.

In the ON mode, the GEM will cycle the rear window motor continuously at a set- speed setting. The GEM provides a ground to activate the rear window wiper relay. The wash mode can only be activated when the rear wiper switch is in the OFF or ON positions. When the rear wiper switch is in the OFF position and wash mode is activated, the rear window wiper will not cycle.

Fluid for the rear window washer is supplied by a washer pump located in the rear passenger compartment.

Scheme 8

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the WDS or equivalent Tester does not power up, refer to the WDS or equivalent Tester manual.
5. Carry out the DATA LINK DIAGNOSTICS test. If the WDS or equivalent Tester responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to COMMUNICATIONS NETWORK . NO RESP/NOT EQUIP for GEM, Refer to PINPOINT TEST 1: NO COMMUNICATION WITH THE GENERIC ELECTRONIC MODULE (GEM) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out the self-test diagnostics for the GEM.
6. If the DTCs retrieved are related to the concern, go to the GEM Diagnostic Trouble Code (DTC) Index to continue diagnostics.
7. If no DTCs related to the concern are retrieved, proceed to the «GEM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-155139-S03623116162005020900000) to continue diagnostics.

Scheme 9

Windshield Wiper Motor

Use an Alternator, Regulator, Battery and Starter Tester (ARBST) to test the wiper motor on the vehicle.

To test the wiper motor, disconnect the windshield wiper mounting arm and pivot shaft from the windshield wiper motor; refer to WIPER PIVOT ARM - FRONT or WIPER PIVOT ARM - REAR .

Disconnect the wiper motor. Connect the (1) green lead from (2) Alternator, Regulator, Battery and Starter Tester (ARBST) to the battery negative (-) post. Connect the (3) red lead from ARBST to the wiper motor (4) common brush terminal (terminal 3).

Test the low-speed mode by connecting a (5) cable from the battery positive (+) post to the (6) low-speed brush terminal (terminal 4) and measure the current draw. If the current draw is greater than 3.5 amperes, install a new windshield wiper motor.

Test the high-speed mode by connecting a cable from the battery positive (+) post to the (7) high-speed brush terminal (terminal 5) and measure the current draw. If the current draw is greater than 5.5 amperes, install a new wiper motor.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

WIPERS AND WASHERS - FRONT

The windshield wipers and washer system consists of the following

1. windshield wiper blade
2. windshield wiper pivot arm
3. windshield wiper mounting arm and pivot shaft
4. windshield wiper motor
5. windshield wiper/washer switch
6. generic electronic control module (GEM)
7. windshield washer degas bottle
8. windshield washer pump
9. windshield washer nozzle jet

Scheme 38

Scheme 39

1. Remove the pivot arm nut.
2. Remove the windshield wiper pivot arm.
3. To install, reverse the removal procedure. Adjust the windshield wiper pivot arms. For additional information, refer to «WINDSHIELD WIPER BLADE AND PIVOT ARM ADJUSTMENT»(ref-155139-S39412259862005020900000) .

Scheme 40

1. Remove the cowl top vent panels; refer to «COWL PANEL GRILLE»(ref-155139-S24485034662005021000000) .
2. Remove the wiper mounting arm and pivot shaft. Disconnect the electrical connector. Remove the bolts. Remove the wiper mounting arm and pivot shaft.
3. Remove the motor assembly.
4. To install, reverse the removal procedure.

Scheme 41

1. Remove the wiper mounting arm and pivot shaft refer to, «WIPER MOUNTING ARM AND PIVOT SHAFT»(ref-155139-S22874992142005020900000) .
2. Remove the windshield wiper motor. Remove the bolt and windshield wiper motor linkage. Remove the windshield wiper motor mounting bolts. Remove the windshield wiper motor.
3. To install, reverse the removal procedure.

WIPERS AND WASHERS - REAR

The rear window wiper and washer system consists of the following

1. rear window wiper blade
2. rear window wiper arm
3. rear window wiper motor
4. rear window wiper/washer switch
5. generic electronic control module (GEM)
6. windshield washer degas bottle
7. rear window washer pump
8. rear window washer hose
9. rear window washer hose check valve
10. rear window washer nozzle jet

Scheme 42

1. Remove the pivot arm. Lift pivot arm to the upright position. Slide the locking tab out. Pull up and remove the pivot arm.
2. To install, reverse the removal procedure. Adjust the windshield wiper pivot arm. For additional information, refer to «REAR WINDOW WIPER BLADE AND PIVOT ARM ADJUSTMENT»(ref-155139-S10544486582005020900000) .

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. Remove the pivot arm. Lift pivot arm to the upright position. Slide the locking tab out. Pull up and remove the pivot arm.
2. Remove the rear wiper motor shaft nut cover.
3. Remove the rear wiper motor shaft nut.
4. Open the liftgate.
5. Remove the rear wiper motor plastic cover.
6. Remove rear wiper motor. Disconnect the electrical connector. Remove the nut. Remove the bolt. Remove the rear wiper motor.
7. To install, reverse the removal procedure.

Scheme 48

1. Remove the RH front wheel and tire assembly.
2. Remove the RH front splash shield. WARNING: Windshield washer solution contains methanol, which is poisonous. Observe all cautions and warnings indicated on the label of the washer solution container. Failure to follow these instructions may result in personal injury. NOTE: To prevent spilling windshield washer fluid, drain the windshield washer degas bottle before washer pump removal.
3. Remove the windshield washer pump. Disconnect the electrical connector. Disconnect the hose. Remove the windshield washer pump. CAUTION: Do not operate the windshield washer pump prior to filling the windshield washer degas bottle.
4. To install, reverse the removal procedure. WARNING: Windshield washer solution contains methanol, which is poisonous. Observe all cautions and warnings indicated on the label of the washer solution container. Failure to follow these instructions may result in personal injury. Fill the windshield washer degas bottle with windshield washer fluid.

Scheme 49

1. Cycle and park the rear window wiper.
2. Verify that the rear window wiper blade is located at the specified position.
3. If not within specification, remove the rear window wiper pivot arm and reposition to the correct location; refer to «REAR WINDOW WIPER BLADE AND PIVOT ARM ADJUSTMENT»(ref-155139-S10544486582005020900000) i.

Scheme 50

Scheme 51

Scheme 52

1. Remove the wiper pivot arms. Remove the nuts. Remove the wiper pivot arms.
2. Remove the driver-side cowl grille. Remove the pin-type retainers. Remove the screw caps and screws. Remove the cowl grille.
3. Remove the passenger-side cowl grille. Remove the pin-type retainers. Remove the screw caps and screws. Remove the cowl grille.
4. To install, reverse the removal procedure.
