Power Windows: Removal & Installation Mazda Tribute I

Windows 41 illustrations ~1221 words

Removal

WARNINGTo prevent glass splinters from entering the eyes or cutting hands, wear safety glasses and heavy gloves when cutting the glass from the vehicle. Failure to follow these instructions may result in personal injury.

Scheme 25

Scheme 25
  1. Remove the headliner. For additional information, refer to «HEADLINER»(ref-171754-S09027903012005021100000) . NOTE: Lubricate the urethane adhesive with water to aid the special tool when cutting. NOTE: Locating tabs need to be cut through in order to remove the rear quarter glass. The new quarter window glass will be equipped with new locating tabs.
  2. Using the special tool, cut the urethane adhesive from the quarter window glass starting at the top center and working toward the bottom corners and remove the rear quarter window glass.
  3. Using a soft brush or vacuum, remove any foreign material or dirt from the pinch weld.

Installation

CAUTIONAfter installing the urethane installed glass, the vehicle should not be driven until the urethane adhesive has cured. The curing time at temperatures above 13°C (55°F) and relative humidity above 50% is 12-24 hours. (Refer to the Essex drive away chart for the cure times as temperatures and humidity vary.) Inadequate curing of the urethane adhesive will adversely affect the strength of the urethane bond.

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28
  1. Dry fit the quarter window glass, making alignment marks with tape or non-staining grease pencil. CAUTION: Do not scratch the pinch weld area.
  2. Trim the remaining urethane adhesive on the pinch weld to within the specification. The existing urethane adhesive surface should be smooth and free of cuts and contamination. CAUTION: Use caution when applying Urethane Metal Primer Essex U-413. Apply a light amount of primer. Too much primer will run and damage the painted surface.
  3. Use a wool applicator to apply Urethane Metal Primer Essex U-413 to any exposed metal on the pinch weld. Allow 6 to 10 minutes to dry.
  4. Clean the inside of the quarter glass surface with alcohol-free cleaner, making sure the ceramic coated area is clean. NOTE: Wipe off the glass prep immediately after each application because it flash dries.
  5. Apply Urethane Glass Prep Essex U-401 twice around the glass surface to be urethaned.
  6. Apply Glass Primer Essex U-402 to the same area that was prepped in the previous step. Allow five minutes to dry.
  7. Cut the urethane adhesive applicator tip to specification. NOTE: Use caution when applying urethane adhesive. Apply to the outside edges of locating tabs on the glass surface.
  8. Apply a bead of Urethane Adhesive Essex 400-HV or Essex U-216. Start at the bottom and work around to the sides of the quarter window glass.
  9. Install the quarter window glass, aligning it to the marks previously made.
  10. After the quarter window glass is set, check for water leaks and add urethane adhesive where needed.
  11. If necessary, remove excess urethane adhesive from the outside surface of the quarter window glass.
  12. Install the headliner. Refer to «HEADLINER»(ref-171754-S09027903012005021100000) .

Scheme 29

Scheme 29: Removal and Installation

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33
  1. Open the liftgate glass.
  2. Remove the two liftgate nut access covers (one on each side).
  3. Disconnect the rear window glass electrical harness connector.
  4. Disconnect the heated window grid wire electrical connector. NOTE: An assistant may be needed to carry out this step.
  5. Disconnect the two liftgate window glass cylinders. Slide the spring retainer to the end of the socket. Disconnect the socket from the ball stud. NOTE: An assistant may be needed to carry out this step.
  6. Remove the two liftgate window glass hinge nuts.
  7. To install, reverse the removal procedure. Transfer components as necessary.

Scheme 34

Scheme 34: Removal and Installation

Scheme 35

Scheme 35
  1. Remove the front door window glass. For additional information, refer to «FRONT DOOR WINDOW GLASS»(ref-154860-S15579476582005021400000) .
  2. Remove the front door interior sail panel. If equipped, disconnect the speaker electrical connector.
  3. Remove the door glass top run bolts.
  4. Remove the door glass top run.
  5. To install, reverse the removal procedure.

Scheme 36

Scheme 36: Removal

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40

Scheme 41

Scheme 41

Scheme 42

Scheme 42
  1. Remove the rear door window regulator. For additional information, refer to «REAR DOOR WINDOW REGULATOR»(ref-154860-S42858880722005021400000) .
  2. Position the rear door window glass to the full down position.
  3. Remove the screws and the rear door exterior sail panel.
  4. Remove the rear door interior glass weatherstrip.
  5. Remove the rear door exterior belt line molding.
  6. Remove the rear door glass top run bolts.
  7. Position the rear door window glass down and forward.
  8. Remove the rear door glass top run.
  9. To install, reverse the removal procedure.

Removal and Installation

All vehicles

Scheme 43

Scheme 43: Removal and Installation

Scheme 44

Scheme 44

Scheme 45

Scheme 45

Scheme 46

Scheme 46

Scheme 47

Scheme 47

Scheme 48

Scheme 48
  1. Remove the front door trim panel. Refer to «FRONT DOOR TRIM PANEL»(ref-154860-S08267650862005021400000) .
  2. Remove the screw and the front door trim panel bracket.
  3. Position the water shield aside. Vehicles with power windows
  4. Connect the window control switch electrical connector.
  5. Connect the battery. All vehicles
  6. Lower the front door window glass to gain access to the screws. Vehicles with power windows
  7. Disconnect the battery.
  8. Disconnect the window control switch electrical connector. All vehicles
  9. Remove the front door window glass screws.
  10. Support the front door window glass in the full up position. Vehicles with power windows
  11. Disconnect the front door power window regulator motor electrical connector.
  12. Remove the front door power window regulator assembly. Remove the bolts. Remove the nuts. Vehicles with manual windows
  13. Remove the front door window regulator assembly. Remove the bolts. Remove the nuts. All vehicles
  14. To install, reverse the removal procedure. Cycle the door window glass to make sure of correct door window glass engagement.

All vehicles

Scheme 49

Scheme 49: Removal and Installation

Scheme 50

Scheme 50

Scheme 51

Scheme 51

Scheme 52

Scheme 52

Scheme 53

Scheme 53

Scheme 54

Scheme 54

Scheme 55

Scheme 55
  1. Remove the rear door trim panel. Refer to «REAR DOOR TRIM PANEL»(ref-154860-S19269997872005021400000) .
  2. Remove the screw and the rear door trim panel bracket.
  3. Position the water shield aside. Vehicles with power windows
  4. Connect the window control switch electrical connector. All vehicles
  5. Lower the rear door window glass to gain access to the screws. Vehicles with power windows
  6. Disconnect the window control switch electrical connector. All vehicles
  7. Remove the rear door window glass screws.
  8. Support the rear door window glass in the full up position. Vehicles with power windows
  9. Disconnect the rear door power window regulator electrical connector.
  10. Remove the rear door power window regulator assembly. Remove the bolts. Remove the nuts. Vehicles with manual windows
  11. Remove the rear door window regulator assembly. Remove the bolts. Remove the nuts. All vehicles
  12. To install, reverse the removal procedure. Cycle the door glass to make sure of correct window glass engagement.

Note. The removal and installation procedures for all window control switches are similar.

Scheme 56

Scheme 56: Removal and Installation
  1. Remove the front door trim panel or the rear door trim panel. Refer to «FRONT DOOR TRIM PANEL»(ref-154860-S08267650862005021400000) , or «REAR DOOR TRIM PANEL»(ref-154860-S19269997872005021400000) .
  2. Release the locking clips and remove the window control switch.
  3. To install, reverse the removal procedure.

Vehicles with power windows

Scheme 57

Scheme 57: Removal and Installation

Scheme 58

Scheme 58

Scheme 59

Scheme 59

Scheme 60

Scheme 60
  1. Disconnect the battery ground cable. Vehicles with manual windows
  2. Remove the front door manual window regulator handle. Release the clip. Remove the front door manual window regulator handle. All vehicles
  3. Remove the front door latch release handle bezel. Remove the screw. Remove the front door latch release handle bezel.
  4. Remove the door handle cup screw.
  5. Remove the front door trim panel. Remove the screws. Remove the front door trim panel and disconnect the electrical connector (vehicles with power windows only).
  6. To install, reverse the removal procedure.

Vehicles with manual windows

Scheme 61

Scheme 61: Removal and Installation

Scheme 62

Scheme 62

Scheme 63

Scheme 63

Scheme 64

Scheme 64

Scheme 65

Scheme 65
  1. Remove the rear door manual window regulator handle. Release the clip. Remove the rear door manual window regulator handle. All vehicles
  2. Remove the rear door latch release handle bezel. Remove the screw. Remove the rear door latch release handle bezel.
  3. Remove the door handle cup screw.
  4. Remove the rear door sail panel.
  5. Remove the rear door trim panel. Disconnect the electrical connector (vehicles with power windows only).
  6. To install, reverse the removal procedure.
