SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Ford FS-10, Swashplate 10-Cyl. |
| Compressor Belt Deflection | (1) |
| Compressor Oil Capacity (2) | 9.0 ozs. |
| Refrigerant (R-134a) Capacity | 30.0 ozs. |
| System Operating Pressures (3) |
| High Side | 125-230 psi (8.8-16.2 kg/cm 2 ) |
| Low Side | 26-46 psi (1.8-3.2 kg/cm 2 ) |
| (1) Belt tension is automatically adjusted by belt tensioner. Tension indicator should be within specified marks. (2) Use PAG compressor oil. (3) Specification is with ambient temperature at 80°F (27°C). |
| (1) | Belt tension is automatically adjusted by belt tensioner. Tension indicator should be within specified marks. |
| (2) | Use PAG compressor oil. |
| (3) | Specification is with ambient temperature at 80°F (27°C). |
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG SYSTEM SAFETY article in GENERAL SERVICING. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bolts | 18 (25) |
| Compressor Bracket Bolts | 18 (25) |
| Compressor Bracket Nuts | 35 (48) |
| Instrument Panel Center Brace Bolts | 18 (25) |
| Manifold-To-Compressor | 15 (21) |
| Steering Column Pinch Bolt | 17 (23) |
| Steering Column Support Bolt | 12 (16) |
| Steering Column Support Nuts | 14 (19) |
| INCH Lbs. (N.m) |
| Accumulator Bracket Nut | 71 (8) |
| Condenser Mounting Brackets | 80 (9) |
| Evaporator & Heater Core Housing Support Nuts | 71 (8) |
| High Pressure Cut-Off Switch | 71 (8) |
| Instrument Panel Nut | 80 (9) |
| Instrument Panel Cowl Side Bolts | 80 (9) |
| Instrument Panel Cowl Top Bolt | 71 (8) |
| Passenger Side Air Bag Module Mounting Bolts | 71 (8) |
| Peanut Fitting Nut | 71 (8) |
| Steering Wheel Pinion Bolt | 106 (12) |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
