INTERIOR LIGHT REMOVAL/INSTALLATION
- Disconnect the negative battery cable.
- Remove the lens. (See «LENS REMOVAL NOTE»(ref-367665-S19563647832010072700000) .)
- Remove the interior light bulb.
- Remove the interior light. (See «INTERIOR LIGHT REMOVAL NOTE»(ref-367665-S25735847892010072700000) .)
- Disconnect the connector.
- Install in the reverse order of removal.
Scheme 51
Scheme 52
Scheme 52: Interior Light Removal Note
- Insert a tape-wrapped flathead screwdriver into the gap between the headliner and the interior light.
- Press the tab, and remove the interior light.
Scheme 53
Scheme 53: Lens Removal Note
- Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
Scheme 54
Scheme 54: INTERIOR LIGHT INSPECTION
Scheme 55
- Remove the interior light. (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-367665-S33165249612010072700000) .)
- Verify that the continuity between the interior light terminals is as indicated in the table. If not as indicated in the table, replace the interior light.
Scheme 56
Scheme 56: TRUNK COMPARTMENT LIGHT BULB REMOVAL/INSTALLATION
- Disconnect the negative battery cable.
- Remove the lens, then remove the trunk compartment light bulb.
- Install in the reverse order of removal.
