SYMPTOM TROUBLESHOOTING CHART POWER WINDOW SYSTEM (WITH EXTERIOR OPEN/CLOSE FUNCTION)
| No. | TROUBLESHOOTING ITEM | ACTION |
|---|---|---|
| 1 | Door glass does not move up and down in automatic mode | (See NO. 1 DOOR GLASS DOES NOT MOVE UP AND DOWN IN AUTOMATIC MODE POWER WINDOW SYSTEM (WITH EXTERIOR OPEN/CLOSE FUNCTION) .) |
| 2 | Door glass does not reverse, even when encountering a foreign object in its path. | (See NO. 2 DOOR GLASS DOES NOT REVERSE, EVEN WHEN ENCOUNTERING A FOREIGN OBJECT IN IT IS PATH POWER WINDOW SYSTEM (WITH EXTERIOR OPEN/CLOSE FUNCTION) .) |
| 3 | Door glass does not reverse, even when encountering a foreign object in its path. | (See NO. 3 DOOR GLASS REVERSES EVEN THOUGH THE GLASS DOES NOT ENCOUNTER A FOREIGN OBJECT WHILE IT IS MOVING UP IN AUTOMATIC MODE POWER WINDOW SYSTEM (WITH EXTERIOR OPEN/CLOSE FUNCTION) .) |
| 4 | Abnormal noise during the power window operation | (See NO. 4 ABNORMAL NOISE WHILE THE DOOR GLASS IS OPENING OR CLOSING POWER WINDOW SYSTEM (WITH EXTERIOR OPEN/CLOSE FUNCTION) .) |
SYMPTOM TROUBLESHOOTING CHART
Scheme 3
- Always perform basic power window system inspection before troubleshooting.
- Troubleshooting procedures provide information unique to malfunctions of the automatic window return function.
| CAUTION | If any of the following conditions continues indefinitely, the power window motor will heat up causing the protection circuit (integrated in power window motor) to operate. If this occurs, the operation of the power window motor protection circuit temporarily disables the power windows. Continuous up and down operation of the power window. Continuously pulling up the power window switch while the window glass is fully closed. Continuously pressing the power window switch while the window glass fully opened. A malfunction in the power window system will be determined and the system will shift to malfunction mode if the power windows are operated up or down using the power window switch while the power window protection circuit is operating. While the power window system is in malfunction mode, but they do not operate using the auto open/close function. The power window system reverts to normal operation after performing the Power Window Initialization Procedure. |
Note. Initial setting must be performed for the switch of each seat. If the following operations have been performed, initial setting is reset, and auto up/down and two-step down operation are disabled. Therefore, performing initial setting is necessary. Negative battery cable disconnected or power window system power supply fuse removed, (perform initial setting for each door glasses.) Power window switch connector disconnected, (perform initial setting for the switch connected with the connector)
Manual Mode Function Inspection
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Turn the power-cut switch to UNLOCK. Does each door glass move up and down in manual mode using the power window subswitch? | Yes | Go to the next step. |
| No | Inspect the following items: Power window main switch (power-cut switch system malfunction) Power window subswitch power supply fuses Power window subswitch ground wiring harness Power window switch power supply wiring harnesses Wiring harness between power window subswitch and power window motor Power window subswitch Power window motor Repair or replace the malfunctioning part, then go to the next step. | ||
| 2 | Does the driver-side door glass move up and down in manual mode using the power window main switch? | Yes | Go to the next step. |
| No | Inspect the following items: Power window main switch power supply fuses Power window main switch ground wiring harness Power window main switch power supply wiring harnesses Wiring harness between power window main switch and power window motor Power window main switch Repair or replace the malfunctioning part, then go to the next step. | ||
| 3 | Does each other door glass other than the driver-side door glass move up and down in manual mode using the power window main switch? | Yes | Go to the next step. |
| No | Perform the power window initialization procedure for any door glass that does not move up and down, and reinspect. (See POWER WINDOW INITIALIZATION PROCEDURE .) If it does not move up and down upon reinspection, inspect the following: Wiring harness between power window main switch and subswitch Repair or replace the malfunctioning part, then go to the next step. | ||
| 4 | Turn the power-cut switch to LOCK. Push/pull the power window main switch (switches for all windows in manual mode.) Does only driver-side front door glass move up and down? | Yes | Manual mode function is normal. Go to the automatic mode function inspection. |
| No | Replace the power window main switch, then go to the automatic mode function inspection (power-cut switch system malfunction.) | ||
DIAGNOSTIC PROCEDURE
Automatic Mode Function Inspection
Note. Perform the following inspection for the power window main switch and the power window subswitches for each window.
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Operate the power window switch in automatic mode. Does the door glass move up and down in automatic mode? | Yes | Go to the next step. |
| No | Door glass does not move up and down in automatic mode: Go to Step 1 of NO. 1 DOOR GLASS DOES NOT MOVE UP AND DOWN IN AUTOMATIC MODE. Door glass moves up and down in automatic mode, but door glass reverses: Go to Step 1 of NO. 3 DOOR GLASS REVERSES EVEN THOUGH THE GLASS DOES NOT ENCOUNTER A FOREIGN OBJECT WHILE IT IS MOVING UP IN AUTOMATIC MODE. | ||
| 2 | Gently pull the power window switch while the door glass is moving down in automatic mode. Does the glass stop? | Yes | Go to the next step. |
| No | Replace the power window switch, then go to the automatic door glass return function inspection. | ||
| 3 | Gently press the power window switch while the door glass is moving up in automatic mode. Does the glass stop? | Yes | Automatic mode function is normal. Go to the automatic door glass return function inspection. |
| No | Replace the power window switch, then go to the automatic door glass return function inspection. | ||
DIAGNOSTIC PROCEDURE
Automatic Door Glass Return Function Inspection
Note. Perform the following inspection for the power window main switch and the power window subswitches for each window. With the switch held at auto-up, the door glass does not automatically reverse even when a foreign object is encountered.
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Lower the door glass completely. Use the power window switch to close the door glass in automatic mode. Does the door glass automatically reverse even though the glass does not encounter a foreign object while it is moving up in automatic mode? | Yes | Go to Step 1 of NO. 3 DOOR GLASS REVERSES EVEN THOUGH THE GLASS DOES NOT ENCOUNTER A FOREIGN OBJECT WHILE IT IS MOVING UP IN AUTOMATIC MODE. |
| No | Go to the next step. | ||
| 2 | Lower the door glass completely. Take a hammer and hold it against the inside of the top of the window frame so that the door glass will hit its handle when it is closed. Raise the door glass using automatic mode. When the door glass hits the hammer handle, does it immediately reverse and move down to approx. 200 mm {7.87 in} from the completely closed position? | Yes | Automatic door glass return function inspection is normal. Go to the IG OFF timer function inspection. |
| No | Go to Step 1 of NO. 2 DOOR GLASS DOES NOT REVERSE, EVEN WHEN ENCOUNTERING A FOREIGN OBJECT IN ITS PATH. | ||
DIAGNOSTIC PROCEDURE
IG OFF Timer Function Inspection
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Close all doors. Turn the ignition switch to the ON position. In automatic mode, push down the power window main switch for the driver-side front door glass. The door glass should move down within approx. 43 s after ignition switch off. In manual mode (finger continuously depressing the power window main switch), the door glass should move down within approx. 43 s after ignition switch off. Does the driver-side front door glass move down? | Yes | Go to the next step. |
| No | Perform the driver-side power window initialization procedure, and reinspect. (See POWER WINDOW INITIALIZATION PROCEDURE .) If it does not move up and down upon reinspection, inspect the following: Wiring harness for the door open/close signal system Latch switch Repair or replace the malfunctioning part, and reinspect. If operation is not normal, replace the power window main switch, and then go to the next step. | ||
| 2 | Turn the ignition switch to the ON position. In automatic mode, pull up the power window main switch for the driver-side front door glass. The door glass does not move up within approx. 43 s after ignition switch off. Verify that driver-side front door glass does not operate. Does the driver-side front door glass move up? | Yes | Perform the driver-side power window initialization procedure, and reinspect. (See POWER WINDOW INITIALIZATION PROCEDURE .) If operation is not normal, replace the power window main switch, then go to the next step. |
| No | Go to the next step. | ||
| 3 | Turn the ignition switch to the ON position. Lower the driver-side front door glass completely. Take a hammer and hold it against the inside of the top of the door glass frame so that the door glass will hit its handle when it is closing. Raise the door glass using manual mode. When the door glass hits the hammer handle, does it immediately reverse and move down to approx. 200 mm {7.87 in} from the completely closed position? | Yes | Go to the next step. |
| No | Perform the driver-side power window initialization procedure, and reinspect. (See POWER WINDOW INITIALIZATION PROCEDURE .) If operation is not normal, replace the power window main switch, then go to the next step. | ||
| 4 | Open any door. Turn the ignition switch to the ON position. Push/pull the power window main switch for the door glass within approx. 43 s after ignition switch off. Verify that the door glass does not move up or down. Does the door glass move up or down? | Yes | Inspect the door switch and related wiring harness. If above parts are normal, replace the power window main switch, then go to the next step. If the above parts have any malfunction, repair or replace the malfunction part, then go to the next step. |
| No | Go to the next step. | ||
| 5 | Close all doors. Turn the ignition switch to the ON position. Push/pull the power window main switch for door glass after approx. 60 s after ignition switch off. Verify that the door glass does not move up or down. Does the door glass move up or down? | Yes | Perform the driver-side power window initialization procedure, and reinspect. (See POWER WINDOW INITIALIZATION PROCEDURE .) If operation is not normal, replace the power window main switch, then go to the two-step down function inspection. |
| No | The IG OFF timer function is normal. Go to the two-step down function inspection. | ||
DIAGNOSTIC PROCEDURE
Two-Step Down Function Inspection
- The distance the door glass opens can be changed using the two-step down function (approx. 20-100 mm {0.79-3.93 in}.)
- The two-step down function can be made inoperative. (The function is operative at the initial setting.)
- The two-step down function does not function during IG OFF timer.
Note. Perform the following inspection for the power window main switch and the power window subswitches for each window.
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Raise door glass completely. When the door glass is lowered using manual mode, does it move down to approx. 30 mm {1.2 in} from the completely closed position and stop for 1 s? (This inspection cannot be performed during IG OFF timer function operation.) | Yes | Two-step down function is normal. Reinspect malfunction symptoms. |
| No | Perform the power window initial setting procedure and verify auto-up/down operation. (See POWER WINDOW INITIALIZATION PROCEDURE .) If the automatic function does not operate, go to Automatic Door Glass Return Function Inspection. If the automatic function operates but the two-step down function does not, replace the power window switch. | ||
