WHEEL HUB, STEERING KNUCKLE REMOVAL/INSTALLATION
| CAUTION | Performing the following procedures without first removing the ABS wheel-speed sensor may possibly cause an open circuit in the wiring harness if it is pulled by mistake. Before performing the following procedures, disconnect the ABS wheel-speed sensor or ABS wheel-speed sensor harness connector (axle side) and fix it to an appropriate place where the sensor will not be pulled by mistake while servicing the vehicle. |
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
- After installation, inspect the front wheel alignment. (See «FRONT WHEEL ALIGNMENT»(ref-367661-S19385474912010072700000) .)
Scheme 3
Brake Caliper Component Removal Note
- Suspend the brake caliper component using a cable or equivalent.
Scheme 4
WHEEL HUB BOLT REPLACEMENT
- Remove the brake caliper component and disc plate.
- Remove the wheel hub bolt using the SST as shown in the figure.
- Place a new wheel hub bolt in the wheel hub.
- Install the wheel hub bolt by placing a proper sized washer on the hub, and tightening the nut as shown in the figure.
