ENGINE OIL REPLACEMENT [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.
CAUTIONIf engine oil is spilled on the exhaust system, wipe it off completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat. Because engine starting performance could worsen, do not use either synthetic or semi-synthetic motor oil.

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Position the vehicle on level ground.
  2. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
  3. Remove the oil filler cap.
  4. Remove the oil pan drain plug.
  5. Drain the engine oil into a container.
  6. Install the oil pan drain plug with a new washer. Oil pan drain plug tightening torque 29.4-41.2 N.m {3.00-4.20 kgf.m, 21.7-30.3 ft.lbf} NOTE: The amount of residual oil in the engine can vary according to factors such as the replacement method and oil temperature. Verify the oil level after engine oil replacement.
  7. Refill with the following type and amount of the engine oil. Engine oil specification ENGINE OIL SPECIFICATION CHART Item U.S.A. and CANADA Except U.S.A. and CANADA Engine oil grade API SL, SM or ILSAC Engine oil viscosity 5W-20 Engine oil capacity (approx. quantity) Oil replacement: 4.2 L {4.4 US qt, 3.7 lmp qt} Oil and oil filter replacement: 4.4 L {4.6 US qt, 3.9 lmp qt} Engine overhaul: 5.6 L {5.9 US qt, 4.9 lmp qt} Total (dry engine): 7.0 L {7.4 US qt, 6.2 lmp qt} (MT), 6.3 L {6.7 US qt, 5.5 lmp qt} (AT)
  8. Install the oil filler cap.
  9. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  10. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [13B-MSP]»(ref-367624-S37434359212010072700000) .)
  11. Install the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)

OIL FILTER REPLACEMENT [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.
CAUTIONWhen removing the oil filter, cover up the surrounding area with cloth to prevent oil in the filter from spilling on other parts. If engine oil is spilled on the exhaust system, wipe it off completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat.

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Remove the under cover.
  2. Remove the oil filter using the SST.
  3. Clean the installation surface of the oil filter.
  4. Apply clean engine oil to the O-ring of a new oil filter.
  5. Tighten the oil filter using the SST and according to the instructions on the package or side of the oil filter. Tightening torque (reference value) 11.7-15.7 N.m {1.20-1.60 kgf.m, 8.7-11.5 ft.lbf}
  6. Wipe off the spilled engine oil from the surrounding area.
  7. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  8. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [13B-MSP]»(ref-367624-S37434359212010072700000) .)
  9. Install the under cover.

OIL COOLER REMOVAL/INSTALLATION [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 15

Scheme 15
Scheme 15
  1. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
  2. Remove the following. Front tire (LH) Front tire (RH) (MT) Splash shield Aerodynamic undercover (See «AERODYNAMIC UNDER COVER REMOVAL/INSTALLATION»(ref-367654-S38607773612010072700000) .)
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.
  5. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  6. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [13B-MSP]»(ref-367624-S37434359212010072700000) .)

Oil Cooler Hose Removal Note

  1. Use a drain pan to catch the oil when the oil hoses are disconnected.

OIL PAN REMOVAL/INSTALLATION [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 16

Scheme 16
Scheme 16
  1. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
  2. Drain the engine oil. (See «ENGINE OIL REPLACEMENT [13B-MSP]»(ref-367624-S00267410712010072700000) .)
  3. Remove the under cover. (See «OIL FILTER REPLACEMENT [13B-MSP]»(ref-367624-S17078940142010072700000) .)
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.
  6. Refill with the specified type and amount of the engine oil. (See «ENGINE OIL REPLACEMENT [13B-MSP]»(ref-367624-S00267410712010072700000) .)
  7. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  8. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [13B-MSP]»(ref-367624-S37434359212010072700000) .)

Scheme 17

Scheme 17: Oil Pan Removal Note
Scheme 17: Oil Pan Removal Note
  1. Remove the oil pan using a separator tool.

Oil Pan Installation Note

CAUTIONApply the silicon sealant in a single, unbroken line around the whole perimeter. Install the oil pan within 5 min after applying the silicone sealant. Using bolts with the old seal adhering could cause cracks in the housing.

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Completely clean and remove any oil, dirt, sealant or other foreign material that may be adhering to the oil pan upper block and oil pan.
  2. When reusing the oil pan installation bolts, clean any old sealant from the bolts.
  3. Apply silicone sealant to the areas as shown in the figure.
  4. Install the oil pan to the oil pan upper block.
  5. Tighten the oil pan installation bolts. Tightening torque 7.8-10.8 N.m {79.6-110.1 kgf.cm, 69.1-95.5 in.lbf}

OIL PAN UPPER BLOCK REMOVAL/INSTALLATION [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 20

Scheme 20
Scheme 20
  1. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  4. Drain the engine oil. (See «ENGINE OIL REPLACEMENT [13B-MSP]»(ref-367624-S00267410712010072700000) .)
  5. Remove the under cover. (See «OIL FILTER REPLACEMENT [13B-MSP]»(ref-367624-S17078940142010072700000) .)
  6. Remove the oil pan. (See «OIL PAN REMOVAL/INSTALLATION [13B-MSP]»(ref-367624-S15651734752010072700000) .)
  7. Remove in the order indicated in the table.
  8. Install in the reverse order of removal.
  9. Refill with the specified type and amount of the engine oil. (See «ENGINE OIL REPLACEMENT [13B-MSP]»(ref-367624-S00267410712010072700000) .)
  10. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  11. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [13B-MSP]»(ref-367624-S37434359212010072700000) .)

Oil Pan Upper Block Component Removal Note

CAUTIONBe careful not to damage the installation surface of the housing and oil pan upper block.
  1. Remove the oil pan upper block component using a separator tool.

Oil Pan Upper Block Component Installation Note

CAUTIONApply the silicon sealant in a single, unbroken line around the whole perimeter. Install the oil pan upper block within 5 min after applying the silicone sealant. Using bolts with the old seal adhering could cause cracks in the housing.

Scheme 21

Scheme 21
Scheme 21
  1. Completely clean and remove any oil, dirt, sealant or other foreign material that may be adhering to the oil pan upper block and housing.
  2. When reusing the oil pan upper block installation bolts, clean any old sealant from the bolts.
  3. Apply silicone sealant to the areas as shown in the figure. CAUTION: Apply silicone sealant to the outer circumference of the bolt hole at locations A shown in the figure. Thickness 2.5-6.5 mm {0.10-0.26 in}
  4. Install the oil pan upper block component to the housing.
  5. Tighten the oil pan upper block installation bolts. Tightening torque 18.6-25.5 N.m {1.9-2.6 kgf.m, 13.8-18.8 ft.lbf}

METERING OIL PUMP REMOVAL/INSTALLATION [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 22

Scheme 22
Scheme 22
  1. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  4. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [13B-MSP]»(ref-367619-S09402478192010072700000) .)
  5. Remove the front suspension tower bar. (MT) (See «FRONT SUSPENSION TOWER BAR REMOVAL/INSTALLATION [MT]»(ref-367650-S11111731452010072700000) .)
  6. Remove the extension manifold (upper, lower) and oil filler pipe. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S14848159782010072700000) .)
  7. Remove the oil pressure sensor. (See «OIL PRESSURE SENSOR REMOVAL/INSTALLATION [13B-MSP]»(ref-367617-S26296152312010072700000) .)
  8. Remove in the order indicated in the table.
  9. Install in the reverse order of removal.
  10. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  11. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [13B-MSP]»(ref-367624-S37434359212010072700000) .)
  12. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [13B-MSP]»(ref-367619-S36400923022010072700000) .)

Scheme 23

Scheme 23: Oil Hose Removal Note
Scheme 23: Oil Hose Removal Note
  1. Insert a flathead screwdriver into the notch of the oil hose retainer, and pull up the retainer in the direction of the arrow shown in the figure to unlock. CAUTION: Cover the areas around the oil hoses and metering oil pumps before disconnecting the oil hoses so that the oil remaining in the oil hoses and the metering oil pumps does not get on surrounding parts.
  2. Disconnect the oil hose.

Scheme 24

Scheme 24: Oil Hose Installation Note
Scheme 24: Oil Hose Installation Note
  1. Verify that the oil hose retainer is in the unlocked position.
  2. Insert the oil hose into the pipe completely.
  3. Press down the retainer to lock the oil hose.
  4. Move the oil hose back and forth in the axial direction a few times and verify that it is securely locked.

OIL NOZZLE REMOVAL/INSTALLATION [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 25

Scheme 25
Scheme 25
  1. Complete the BEFORE SERVICE PRECAUTION. (See «BEFORE SERVICE PRECAUTION [13B-MSP]»(ref-367620-S18319994272010072700000) .)
  2. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
  3. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  4. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  5. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [13B-MSP]»(ref-367619-S09402478192010072700000) .)
  6. Remove the front suspension tower bar. (MT) (See «FRONT SUSPENSION TOWER BAR REMOVAL/INSTALLATION [MT]»(ref-367650-S11111731452010072700000) .)
  7. Remove the extension manifold (upper, lower) and oil filler pipe. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S14848159782010072700000) .)
  8. Remove the metering oil pump No. 1 and No. 2. (See «METERING OIL PUMP REMOVAL/INSTALLATION [13B-MSP]»(ref-367624-S10122538502010072700000) .)
  9. Remove the fuel injector and fuel distributor component (intake manifold side.) (See «FUEL INJECTOR REMOVAL/INSTALLATION [13B-MSP]»(ref-367620-S22529116302010072700000) .)
  10. Remove in the order indicated in the table.
  11. Install in the reverse order of removal.
  12. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  13. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [13B-MSP]»(ref-367624-S37434359212010072700000) .)
  14. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [13B-MSP]»(ref-367619-S36400923022010072700000) .)

Oil Tube Removal Note

  1. Record the routing of the oil tubes when removing so that they can be re-installed in the same routing condition.
  2. Remove the oil tubes.

Scheme 26

Scheme 26: Metering Oil Pump Voltage Inspection
Scheme 26: Metering Oil Pump Voltage Inspection
  1. Disconnect the metering oil pump No. 1 and No. 2 connectors (2 terminals.) (See «METERING OIL PUMP REMOVAL/INSTALLATION [13B-MSP]»(ref-367624-S10122538502010072700000) .)
  2. Measure the voltage at terminal B using a tester. If not as specified, repair or replace the related wiring harnesses. Metering oil pump No. 1, No. 2 standard voltage B+ [IG-ON, 20°C {68°F}]

Scheme 27

Scheme 27: Metering Oil Pump Resistance Inspection
Scheme 27: Metering Oil Pump Resistance Inspection
  1. Disconnect the metering oil pump No. 1 and No. 2 connectors (2 terminals.) (See «METERING OIL PUMP REMOVAL/INSTALLATION [13B-MSP]»(ref-367624-S10122538502010072700000) .)
  2. Measure the resistance between terminals A-B using a tester. If not within the specification, replace the metering oil pump. Metering oil pump No. 1, No. 2 standard resistance 3.6-4.1 ohms [20°C {68°F}]

Scheme 28

Scheme 28: Oil Nozzle Inspection
Scheme 28: Oil Nozzle Inspection
  1. Remove the oil nozzle. (See «OIL NOZZLE REMOVAL/INSTALLATION [13B-MSP]»(ref-367624-S19890216522010072700000) .)
  2. Blow compressed air into area A while applying water to area B and verify that bubbles form on area B. If not as specified, replace the oil nozzle. Specification SPECIFICATION CHART Compressed air (kPa {kgf/cm 2 , psi}) Condition Below 200 {2.04, 29.0} Bubbles not exist 350 {3.57, 50.8} or more Bubbles exist

OIL CONTROL VALVE (OCV) REMOVAL/INSTALLATION [13B-MSP]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 29

Scheme 29
Scheme 29
  1. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
  4. Remove the air hose and air cleaner component. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S14848159782010072700000) .)
  5. Remove the throttle body with the water hoses still connected. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S14848159782010072700000) .)
  6. Remove the ignition coil and ignition coil bracket as a single unit.
  7. Remove in the order indicated in the table.
  8. Install in the reverse order of removal.
