FUSE SERVICE CAUTIONS
| CAUTION | Determine and correct the cause of the burnt fuse before replacing it with the specified type. If the fuse is replaced before doing this, it may burn again. |
Scheme 10
- Disconnect the negative battery cable.
- Remove the main fuse block cover.
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 11
- Press the tabs in the direction indicated by the arrows, lift the main fuse block, and then remove the bolt.
Relay type
| Terminal type | Part name | |
|---|---|---|
| 4 terminals | Type A | Main relay TNS relay ACC relay Front fog light relay Drive-by-wire relay Cooling fan relay No. 1 Cooling fan relay No. 2 Cooling fan relay No. 4 Cooling fan relay No. 5 A/C relay Blower relay Rear window defroster relay Fuel pump speed control relay Fuel pump relay Horn relay Trunk lid opener relay |
| Type B | Ignition relay Starter relay Headlight relay Air pump relay | |
| 5 terminals | Type C | Cooling fan relay No. 3 |
RELAY TERMINAL REFERENCE
Type A
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
Scheme 12
Scheme 13
Type B
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
Scheme 14
Scheme 15
Type C
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
