OIL SEAL (COMPANION FLANGE) REPLACEMENT

1. Remove the rear differential. (See «REAR DIFFERENTIAL REMOVAL/INSTALLATION»(ref-367659-S32650357742010072700000) .)
2. Replace the oil seal (companion flange) referring to the rear differential disassembly/assembly procedure. (See «REAR DIFFERENTIAL DISASSEMBLY»(ref-367659-S06796781172010072700000) .) (See «REAR DIFFERENTIAL ASSEMBLY»(ref-367659-S31118430482010072700000) .)
3. Install the rear differential. (See «REAR DIFFERENTIAL REMOVAL/INSTALLATION»(ref-367659-S32650357742010072700000) .)

1. Drain the rear differential oil.
2. Remove the rear auto leveling sensor. (See «REAR AUTO LEVELING SENSOR REMOVAL/INSTALLATION»(ref-367665-S27440960862010072700000) .)
3. Remove the tunnel member. (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367625-S05852593282010072700000) .)
4. Remove the middle pipe and main silencer. (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367625-S05852593282010072700000) .)
5. Remove the TWC. (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367625-S05852593282010072700000) .)
6. Remove the heat insulator. (See «TRANSMISSION REMOVAL/INSTALLATION [P66M-D]»(ref-367635-S07700204162010072700000) .) (See «AUTOMATIC TRANSMISSION REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S25847343162010072700000) .)
7. Remove the propeller shaft. (See «PROPELLER SHAFT REMOVAL/INSTALLATION»(ref-367656-S01250541202010072700000) .)
8. Remove in the order indicated in the table.
9. Install in the reverse order of removal.
10. Add rear differential oil. (See «DIFFERENTIAL OIL REPLACEMENT»(ref-367659-S22017478362010072700000) .)
11. Inspect the rear wheel alignment. (See «REAR WHEEL ALIGNMENT»(ref-367661-S23950863502010072700000) .)

Scheme 11

Brake Caliper Component Removal Note

1. Suspend the brake calliper component using a cable or equivalent.
2. Temporarily tighten the wheel nut to prevent the disc plate from falling off.

Scheme 12

Scheme 13

1. Insert a tire lever or equivalent between the rear differential and differential side outer ring, and remove the rear drive shaft. CAUTION: The sharp edges of the drive shaft can slice or puncture the oil seal. Be careful not to damage the oil seal when removing the drive shaft from the differential.
2. Pull the rear drive shaft and rear knuckle component to the outer side, and detach the rear drive shaft from the rear differential.
3. To hold the rear drive shaft and rear knuckle component, install the rear lateral link (upper) to the rear knuckle temporarily after disconnecting the rear drive shaft.

Scheme 14

1. Support the transmission using a jack.
2. Support the rear differential using a jack.
3. Remove the power plant frame.

Scheme 15

1. Support the rear differential using a jack.
2. Remove the differential mounting installation bolts.
3. Lower the jack slowly and remove the rear differential.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Support the rear differential using a jack.
2. Temporarily tighten the differential mounting installation bolts.
3. Install the power plant frame.
4. Install the plate.
5. Temporarily tighten the bolts and nuts as shown in the figure.
6. Tighten the nut B until the power plant frame is seated in the rear differential.
7. Install the heat insulator, TWC, middle pipe, main silencer and front tunnel member. (See «TRANSMISSION REMOVAL/INSTALLATION [P66M-D]»(ref-367635-S07700204162010072700000) .), (See «AUTOMATIC TRANSMISSION REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S25847343162010072700000) .), (See «AUTOMATIC TRANSMISSION REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S25847343162010072700000) .), (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367625-S05852593282010072700000) .)
8. Raise the power plant frame front end (transmission side) or transmission using a jack so that dimension A (between power plant frame lower surface and front tunnel member lower surface) shown in the figure is within the adjustment value. Adjustment dimension A 55-57 mm {2.17-2.24 in} NOTE: When raising the power plant frame without a transmission jack, use bolts (M12x1 .25) with a thread length of 55 mm {2.17 in} or more. Tighten the bolts from the underside of the front tunnel member as shown in the figure and raise the power plant frame. When using bolts, the underside of the power plant frame could be damaged. Affix tape to the underside of the frame to prevent damage. If there is the possibility of age-related bending/deterioration of the mount, adjust dimension A to approx. 15 mm {0.59 in} higher than the adjustment value to facilitate obtaining the specification.
9. Tighten the bolts and nuts on the rear differential side in the order shown in the figure. TIGHTENING TORQUE SPECIFICATION Step Bolt, nut Tightening torque (N.m {kg.m, ft.lb} 1 A 126.0-154.0 {12.85-15.70, 93.0-113.5} 2 B 126.0-154.0 {12.85-15.70, 93.0-113.5} 3 C 126.0-154.0 {12.85-15.70, 93.0-113.5} 4 F 74.5-93.2 {7.60-9.50, 55.0-68.7}
10. Tighten the bolts and nuts on the transmission side as shown in the figure. Tightening torque 126.0-154.0 N.m {12.9-15.7 kg.m, 93.0- 113.5 ft.lb}
11. Verify that dimension A is within the specification with the transmission jack and the adjustment bolt removed. If not within the specification, adjust dimension A again. Standard dimension A 48.4-56.4 mm {1.91-2.22 in}
12. Temporarily loosen the differential mount installation bolts, straighten the differential mounting bracket bushings, and then tighten the differential mounting installation bolts again to the specified torque. CAUTION: Never support the rear differential using a jack when tightening the differential mounting installation bolts. Otherwise, the differential mounting bracket bushings will twist and cause an abnormal noise while the vehicle is moving. Tightening torque 74.5-105.0 N.m {7.60-10.70 kg.m, 55.0-77.44 ft.lb} Rear Drive Shaft, Rear Knuckle Component Installation Note Install a new drive shaft clip to the clip groove at the top of the rear drive shaft with the clip opening facing upward and the clip width within the specification. Standard 32 mm {1.3 in} After installing the clip, measure the outer diametric if it exceeds the specification, reinstall a new clip. Apply differential oil to the differential oil seal lip. CAUTION: The sharp edges of the rear drive shaft can slice or puncture the oil seal Be careful not to damage the oil seal when installing the rear drive shaft from the rear differential. Insert the rear drive shaft into the rear differential with the clip opening facing upward. After installation, verify that the rear drive shaft is securely held by the clip by pulling the outer ring on the differential side towards the axle.

Scheme 22

1. Disassemble in the order indicated in the table.

Scheme 23

1. Install the differential component to the SSTs.

Scheme 24

1. Mark the bearing cap and differential carrier for proper installation.

Scheme 25

1. Remove the adjustment shim using a flathead screwdriver.
2. Put left and right identification marks on the removed adjustment shims and side bearing outer races.

Scheme 26
