Automatic Transmission Shift Mechanism: Overview Mazda RX-8 I рестайлинг

Scheme 538

Scheme 539

1. Turn the ignition switch to the ON position (engine OFF)
2. With the brake pedal depressed, verify that there is a "click" at each range when shifted.
3. Verify that the selector lever can be shifted.
4. Verify that there is a "click" at each position when shifted from the P position to the M range.
5. Verify that the positions of the selector lever and the indicator are aligned. If there is any malfunction, adjust the TR switch. (See «TRANSMISSION RANGE (TR) SWITCH ADJUSTMENT [SJ6A-EL]»(ref-367646-S23381336062010072700000) .)
6. Verify that the vehicle operates in each selected range.

Scheme 540
