Dynamic Stability Control System: Diagnosis Mazda RX-8 I

DSC HU/CM INSPECTION

1. Disconnect the DSC HU/CM connector.
2. Connect the negative battery cable.
3. Attach the tester lead to the DSC HU/CM harness side connector, then inspect voltage, continuity or resistance according to the «standard (reference value)»(ref-178171-S36547285782005061200000) .

Scheme 105

Scheme 106

Scheme 107

Scheme 108

FRONT ABS WHEEL-SPEED SENSOR INSPECTION

1. Inspect the front ABS wheel-speed sensor in the same order of vehicles with ABS. (See FRONT ABS WHEEL-SPEED SENSOR INSPECTION .)

REAR ABS WHEEL-SPEED SENSOR INSPECTION

1. Inspect the rear ABS wheel-speed sensor in the same order of vehicles with ABS. (See REAR ABS WHEEL-SPEED SENSOR INSPECTION .)
