Maintenance Information: Overview Mazda Protege BH

Fuse & Circuit Breaker Identification

1. 1 - 30 Amp (Pink) Headlights - High Beams
2. 2 - 30 Amp (Pink) Fuel Injection System
3. 3 - 80 Amp (Black) Main Protection Of All Circuits
4. 4 - 30 Amp (Pink) Additional Cooling Fan (A/C)
5. 5 - 50 Amp (Red) Radio, Sunroof, Turn, Meter, Engine, Power Window, Headlight Cleaner, Wiper Fuses, Ignition System
6. 6 - 60 Amp (Yellow) ABS System
7. 7 - 60 Amp (Yellow) Room, Door Lock, Stoplight, Power Windows
8. 8 - 30 Amp (Pink) Cooling Fan
9. 9 - 15 Amp (Blue) Hazard, Turn Signals
10. 10 - 10 Amp (Red) Air Conditioner
11. 11 - Empty
12. 12 - 15 Amp (Blue) Taillights, Parking Lights, Instrument Panel Illumination License Plate Lights, Glove Box Light
13. 13 - 10 Amp (Red) Engine Control Unit (ECU)
14. 14 - Empty

Scheme 1

1. 1 - Not Used
2. 2 - 15 Amp (Blue) Trunk Light, Interior Lights, Vanity Mirror Lights
3. 3 - 15 Amp (Blue) Sunroof
4. 4 - 15 Amp (Blue) Gauges, Back-up Lights, Turn Signals, Cruise Control
5. 5 - 30 Amp (Green) Power Windows
6. 6 - 10 Amp (Red) Horn
7. 7 - Not Used
8. 8 - 10 Amp (Red) Rear Wiper/Washer
9. 9 - 20 Amp (Yellow) Rear Window Defogger
10. 10 - 10 Amp (Red) Air Conditioner
11. 11 - Not Used
12. 12 - Not Used
13. 13 - 10 Amp (Red) Engine Control System, Air Bag, ABS
14. 14 - 20 Amp (Yellow) Windshield Wiper/Washer
15. 15 - 30 Amp (Green) Power Windows
16. 16 - Not Used
17. 17 - Not Used
18. 18 - 15 Amp (Blue) Radio (Cassette)
19. 19 - 10 Amp (Red) Turn Signals Lights
20. 20 - Not Used
21. 20 - 20 Amp (Yellow) Windshield Wiper/Washer
22. 21 - 15 Amp (Blue) Brake lights
23. 22 - Not Used
24. 23 - 15 Amp (Blue) Cigar Lighter
25. 24 - Not Used
26. 25 - 20 Amp (Yellow) Power Door Locks
27. 26 - Not Used
28. 27 - 10 Amp (Red) Spare
29. 28 - 15 Amp (Blue) Spare
30. 29 - 40 Amp (Green) Heater, Air Conditioner
