Engine Controls - Specifications Mazda Protege BG

Specifications 12 illustrations ~486 words

INTRODUCTION

Use the specifications in this quick-reference article if you are familiar with an on-vehicle service or adjustment procedure and you only need a specification.

CAPACITIES

ApplicationAmp Hr. Rating
B220050
B2600i
Standard50
Heavy Duty65
Miata32
MPV
Standard50
Heavy Duty65
MX-6
Standard50
Heavy Duty55
Navajo(1)
Protege
Standard50
Heavy Duty60
RX7
Standard55
Heavy Duty66
32350
626
Standard50
Heavy Duty55
929
Standard50
Heavy Duty65
(1) Battery is rated at 650 cold cranking amps (standard) and 850 cold cranking amps (heavy duty).
(1)Battery is rated at 650 cold cranking amps (standard) and 850 cold cranking amps (heavy duty).

BATTERY SPECIFICATIONS

ApplicationQuantity
Crankcase (Includes Filter)
B22004.3 Qts. (4.1L)
B2600i5.0 Qts. (4.7L)
Miata3.6 Qts. (3.4L)
MPV
2.6L5.0 Qts. (4.7L)
3.0L5.1 Qts. (4.8L)
MX-64.3 Qts. (4.1L)
Navajo5.0 Qts. (4.7L)
Protege4.0 Qts. (3.8L)
RX74.9 Qts. (4.6L)
3233.4 Qts. (3.2L)
6264.3 Qts. (4.1L)
9295.1 Qts. (4.8L)
Cooling System (Includes Heater)
B22007.9 Qts. (7.5L)
B2600i7.9 Qts. (7.5L)
Miata6.3 Qts. (6.0L)
MPV
2.6L
W/ A/T7.6 Qts. (7.2L)
W/ M/T7.2 Qts. (6.8L)
3.0L
W A/T10.3 Qts. (9.7L)
W/ M/T10.1 Qts. (9.6L)
MX-67.9 Qts. (7.5L)
Navajo
With A/C8.6 Qts. (8.1L)
Without A/C7.8 Qts. (7.4L)
Protege
W/ A/T6.3 Qts. (6.0L)
W/ M/T5.3 Qts. (5.0L)
RX7
Non-Turbo7.7 Qts. (7.3L)
Turbo9.2 Qts. (8.7L)
6267.9 Qts. (7.5L)
323
W/ A/T6.3 Qts. (6.0L)
W/ M/T5.3 Qts. (5.0L)
9299.9 Qts. (9.4L)
Manual Transaxle
MX-6 (1)
Non-Turbo3.5 Qts. (3.3L)
Turbo3.9 Qts. (3.7L)
Protege
DOHC (1)3.6 Qts. (3.4L)
SOHC
2WD (2)2.8 Qts. (2.6L)
4WD (3)2.7 Qts. (2.5L)
323 (2)2.8 Qts. (2.6L)
626 (1)
Non-Turbo3.5 Qts. (3.3L)
Turbo3.9 Qts. (3.7L)
Manual Transmission (4)
B2200
4-Spd.1.8 Qts. (1.7L)
5-Spd.2.1 Qts. (2.0L)
B2600i (1)
2WD3.0 Qts. (2.8L)
4WD3.4 Qts. (3.2L)
Miata2.1 Qts. (2.0L)
MPV
2WD2.6 Qts. (2.5L)
4WD3.0 Qts. (2.8L)
Navajo2.8 Qts. (2.6L)
RX72.6 Qts. (2.5L)
Automatic Transaxle (ATF Dexron-II) (5)
MX-67.2 Qts. (6.8L)
Protege
2WD6.1 Qts. (5.8L)
4WD7.0 Qts. (6.6L)
3236.1 Qts. (5.8L)
6267.2 Qts. (6.8L)
Automatic Transmission (ATF Dexron-II) (6)
B2200, B2600i, Miata & MPV4.2 Qts. (4.0L)
Navajo3.0 Qts. (2.8L)
RX74.2 Qts. (4.0L)
9297.7 Qts. (7.3L)
Front Differential (7)
B2600i1.6 Qts. (1.5L)
MPV1.8 Qts. (1.7L)
Navajo1.7 Qts. (1.6L)
Rear Differential (7)
B22001.3 Qts. (1.2L)
B2600i1.8 Qts. (1.7L)
Miata.69 Qts. (.65L)
MPV1.6 Qts. (1.5L)
Navajo2.6 Qts. (2.5L)
Protege.69 Qts. (.65L)
RX7
Non-Turbo1.4 Qts. (1.3L)
Turbo1.5 Qts. (1.4L)
323.69 Qts. (.65L)
9291.4 Qts. (1.3L)
Transfer Case (8)
B2600i2.1 Qts. (2.0L)
MPV1.6 Qts. (1.5L)
Navajo1.3 Qts. (1.2L)
Protege.53 Qts. (.5L)
(1) For all-season conditions, use SAE 75W-90 or ATF Dexron-II. For temperatures greater than 0°F (-18°C), use SAE 80W-90 or SAE 90. (2) Use SAE 75W-90. (3) For all-season conditions, use SAE 75W-90. If temperature is below 0°F (-18°C), use ATF Dexron-II. (4) On Navajo, use SAE 80W-90 or SAE 75W-90. On all other models, use SAE 75W-90 for all-season conditions, and SAE 80W-90 for temperatures greater than 50°F (10°C). (5) Specification is total fluid capacity of transaxle, not refill capacity after pan removal. (6) On 929, specification is total fluid capacity. On all other models, specification is the amount needed to refill transmission after pan removal. Mazda calls this "replacement fluid capacity" in their maintenance tables and "pan" (as opposed to "total") in their transmission section. (7) On Navajo, use SAE 90. On all other models, use SAE 90 for temperatures greater than 0°F (-18°C), and SAE 80W for temperatures less than 0°F (-18°C). (8) On Navajo, use Mercon ATF. On Protege, use SAE 90 for temperatures greater than 0°F (-18°C), and SAE 80W for temperatures less than 0°F (-18°C). On all other models, use SAE 75W-90 or ATF Dexron-II for all-season conditions, and SAE 80W-90 or SAE 90 for temperatures greater than 0°F (-18°C).
(1)For all-season conditions, use SAE 75W-90 or ATF Dexron-II. For temperatures greater than 0°F (-18°C), use SAE 80W-90 or SAE 90.
(2)Use SAE 75W-90.
(3)For all-season conditions, use SAE 75W-90. If temperature is below 0°F (-18°C), use ATF Dexron-II.
(4)On Navajo, use SAE 80W-90 or SAE 75W-90. On all other models, use SAE 75W-90 for all-season conditions, and SAE 80W-90 for temperatures greater than 50°F (10°C).
(5)Specification is total fluid capacity of transaxle, not refill capacity after pan removal.
(6)On 929, specification is total fluid capacity. On all other models, specification is the amount needed to refill transmission after pan removal. Mazda calls this "replacement fluid capacity" in their maintenance tables and "pan" (as opposed to "total") in their transmission section.
(7)On Navajo, use SAE 90. On all other models, use SAE 90 for temperatures greater than 0°F (-18°C), and SAE 80W for temperatures less than 0°F (-18°C).
(8)On Navajo, use Mercon ATF. On Protege, use SAE 90 for temperatures greater than 0°F (-18°C), and SAE 80W for temperatures less than 0°F (-18°C). On all other models, use SAE 75W-90 or ATF Dexron-II for all-season conditions, and SAE 80W-90 or SAE 90 for temperatures greater than 0°F (-18°C).

FLUID CAPACITIES

SERVICE INTERVALS & SPECIFICATIONS

ComponentMiles
Air Filter30,000
Camshaft Timing Belt60,000
Coolant30,000
Fuel Filter
B2200 (Carbureted)30,000
All Others60,000
Oil
Non-Turbo7500
Turbo5000
Oil Filter
Non-Turbo
RX715000
All Others7500
Turbo5000
Spark Plugs30,000

REPLACEMENT INTERVALS

Application(1) Deflection In. (mm)
Air Pump
RX723/64-7/16 (9-11)
Alternator
B22009/32-5/16 (7-8)
B2600i25/64-15/32 (10-12)
Miata5/16-23/64 (8-9)
MPV
2.6L25/64-15/32 (10-12)
3.0L23/64-25/64 (9-10)
MX-6 & 62615/64-5/16 (6-8)
Navajo(2)
Protege & 3235/16-23/64 (8-9)
RX715/32-19/32 (12-15)
92923/64-25/64 (9-10)
A/C Compressor
B220025/64-15/32 (10-12)
B2600i5/16-25/64 (8-10)
Miata5/16-23/64 (8-9)
MPV
2.6L5/16-25/64 (8-10)
3.0L11/64-13/64 (4.5-5)
MX-6 & 6269/32-23/64 (7-9)
Navajo(2)
Protege & 3235/16-23/64 (8-9)
RX715/64-5/16 (6-8)
9299/32-23/64 (7-9)
Power Steering
B22009/32-5/16 (7-8)
B2600i9/32 (7)
Miata5/16-23/64 (8-9)
MPV9/32 (7)
MX-6 & 6265/16-25/64 (8-10)
Navajo(2)
Protege & 3235/16-23/64 (8-9)
RX77/16-33/64 (11-13)
9299/32-23/64 (7-9)
(1) Measure belt deflection by applying moderate pressure (about 22 lbs., or 10 kg) to belt, midway between pulleys. (2) Navajo is equipped with automatic belt tensioner.
(1)Measure belt deflection by applying moderate pressure (about 22 lbs., or 10 kg) to belt, midway between pulleys.
(2)Navajo is equipped with automatic belt tensioner.

DRIVE BELT ADJUSTMENT (NEW BELT)

ENGINE COMPRESSION

Note. Compression Tester (49-F018-9A0) or equivalent must be used to test compression on RX7.

RX7

  1. Warm engine to normal operating temperature. Disconnect crank angle sensor connector. Hold throttle plate fully open. Remove both trailing spark plugs (the 2 top spark plugs). Connect Compression Tester (49-F018-9A0) to upper spark plug hole of front rotor housing.
  2. Crank engine for 5-10 seconds at specified cranking speed. Note the compression of the 3 combustion chambers. Repeat procedure at the rear rotor housing.

Except RX7

  1. Warm engine to normal operating temperature. Remove all spark plugs. On Navajo, use remote starter switch to crank engine (DO NOT crank engine with ignition switch). On all other models, disconnect ignition coil primary wire connector.
  2. On all models, hold throttle plate fully open. Crank engine at specified cranking speed.
ApplicationSpecification
B22008.6:1
B2600i8.4:1
Miata
Automatic Transmission9.4:1
Manual Transmission9.0:1
MPV
2.6L8.4:1
3.0L8.5:1
MX-6
Non-Turbo8.6:1
Turbo7.8:1
Navajo9.0:1
Protege
DOHC9.0:1
SOHC8.9:1
RX7
Non-Turbo9.7:1
Turbo9.0:1
3239.3:1
626
Non-Turbo8.6:1
Turbo7.8:1
929
DOHC8.9:1
SOHC8.5:1

COMPRESSION RATIO

ApplicationSpecification
Compression Pressure
B2200173 psi (12.2 kg/cm 2 ) @ 300 RPM
B2600i182 psi (12.8 kg/cm 2 ) @ 270 RPM
Miata192 psi (13.5 kg/cm 2 ) @ 300 RPM
MPV
2.6L185 psi (13.0 kg/cm 2 ) @ 280 RPM
3.0L164 psi (11.5 kg/cm 2 ) @ 300 RPM
MX-6
Non-Turbo162 psi (11.4 kg/cm 2 ) @ 270 RPM
Turbo139 psi (9.8 kg/cm 2 ) @ 260 RPM
Navajo(1)
Protege
DOHC182 psi (12.8 kg/cm 2 ) @ 300 RPM
SOHC173 psi (12.2 kg/cm 2 ) @ 300 RPM
RX785 psi (6.0 kg/cm 2 ) @ 250 RPM
323192 psi (13.5 kg/cm 2 ) @ 300 RPM
626
Non-Turbo162 psi (11.4 kg/cm 2 ) @ 270 RPM
Turbo139 psi (9.8 kg/cm 2 ) @ 260 RPM
929
DOHC179 psi (12.6 kg/cm 2 ) @ 300 RPM
SOHC164 psi (11.5 kg/cm 2 ) @ 300 RPM
B2200121 psi (8.5 kg/cm 2 ) @ 300 RPM
B2600i142 psi (10.0 kg/cm 2 ) @ 280 RPM
Miata135 psi (9.5 kg/cm 2 ) @ 300 RPM
MPV
2.6L142 psi (10.0 kg/cm 2 ) @ 280 RPM
3.0L121 psi (8.5 kg/cm 2 ) @ 300 RPM
MX-6
Non-Turbo114 psi (8.0 kg/cm 2 ) @ 270 RPM
Turbo98 psi (6.9 kg/cm 2 ) @ 260 RPM
Navajo(1)
Protege
DOHC128 psi (9.0 kg/cm 2 ) @ 300 RPM
SOHC121 psi (8.5 kg/cm 2 ) @ 300 RPM
RX743 psi (3.0 kg/cm 2 ) @ 250 RPM
323135 psi (9.5 kg/cm 2 ) @ 300 RPM
626
Non-Turbo114 psi (8.0 kg/cm 2 ) @ 270 RPM
Turbo98 psi (6.9 kg/cm 2 ) @ 260 RPM
929
DOHC125 psi (8.8 kg/cm 2 ) @ 300 RPM
SOHC114 psi (8.0 kg/cm 2 ) @ 300 RPM
Maximum Variation Between Cylinders
Miata, Protege & 32328 psi (2.0 kg/cm 2 )
Navajo(2)
RX721 psi (1.5 kg/cm 2 )
All Others(1)
(1) Information is not available. (2) Measurement of lowest cylinder must be within 75 percent of highest cylinder.
(1)Information is not available.
(2)Measurement of lowest cylinder must be within 75 percent of highest cylinder.

COMPRESSION PRESSURE SPECIFICATIONS

VALVE CLEARANCE

Note. All piston engines are equipped with hydraulic valve lash adjusters. Valve clearance is not adjustable.

IGNITION COIL

ApplicationPrimarySecondary
B2200
Carbureted1.0-1.36000-30,000
PFI.81-.996000-30,000
B2600i
Left Side.77-.956000-30,000
Right Side900-1100N/A
Miata.78-.9411,200-15,200
MPV
2.6L
Left Side.77-.956000-30,000
Right Side900-1100N/A
3.0L.81-.996000-30,000
MX-6 & 626
Non-Turbo.77-.9510,300-13,900
Turbo.72-.8810,300-13,900
Navajo.5(1)
Protege & 323.81-.9910,000-16,000
RX7Less than 1.0(2)
929.72-.8810,000-30,000
(1) Information is not available. (2) Further testing of the ignition coil requires use of Ignitor Tester (49-F018-002). See appropriate SYSTEM/COMPONENT TESTS article in the ENGINE PERFORMANCE section.
(1)Information is not available.
(2)Further testing of the ignition coil requires use of Ignitor Tester (49-F018-002). See appropriate SYSTEM/COMPONENT TESTS article in the ENGINE PERFORMANCE section.

IGNITION COIL RESISTANCE

DISTRIBUTOR SENSORS

Note. If models are not listed in tables, distributor and crank angle sensor testing information is not available.

ApplicationOhms
B2200 (Carbureted)900-1200
MPV (3.0L)900-1200
MX-6 & 626
Non-Turbo900-1200
Turbo (Check Ignitor Terminals)
"A" & "B"210-260
"C" & "D"210-260
"E" & "F"210-260

DISTRIBUTOR PICK-UP COIL RESISTANCE

ApplicationOhms
RX7 (Check 4-way connector terminals)
Green & Black Wires110-210
Red & White Wires110-210

CRANK ANGLE SENSOR RESISTANCE

HIGH TENSION WIRE RESISTANCE

High tension wire resistance should not exceed 4900 ohms per foot (7000 ohms per foot on Navajo).

High Tension Wire Routing

For RX7 high tension wire routing (Scheme 1)

Scheme 1

Scheme 1: High Tension Wire Routing
Scheme 1: High Tension Wire Routing

SPARK PLUGS

ApplicationNGK No.
B2200
CarburetedBPR5ES or BPR6ES
PFIBPR5ES-11 or BPR6ES-11
B2600iZFR5F-11 or ZFR6F-11
MiataBKR5E-11, BKR6E-11 or BKR7E-11
MPVZFR5F-11 or ZFR6F-11
MX-6 & 626ZFR5F-11, ZFR6F-11 or ZFR7F-11
Navajo(1)
Protege
DOHCBKR5E-11, BKR6E-11 or BKR7E-11
SOHCBKR5E-11 or BKR6E-11
323BPR5ES-11 or BPR6ES-11
(2) RX7
LeadingBUR7EQ
TrailingBUR9EQ
929
DOHCZFR5F-11 or ZFR6F-11
SOHCZFR5F-11, ZFR6F-11 or ZFR7F-11
(1) Use Motorcraft spark plug number AWSF-42C. (2) (Scheme 2)
(1)Use Motorcraft spark plug number AWSF-42C.

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
B2200 (Carbureted).031 (.80)13 (18)
(1) RX7.055 (1.3)11 (15)
All Others.041 (1.0)13 (18)
(1) (Scheme 2)

SPARK PLUG SPECIFICATIONS

Scheme 2

Scheme 2
Scheme 2

FIRING ORDER & TIMING MARKS

Note. RX7 firing order is 1-2.

Firing Order & Distributor Rotation (B2200, B2600i & MPV 2.6L). Scheme 3

Scheme 3: Firing Order & Distributor Rotation (B2200, B2600i & MPV 2.6L)
Scheme 3: Firing Order & Distributor Rotation (B2200, B2600i & MPV 2.6L)

Firing Order (Miata). Scheme 4

Scheme 4: Firing Order (Miata)
Scheme 4: Firing Order (Miata)

Firing Order & Distributor Rotation (MPV 3.0L & 929). Scheme 5

Scheme 5: Firing Order & Distributor Rotation (MPV 3.0L & 929)
Scheme 5: Firing Order & Distributor Rotation (MPV 3.0L & 929)

Firing Order & Distributor Rotation (MX-6 & 626). Scheme 6

Scheme 6: Firing Order & Distributor Rotation (MX-6 & 626)
Scheme 6: Firing Order & Distributor Rotation (MX-6 & 626)

Firing Order & Coil Pack (Navajo). Scheme 7

Scheme 7: Firing Order & Coil Pack (Navajo)
Scheme 7: Firing Order & Coil Pack (Navajo)

Firing Order & Distributor Rotation (Protege & 323). Scheme 8

Scheme 8: Firing Order & Distributor Rotation (Protege & 323)
Scheme 8: Firing Order & Distributor Rotation (Protege & 323)

IGNITION TIMING

CAUTIONOn RX7, ignition timing is set AFTER top dead center.
ApplicationLeading (Yellow)Trailing (Red)
RX7 (3)5 @ 75020 @ 750
(1) (Scheme 9) (2) Degrees ATDC @ RPM. (3) Connect jumper wire between Green test connector and ground.
(2)Degrees ATDC @ RPM.
(3)Connect jumper wire between Green test connector and ground.

(1) IGNITION TIMING SPECIFICATIONS (RX7) (2)

Scheme 9

Scheme 9
Scheme 9
ApplicationM/T: °BTDC @ RPM(1) A/T: °BTDC @ RPM
B2200
Carbureted6 @ 8256 @ 825
PFI (2)6 @ 7506 @ 770
B2600i (2)5 @ 7505 @ 770
Miata (2)10 @ 8508 @ 850
MPV
2.6L (2)5 @ 7505 @ 770
3.0L (2)11 @ 80011 @ 800
MX-6 & 626
Non-Turbo (2) (3)6 @ 7506 @ 750
Turbo (2)9 @ 7509 @ 750
Navajo(4)(4)
Protege
DOHC (2)10 @ 75010 @ 750
SOHC (2)5 @ 7505 @ 750
323 (2)7 @ 7507 @ 750
929
DOHC (2)N/A8 @ 700
SOHC (2)N/A15 @ 650
(1) Place automatic transmission in Park. (2) Connect jumper wire between Green test connector and ground. (3) Disconnect and plug distributor vacuum advance hose. (4) Base (initial) timing is preset at 10 degrees BTDC and is not adjustable. To check timing, see appropriate ADJUSTMENTS article in the ENGINE PERFORMANCE section.
(1)Place automatic transmission in Park.
(2)Connect jumper wire between Green test connector and ground.
(3)Disconnect and plug distributor vacuum advance hose.
(4)Base (initial) timing is preset at 10 degrees BTDC and is not adjustable. To check timing, see appropriate ADJUSTMENTS article in the ENGINE PERFORMANCE section.

IGNITION TIMING SPECIFICATIONS (EXCEPT RX7)

DISTRIBUTOR SPECIFICATIONS

Note. On models with computer-controlled ignition, see appropriate G TESTS W/CODES article in the ENGINE PERFORMANCE section to diagnose ignition timing problems.

Scheme 10

Scheme 10: Carbureted Ignition Advance Curve - B2200
Scheme 10: Carbureted Ignition Advance Curve - B2200

Scheme 11

Scheme 11: Ignition Advance Curve - MPV 3.0L
Scheme 11: Ignition Advance Curve - MPV 3.0L

Scheme 12

Scheme 12: Ignition Advance/Retard Curve - MX-6 & 626 Non-Turbo
Scheme 12: Ignition Advance/Retard Curve - MX-6 & 626 Non-Turbo

FUEL PUMP

Note. Fuel pump performance measures fuel pressure and volume availability, not regulated fuel pressure.

ApplicationPressure psi (kg/cm 2 )Min. Vol. in 30 Sec. Pts. (L)
B2200 (Carbureted)
Electric Pump2.8-3.6 (.20-.25)1.1 (.66)
Mechanical Pump3.7-4.7 (.26-.33).9 (.43)
Navajo(1).0 (.49)
RX771-92 (5.0-6.5)(1)
All Others
Main Fuel Pump64-85 (4.5-6.0)1.1 (.66)
Transfer Pump (Protege 4WD)5.7 (0.4)1.0 (.57)
(1) Information is not available.
(1)Information is not available.

FUEL PUMP PERFORMANCE

ApplicationAt Idle w/ Vacuum psi (kg/cm 2 )At Idle w/o Vacuum psi (kg/cm 2 )
B2200 (PFI) & B2600i28-37 (2.0-2.6)38-46 (2.7-3.2)
Miata31-38 (2.2-2.7)38-46 (2.7-3.2)
MPV30-37 (2.1-2.6)38-46 (2.7-3.2)
MX-6 & 62627-33 (1.9-2.3)34-40 (2.4-2.8)
Navajo(1)(2)
Protege & 32330-37 (2.1-2.6)38-46 (2.7-3.2)
RX727-33 (1.9-2.3)34-40 (2.4-2.8)
92931-38 (2.2-2.7)38-46 (2.7-3.2)
(1) Pressure should be 30-45 psi (2.2-3.2 kg/cm 2 ) with engine running and 35-45 psi (2.5-3.2 kg/cm 2 ) with key on and engine off. (2) Information is not available.
(1)Pressure should be 30-45 psi (2.2-3.2 kg/cm 2 ) with engine running and 35-45 psi (2.5-3.2 kg/cm 2 ) with key on and engine off.
(2)Information is not available.

REGULATED FUEL PRESSURE

INJECTOR RESISTANCE

ApplicationOhms
Navajo13-16
Except Navajo12-16

INJECTOR RESISTANCE

IDLE SPEED & MIXTURE

ApplicationRPM - M/T(1) RPM - A/T
B2200
Carbureted825825
PFI (2)750770
B2600i (2)750770
Miata (2)850850
MPV
2.6L (2)750770
3.0L (2)800800
MX-6 (2)750750
Navajo(3)(3)
Protege (2)750750
RX7 (2)750750
323 (2)750750
626 (2)750750
929
DOHC (2)N/A700
SOHC (2)N/A650
(1) Place automatic transmission in Park. (2) Connect jumper wire between ground and Green test connector. (3) Idle speed is not adjustable, however, throttle angle (minimum air rate) can be set using special procedure. See appropriate ADJUSTMENTS article in the ENGINE PERFORMANCE section.
(1)Place automatic transmission in Park.
(2)Connect jumper wire between ground and Green test connector.
(3)Idle speed is not adjustable, however, throttle angle (minimum air rate) can be set using special procedure. See appropriate ADJUSTMENTS article in the ENGINE PERFORMANCE section.

IDLE SPEED SPECIFICATIONS

FAST (COLD) IDLE SPEED

ApplicationRPM
B2200 (Carbureted)(1) 3000-4000
(1) Adjust with throttle lever on highest step of fast idle cam.
(1)Adjust with throttle lever on highest step of fast idle cam.

FAST (COLD) IDLE SPEED

DASHPOT SPECIFICATIONS

ApplicationRPM
B2200 (Carbureted With M/T)2700-2900
Miata2350-2650
MPV (3.0L)3200-3800
Protege
DOHCAbout 3500
SOHCAbout 2700
RX7
Non-Turbo2700-3100
Turbo(1)
323About 3000
929 SOHC3200-3800
(1) See ADJUSTMENTS article in the ENGINE PERFORMANCE section.
(1)See ADJUSTMENTS article in the ENGINE PERFORMANCE section.

DASHPOT SPECIFICATIONS

THROTTLE POSITION SENSOR (TPS)

Note. For information on connector terminal identification and test conditions specified in the following tables, see appropriate ADJUSTMENTS article in the ENGINE PERFORMANCE section.

Red Wire VoltageBlue Wire Voltage Closed ThrottleBlue Wire Voltage Wide Open Throttle
4.50-4.59.37-.543.58-4.23
4.60-4.69.38-.553.66-4.32
4.70-4.79.39-.563.74-4.41
4.80-4.89.40-.573.82-4.51
4.90-4.99.40-.583.90-4.60
5.00-5.09.41-.603.97-4.70
5.10-5.19.42-.614.05-4.79
5.20-5.29.43-.624.13-4.88
5.30-5.39.44-.634.21-4.98
5.40-5.49.44-.644.29-5.07
5.50.44-.664.29-5.17

TPS VOLTAGE

Test Condition (1)(2) Continuity
.004" (.1 mm)Yes
.024" (.6 mm)No
(1) Insert feeler gauge of specified thickness between throttle lever and throttle stop screw. (2) Check continuity with ohmmeter connected between TPS terminals "E" and IDL.
(1)Insert feeler gauge of specified thickness between throttle lever and throttle stop screw.
(2)Check continuity with ohmmeter connected between TPS terminals "E" and IDL.

TPS CONTINUITY TEST

Test ConditionContinuity Between IDL & TLContinuity Between POW & TL
Miata
.016" (.4 mm) (1)YesNo
.027" (.7 mm) (1)NoNo
Wide Open ThrottleNoYes
Protege & 323
.004" (.10 mm) (1)YesNo
.039" (1.0 mm) (1)NoNo
Wide Open ThrottleNoYes
(1) Insert feeler gauge of specified thickness between throttle lever and throttle stop screw.
(1)Insert feeler gauge of specified thickness between throttle lever and throttle stop screw.

TPS CONTINUITY TEST

Test ConditionOhms
MPV 3.0L & 929 SOHC
Between Terminals "A" & "D"3500-6500
Between Terminals "B" & "D"
Closed ThrottleAbout 1000 or less
Wide Open Throttle3500-6500
929 DOHC
Between Terminals "A" & "D"3000-6000
Between Terminals "B" & "D"
Closed Throttle200-600
Wide Open Throttle3300-7000

TPS RESISTANCE

Test Condition (1)Continuity Between C & D
MPV 3.0L & 929 SOHC
.020" (.5 mm)Yes
.028" (.7 mm)No
929 DOHC
.004" (.1 mm)Yes
.012" (.3 mm)No
(1) Insert feeler gauge of specified thickness between throttle lever and throttle stop screw.
(1)Insert feeler gauge of specified thickness between throttle lever and throttle stop screw.

TPS ADJUSTMENT

TerminalVolts With Throttle ClosedVolts With Throttle Fully Open
2F (Narrow Range).75-1.25About 5
2G (Full Range).25-1.254.1-4.4

TPS VOLTAGE - RX7

THROTTLE (IDLE) SWITCH

RPMVolts
825 (Idle)About 12
About 1000 Or MoreLess than 1.5

THROTTLE (IDLE) SWITCH VOLTAGE
