Wheel Alignment Specifications & Procedures Mazda MX-6 V

Wheel Alignment 1 illustration
ApplicationSpecification
2WS
Front
Camber in Degrees
Fraction1/4 +/- 3/4
Decimal.25 +/- .75
Caster in Degrees
Fraction1 1/4 +/- 3/4
Decimal1.25 +/- 1.75
Toe-In in Inches
Fraction0 +/- 1/8
Decimal0 +/- .13
Toe-In in Degrees
Fraction0 +/- 1/4
Decimal0 +/- .25
Toe-Out on Turns
Inner36°
Outer31°
Steering Axis Inclination (SAI)12 3/4°
Rear
Camber in Degrees
Fraction1/2 +/- 3/4
Decimal.50 +/- .75
Toe-In in Inches
Fraction1/8 +/- 1/8
Decimal.13 +/- .13
Toe-In in Degrees
Fraction1/4 +/- 1/4
Decimal.25 +/- .25
4WS
Front
Camber in Degrees
Fraction1/4 +/- 1/2
Decimal.25 +/- .50
Caster in Degrees
Fraction1 1/4 +/- 3/4
Decimal1.25 +/- .75
Toe-In in Inches
Fraction0 +/- 1/8
Decimal0 +/- .13
Toe-In in Degrees
Fraction1/4 +/- 1/4
Decimal.25 +/- .25
Toe-Out on Turns
Inner34°
Outer29°
Steering Axis Inclination (SAI)12 3/4°
Rear
Camber in Degrees
Fraction0 +/- 3/4
Decimal0 +/- .75
Toe-In in Inches
Fraction1/8 +/- 1/8
Decimal.13 +/- .13
Toe-In in Degrees
Fraction1/4 +/- 1/4
Decimal.25 +/- .25

WHEEL ALIGNMENT SPECIFICATIONS

Front Camber & Caster Adjustment Loosen the 4 mounting bolts and turn the positioning mark to A to increase caster 5/16°, and B to increase caster and camber 5/16°, and C to increase camber only 5/16°. Scheme 1

Scheme 1: Front Camber & Caster Adjustment Loosen the 4 mounting bolts and turn the positioning mark to A to increase caster 5/16°, and B to increase caster and camber 5/16°, and C to increase camber only 5/16°.
Scheme 1: Front Camber & Caster Adjustment Loosen the 4 mounting bolts and turn the positioning mark to A to increase caster 5/16°, and B to increase caster and camber 5/16°, and C to increase camber only 5/16°.

4-WHEEL STEERING MODELS

Note. Alignment procedures not available.
