Wiring diagram: Starting/charging 2.0l — 2.0l, starting circuit, m/t Mazda MX-6 I
All systems
- Air conditioning 2.0l 2
- Air conditioning 2.5l 2
- Anti-lock brakes
- Anti-theft
- Body computer
- Computer data lines 2.0l 2
- Computer data lines 2.5l
- Cooling fan 2.0l
- Cooling fan 2.5l
- Cruise control
- Defoggers
- Engine performance 2.0l 2
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Instrument cluster
- Interior lights 2
- Power antenna
- Power distribution
- Power door locks 2
- Power mirrors
- Power seats
- Power top/sunroof
- Power windows
- Radio
- Shift interlocks
- Starting/charging 2.0l 5
- Starting/charging 2.5l 5
- Supplemental restraints
- Transmission 2.0l
- Transmission 2.5l
- Warning systems
- Wiper/washer
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
