Alternator & Regulator: Removal & Installation Mazda MX-6 I

Brush Installation

1. Install brush and spring into holder. Allow brush to extend out of holder until wear limit line extends.08-.16" (2-4 mm) beyond end of brush holder. (Scheme 1) Solder pigtail onto brush holder.
2. Insert spring and brush into brush holder. Using a spring scale, pull brush into holder until end of brush protrudes.08" (2.0 mm) from holder. see scheme 11-16. Note reading on spring scale. Replace spring if tension is not 5.6-15.5 ozs. (160-440 g).

Scheme 1

Scheme 2

Scheme 3

Charging System Wiring Diagram (MX-6). Scheme 4
