Wiring Diagrams Mazda MX-5 NC facelift (2008-2015)

28 systems 49 wiring diagrams 770 components
Contents — 28 systems, 49 diagrams
Air conditioning
Anti-lock brakes
Anti-theft
Computer data lines
Cooling fan
Cruise control
Defoggers
Engine performance 2.0l
Exterior lights
Ground distribution
Headlights
Horn
Instrument cluster
Interior lights
Power distribution
Power door locks
Power mirrors
Power seats
Power top/sunroof
Power windows
Radio
Shift interlock
Starting/charging
Supplemental restraints
Transmission
Trunk, tailgate, fuel door
Warning systems
Wiper/washer

Air conditioning

# Automatic a/c circuit

# Automatic a/c circuit (1 of 2)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (1 of 2). Mazda MX-5 NC facelift (2008-2015)
Components on the diagram

    # Automatic a/c circuit (2 of 2)

    Air conditioning — Automatic a/c circuit — Automatic a/c circuit (2 of 2). Mazda MX-5 NC facelift (2008-2015)
    Components on the diagram

      # Manual a/c circuit

      # Manual a/c circuit (1 of 2)

      Air conditioning — Manual a/c circuit — Manual a/c circuit (1 of 2). Mazda MX-5 NC facelift (2008-2015)
      Components on the diagram

        # Manual a/c circuit (2 of 2)

        Air conditioning — Manual a/c circuit — Manual a/c circuit (2 of 2). Mazda MX-5 NC facelift (2008-2015)
        Components on the diagram

          Anti-lock brakes

          # Anti-lock brakes circuit, with dynamic stability control

          Anti-lock brakes — Anti-lock brakes circuit, with dynamic stability control — Anti-lock brakes circuit, with dynamic stability control. Mazda MX-5 NC facelift (2008-2015)
          Components on the diagram

            # Anti-lock brakes circuit, without dynamic stability control

            Anti-lock brakes — Anti-lock brakes circuit, without dynamic stability control — Anti-lock brakes circuit, without dynamic stability control. Mazda MX-5 NC facelift (2008-2015)
            Components on the diagram

              Anti-theft

              # Anti-theft circuit

              # Anti-theft circuit (1 of 2)

              Anti-theft — Anti-theft circuit — Anti-theft circuit (1 of 2). Mazda MX-5 NC facelift (2008-2015)
              Components on the diagram

                # Anti-theft circuit (2 of 2)

                Anti-theft — Anti-theft circuit — Anti-theft circuit (2 of 2). Mazda MX-5 NC facelift (2008-2015)
                Components on the diagram

                  Computer data lines

                  # Computer data lines circuit

                  Computer data lines — Computer data lines circuit — Computer data lines circuit. Mazda MX-5 NC facelift (2008-2015)
                  Components on the diagram

                    Cooling fan

                    # Cooling fan circuit

                    Cooling fan — Cooling fan circuit — Cooling fan circuit. Mazda MX-5 NC facelift (2008-2015)
                    Components on the diagram

                      Cruise control

                      # Cruise control circuit

                      Cruise control — Cruise control circuit — Cruise control circuit. Mazda MX-5 NC facelift (2008-2015)
                      Components on the diagram

                        Defoggers

                        # Defoggers circuit

                        Defoggers — Defoggers circuit — Defoggers circuit. Mazda MX-5 NC facelift (2008-2015)
                        Components on the diagram

                          Engine performance 2.0l

                          # Wiring diagram engine performance 2.0l

                          # Wiring diagram engine performance 2.0l (1 of 4)

                          Engine performance 2.0l — Wiring diagram engine performance 2.0l — Wiring diagram engine performance 2.0l (1 of 4). Mazda MX-5 NC facelift (2008-2015)
                          Components on the diagram

                            # Wiring diagram engine performance 2.0l (2 of 4)

                            Engine performance 2.0l — Wiring diagram engine performance 2.0l — Wiring diagram engine performance 2.0l (2 of 4). Mazda MX-5 NC facelift (2008-2015)
                            Components on the diagram

                              # Wiring diagram engine performance 2.0l (3 of 4)

                              Engine performance 2.0l — Wiring diagram engine performance 2.0l — Wiring diagram engine performance 2.0l (3 of 4). Mazda MX-5 NC facelift (2008-2015)
                              Components on the diagram

                                # Wiring diagram engine performance 2.0l (4 of 4)

                                Engine performance 2.0l — Wiring diagram engine performance 2.0l — Wiring diagram engine performance 2.0l (4 of 4). Mazda MX-5 NC facelift (2008-2015)
                                Components on the diagram

                                  Exterior lights

                                  # Backup lamps circuit

                                  Exterior lights — Backup lamps circuit — Backup lamps circuit. Mazda MX-5 NC facelift (2008-2015)
                                  Components on the diagram

                                    # Exterior lamps circuit

                                    Exterior lights — Exterior lamps circuit — Exterior lamps circuit. Mazda MX-5 NC facelift (2008-2015)
                                    Components on the diagram

                                      Ground distribution

                                      # Ground distribution circuit

                                      Ground distribution — Ground distribution circuit — Ground distribution circuit. Mazda MX-5 NC facelift (2008-2015)
                                      Components on the diagram

                                        Headlights

                                        # Headlights circuit, with halogen, with drl

                                        Headlights — Headlights circuit, with halogen, with drl — Headlights circuit, with halogen, with drl. Mazda MX-5 NC facelift (2008-2015)
                                        Components on the diagram

                                          # Headlights circuit, with halogen, without drl

                                          Headlights — Headlights circuit, with halogen, without drl — Headlights circuit, with halogen, without drl. Mazda MX-5 NC facelift (2008-2015)
                                          Components on the diagram

                                            # Headlights circuit, with hid, with drl

                                            Headlights — Headlights circuit, with hid, with drl — Headlights circuit, with hid, with drl. Mazda MX-5 NC facelift (2008-2015)
                                            Components on the diagram

                                              # Headlights circuit, with hid, without drl

                                              Headlights — Headlights circuit, with hid, without drl — Headlights circuit, with hid, without drl. Mazda MX-5 NC facelift (2008-2015)
                                              Components on the diagram

                                                Horn

                                                # Horn circuit

                                                Horn — Horn circuit — Horn circuit. Mazda MX-5 NC facelift (2008-2015)
                                                Components on the diagram

                                                  Instrument cluster

                                                  # Instrument cluster circuit

                                                  Instrument cluster — Instrument cluster circuit — Instrument cluster circuit. Mazda MX-5 NC facelift (2008-2015)
                                                  Components on the diagram

                                                    Interior lights

                                                    # Interior lights circuit

                                                    Interior lights — Interior lights circuit — Interior lights circuit. Mazda MX-5 NC facelift (2008-2015)
                                                    Components on the diagram

                                                      Power distribution

                                                      # Power distribution circuit

                                                      # Power distribution circuit (1 of 2)

                                                      Power distribution — Power distribution circuit — Power distribution circuit (1 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                      Components on the diagram

                                                        # Power distribution circuit (2 of 2)

                                                        Power distribution — Power distribution circuit — Power distribution circuit (2 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                        Components on the diagram

                                                          Power door locks

                                                          # Power door locks circuit

                                                          # Power door locks circuit (1 of 2)

                                                          Power door locks — Power door locks circuit — Power door locks circuit (1 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                          Components on the diagram

                                                            # Power door locks circuit (2 of 2)

                                                            Power door locks — Power door locks circuit — Power door locks circuit (2 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                            Components on the diagram

                                                              Power mirrors

                                                              # Auto dimming mirror circuit

                                                              Power mirrors — Auto dimming mirror circuit — Auto dimming mirror circuit. Mazda MX-5 NC facelift (2008-2015)
                                                              Components on the diagram

                                                                # Power mirror circuit

                                                                Power mirrors — Power mirror circuit — Power mirror circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                Components on the diagram

                                                                  Power seats

                                                                  # Power seats circuit

                                                                  Power seats — Power seats circuit — Power seats circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                  Components on the diagram

                                                                    Power top/sunroof

                                                                    # Power top/sunroof circuit

                                                                    Power top/sunroof — Power top/sunroof circuit — Power top/sunroof circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                    Components on the diagram

                                                                      Power windows

                                                                      # Power windows circuit, with power retractable hardtop

                                                                      Power windows — Power windows circuit, with power retractable hardtop — Power windows circuit, with power retractable hardtop. Mazda MX-5 NC facelift (2008-2015)
                                                                      Components on the diagram

                                                                        # Power windows circuit, without power retractable hardtop

                                                                        Power windows — Power windows circuit, without power retractable hardtop — Power windows circuit, without power retractable hardtop. Mazda MX-5 NC facelift (2008-2015)
                                                                        Components on the diagram

                                                                          Radio

                                                                          # Radio circuit, with bose

                                                                          # Radio circuit, with bose (1 of 2)

                                                                          Radio — Radio circuit, with bose — Radio circuit, with bose (1 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                                          Components on the diagram

                                                                            # Radio circuit, with bose (2 of 2)

                                                                            Radio — Radio circuit, with bose — Radio circuit, with bose (2 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                                            Components on the diagram

                                                                              # Radio circuit, without bose

                                                                              Radio — Radio circuit, without bose — Radio circuit, without bose. Mazda MX-5 NC facelift (2008-2015)
                                                                              Components on the diagram

                                                                                Shift interlock

                                                                                # Shift interlock circuit

                                                                                Shift interlock — Shift interlock circuit — Shift interlock circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                                Components on the diagram

                                                                                  Starting/charging

                                                                                  # Charging circuit

                                                                                  Starting/charging — Charging circuit — Charging circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                                  Components on the diagram

                                                                                    # Starting circuit

                                                                                    Starting/charging — Starting circuit — Starting circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                                    Components on the diagram

                                                                                      Supplemental restraints

                                                                                      # Supplemental restraints circuit

                                                                                      # Supplemental restraints circuit (1 of 2)

                                                                                      Supplemental restraints — Supplemental restraints circuit — Supplemental restraints circuit (1 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                                                      Components on the diagram

                                                                                        # Supplemental restraints circuit (2 of 2)

                                                                                        Supplemental restraints — Supplemental restraints circuit — Supplemental restraints circuit (2 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                                                        Components on the diagram

                                                                                          Transmission

                                                                                          # Transmission circuit

                                                                                          # Transmission circuit (1 of 2)

                                                                                          Transmission — Transmission circuit — Transmission circuit (1 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                                                          Components on the diagram

                                                                                            # Transmission circuit (2 of 2)

                                                                                            Transmission — Transmission circuit — Transmission circuit (2 of 2). Mazda MX-5 NC facelift (2008-2015)
                                                                                            Components on the diagram

                                                                                              Trunk, tailgate, fuel door

                                                                                              # Trunk release circuit

                                                                                              Trunk, tailgate, fuel door — Trunk release circuit — Trunk release circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                                              Components on the diagram

                                                                                                Warning systems

                                                                                                # Warning systems circuit

                                                                                                Warning systems — Warning systems circuit — Warning systems circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                                                Components on the diagram

                                                                                                  Wiper/washer

                                                                                                  # Wiper/washer circuit

                                                                                                  Wiper/washer — Wiper/washer circuit — Wiper/washer circuit. Mazda MX-5 NC facelift (2008-2015)
                                                                                                  Components on the diagram
