Front Axle: Removal & Installation Mazda MX-5 NC рестайлинг

Wheel Hubs 6 illustrations ~154 words

WHEEL HUB, STEERING KNUCKLE REMOVAL/INSTALLATION

CAUTIONPerforming the following procedures without first removing the ABS wheel-speed sensor may possibly cause an open circuit in the wiring harness if it is pulled by mistake. Before performing the following procedures, disconnect the ABS wheel-speed sensor harness connector (axle side) and fix it to an appropriate place where the sensor will not be pulled by mistake while servicing the vehicle.

Scheme 3

Scheme 3
Scheme 3
  1. Remove in the order indicated in the table.
  2. Install in the reverse order of removal.
  3. After installation, inspect front wheel alignment. (See «FRONT WHEEL ALIGNMENT»(ref-430306-S26371044342011101700000) .)

Scheme 4

Scheme 4: Brake Caliper Component Removal Note
Scheme 4: Brake Caliper Component Removal Note
  1. Suspend the brake caliper component using a cable or equivalent.

Wheel Hub Bolt Removal Note

Note. Remove the wheel hub bolt only if there is an abnormality.

Scheme 5

Scheme 5: Wheel Hub Bolt Removal Note
Scheme 5: Wheel Hub Bolt Removal Note
  1. Remove the wheel hub bolts from the wheel hub using a press.

Scheme 6

Scheme 6: Wheel Hub Bolt Installation Note
Scheme 6: Wheel Hub Bolt Installation Note
  1. Press in new wheel hub bolts into the wheel hub using a press.

Scheme 7

Scheme 7: FRONT WHEEL HUB BOLT REPLACEMENT
Scheme 7: FRONT WHEEL HUB BOLT REPLACEMENT

Scheme 8

Scheme 8
Scheme 8
  1. Remove the brake caliper component and disc plate.
  2. Remove the wheel hub bolt using the SST as shown in the illustration.
  3. Place a new wheel hub bolt in the wheel hub.
  4. Install the wheel hub bolt by placing a proper sized washer on the hub, and tightening the nut as shown in the illustration.
