Glass/windows/mirrors: Overview Mazda MX-5 NC рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Position the door glass so that the distance between the top of the front door glass and top of the front beltline molding is 110 mm {4.33 in} .
2. Remove the battery cover.
3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» ).
4. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION» ).
5. Remove the door module panel. (See «DOOR MODULE PANEL REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2008-2015/remont/exterior-body-panels/#body-panel-system-doors-and-liftgate) ).
6. Remove the glass stopper.
7. Remove the nuts attaching door glass to regulator.
8. Lift the door glass up, then remove it while tilting it in the direction of the arrow shown in figure.
9. Install in the reverse order of removal.
10. Adjust the door glass. (See «DOOR GLASS ADJUSTMENT» ).

Scheme 5

Scheme 6

Scheme 7

1. Position the door glass so that the distance between the top of the front door glass and top of the front beltline molding is 110 mm {4.33 in} .
2. Remove the battery cover.
3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» ).
4. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION» ).
5. Remove the door module panel. (See «DOOR MODULE PANEL REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2008-2015/remont/exterior-body-panels/#body-panel-system-doors-and-liftgate) ).
6. Remove the door glass. (See «DOOR GLASS REMOVAL/INSTALLATION» ).
7. Remove the power window regulator. (See «POWER WINDOW REGULATOR REMOVAL/INSTALLATION» ).
8. Remove the nut and bolt, then remove the door glass guide. (See «DOOR GLASS GUIDE INSTALLATION NOTE» ).
9. Remove the nuts, then remove the door quarter glass.
10. Install in the reverse order of removal.

Scheme 8

1. Adjust the adjustment bolt as shown in the figure.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Fully close the door glass.
2. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION» ).
3. Remove the door module panel. (See «DOOR MODULE PANEL REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2008-2015/remont/exterior-body-panels/#body-panel-system-doors-and-liftgate) ).
4. Connect the power window regulator connector.
5. Loosen the glass stopper installation bolts.
6. Loosen the power window regulator and door glass tightening nuts.
7. Align the door glass with the rear edge of the front beltline molding. NOTE: The standard position for the rear edge of the front beltline molding is 1 mm {0.04 in} from the rear edge of the door panel. If the standard position for the rear edge of the front beltline molding has deviated, align the rear edge of the door glass to the standard position for the rear edge position of the front beltline molding.
8. Lightly tighten the power window regulator and door glass tightening nuts.
9. Adjust the clearance between the upper edge of the door glass and the door glass guide. Clearance Standard Minimum Maximum a 1.0 mm {0.04 in} 0 mm {0 in} 1.5 mm {0.06 in}
10. Adjust the door glass position.
11. Tighten the power window regulator and door glass tightening nuts.
12. Tighten the bolts while pressing the glass stopper in the direction of the arrows shown in figure.
13. Verify that the door glass opens and closes smoothly.
14. Install the door module panel. (See «DOOR MODULE PANEL REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2008-2015/remont/exterior-body-panels/#body-panel-system-doors-and-liftgate) ).
15. Install the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION» ).
16. Close the door with the convertible top, detachable hardtop, or power retractable hardtop closed and verify that the door glass opens and closes smoothly.

Scheme 15

Scheme 16

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]» ).
3. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION» ).
4. Remove the door module panel. (See «DOOR MODULE PANEL REMOVAL/INSTALLATION»(/mazda/mx-5/nc-2008-2015/remont/exterior-body-panels/#body-panel-system-doors-and-liftgate) ).
5. Remove the door glass. (See «DOOR GLASS REMOVAL/INSTALLATION» ).
6. Remove the nuts.
7. Remove the power window regulator.
8. Install in the reverse order of removal.

Scheme 17

1. Remove in the order indicated in the figure.
2. Assemble in the reverse order of disassembly. NOTE: When installing the power window motor, be careful that the cable does not become unwounded from the drum.

Scheme 18

1. Carefully bend away the crimp of the cover using long nose pliers.
