| CAUTION | If installation is performed without using the SST, the seal ring will be damaged and deformed, resulting in an incorrect installation. Always use the SST to install the seal ring. |
Scheme 8
Scheme 9
Scheme 10
- Temporarily install the seal ring to the pipe so that the seal ring is even with the flange.
- Install the SST to the seal ring so that the SST is even with the flange.
- Press in the seal ring by tapping the SST using a plastic hammer until the seal ring contacts the flange.
Scheme 11
- Spray carbon remover (TB6601 or equivalent) on the flared section of the middle pipe.
- Remove the carbon adhering to the flared section shown in illustration using a nylon brush or sandpaper (No. 400 or equivalent).
