Piston Ring Assembly Note

  1. Install the two oil control ring segments and spacer.
  2. Verify that the second ring is installed with scraper face side downward.
  3. Verify that the top ring is installed with scraper face side inner of upper.

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77: Piston Assembly Note
Scheme 77: Piston Assembly Note
  1. Position the end gap of each ring as indicated in the figure.
  2. Insert the piston and connecting rod into the cylinder with the arrow mark to front of the engine.

Scheme 78
