Air Bag System: Removal & Installation Mazda MX-5 NC рестайлинг

Airbag 16 illustrations ~1359 words

DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS ) (See AIR BAG SYSTEM SERVICE CAUTIONS )

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the covers.
  5. Remove the bolts.
  6. Using a flathead screwdriver, lift the locking device carefully, however do not remove it.
  7. Disconnect the air bag module connector.
  8. Disconnect the horn switch connector.
  9. Remove the driver-side air bag module.
  10. Install in the reverse order of removal.
  11. Turn the ignition switch to the ON position.
  12. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) )

PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS ) (See AIR BAG SYSTEM SERVICE CAUTIONS ) If the passenger-side air bag module is installed with debris in the module, it may be scattered when the air bag module operates (deploys), causing injury. Verify that there is no debris in the passenger-side air bag module before installation. If a damaged passenger-side air bag module is installed, the vehicle may be damaged or the passenger may be injured when the air bag module operates (deploys). Verify that the passenger-side air bag has no damage before installation. Due to the adoption of 2-step deployment control in the passenger-side air bag module, depending on the impact force, it is possible that inflator No. 2 might not deploy. In such cases, before disposing of the air bag module, make sure to follow the inflator deployment procedures and verify complete deployment of inflators No. 1 and 2.

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-430296-S12626857422011101700000) )
  5. Remove the cap. (See «CAP INSTALLATION NOTE»(ref-430310-S38570539332011101700000) )
  6. Using a flathead screwdriver, lift the locking device carefully, however do not remove it.
  7. Disconnect the connector.
  8. Remove the screw A.
  9. Remove the nuts.
  10. Remove the brackets.
  11. Remove the screw B.
  12. Remove the passenger-side air bag module in the order indicated below. Disengage the tab locks by sliding the passenger-side air bag module upward. Slide the passenger-side air bag module rearward. Remove the passenger-side air bag module by pulling it from the backside and then down.
  13. Install in the reverse order of removal.
  14. Turn the ignition switch to the ON position.
  15. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) )

Cap Installation Note

  1. The cap cannot be reused. Replace the cap with a new one when the cap or the passenger-side air bag module has been removed.

SIDE AIR BAG MODULE REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS ) (See AIR BAG SYSTEM SERVICE CAUTIONS ) If the side air bag module is installed with debris in the seat back, the foreign material may be scattered when the side air bag module operates (deploys), causing injury. Verify that there is no foreign material in the seat back before installing the side air bag module.

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the seat. (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) )
  5. Remove the band A.
  6. Detach the tab as shown in the illustration and remove the connector from the seat connector.
  7. Remove the seat back trim and pad. (See «SEAT BACK TRIM REMOVAL/INSTALLATION»(ref-430316-S22735366182011101700000) )
  8. Remove the band B.
  9. Remove the nuts.
  10. Remove the side air bag module.
  11. Install in the reverse order of removal.
  12. Turn the ignition switch to the ON position.
  13. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) )

CRASH ZONE SENSOR REMOVAL/INSTALLATION

WARNINGHandling the crash zone sensor improperly can accidentally deploy the air bags and pre-tensione seat belts, which may seriously injure you. Read the air bag system service warnings and cautions before handling the crash zone sensor. (See AIR BAG SYSTEM SERVICE WARNINGS ) (See AIR BAG SYSTEM SERVICE CAUTIONS )

Scheme 22

Scheme 22
Scheme 22
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-430315-S08524033602011101700000) )
  5. Remove the fresh-air duct. See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [LF]»(ref-478572-S27568218632012061100000) .
  6. Remove the bolt A.
  7. Remove the cover.
  8. Disconnect the connector.
  9. Remove the bolt B.
  10. Remove the crash zone sensor.
  11. Install in the reverse order of removal.
  12. Turn the ignition switch to the ON position.
  13. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) )

SAS CONTROL MODULE REMOVAL/INSTALLATION

WARNINGHandling the SAS control module improperly can accidentally deploy the air bag modules and pre-tensioner seat belt, which may seriously injure you. Read the air bag system service warnings and cautions before handling the SAS control module. (See AIR BAG SYSTEM SERVICE WARNINGS ) (See AIR BAG SYSTEM SERVICE CAUTIONS )
CAUTIONHandling the SAS control module improperly can accidentally deploy the air bag modules and pre-tensioner seat belt, which may seriously injure you. If configuration is not completed before removing the SAS control module, DTC B2477 will be displayed.

Scheme 23

Scheme 23
Scheme 23
  1. Perform SAS control module configuration when replacing it. (See «SAS CONTROL MODULE CONFIGURATIONS»(ref-430310-S01426821322011101700000) )
  2. Turn the ignition switch to the LOCK position.
  3. Remove the battery cover.
  4. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  5. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-430296-S07285052982011101700000) ) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-430296-S27872972132011101700000) ) Keyless antenna (center) (with advanced keyless entry and start system) (See «KEYLESS ANTENNA REMOVAL/INSTALLATION»(ref-430313-S14937662632011101700000) )
  6. Disconnect the connector
  7. Remove the bolts.
  8. Remove the SAS control module.
  9. Install in the reverse order of removal.
  10. Turn the ignition switch to the ON position. If the SAS control module is replaced, turn the ignition switch to the ON position for 20 s or more after completing the configuration. (See «SAS CONTROL MODULE CONFIGURATION»(ref-430310-S01426821322011101700000) )
  11. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) )

Scheme 24

Scheme 24: SAS CONTROL MODULE CONFIGURATION
Scheme 24: SAS CONTROL MODULE CONFIGURATION
  1. Connect the M-MDS to the DLC-2.
  2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Module Programming". When using the PDS (Pocket PC) Select "Programming". Select "Module Programming".
  3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "RCM".
  4. Perform the configuration according to the directions on the screen.
  5. Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC (s) is detected, perform the applicable DTC inspection. (See «DTC TABLE»(ref-478580-S09497905322012061100000) )

Scheme 25

Scheme 25: SEAT TRACK POSITION SENSOR REMOVAL/INSTALLATION
Scheme 25: SEAT TRACK POSITION SENSOR REMOVAL/INSTALLATION

Scheme 26

Scheme 26
Scheme 26
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the driver's seat. (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) )
  5. Detach the tab as shown in the illustration and remove the connector from the seat connector.
  6. Remove the screw.
  7. Remove the seat track position sensor.
  8. Install in the reverse order of removal.

Scheme 27

Scheme 27: Seat Track Position Sensor Installation Note
Scheme 27: Seat Track Position Sensor Installation Note
  1. Verify that the seat track position sensor is not contacting the metal plate.

SEAT WEIGHT SENSOR CONTROL MODULE REMOVAL/INSTALLATION

CAUTIONWhen the seat weight sensor control module is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION )

Scheme 28

Scheme 28
Scheme 28
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the connector.
  5. Remove the screws.
  6. Remove the seat weight sensor control module.
  7. Install in the reverse order of removal.

SIDE AIR BAG SENSOR REMOVAL/INSTALLATION

WARNINGHandling the side air bag sensor improperly can accidentally operate (deploy) the air bag module which may seriously injure you. Read the air bag system service warnings and cautions before handling the side air bag sensor. (See AIR BAG SYSTEM SERVICE WARNINGS ) (See AIR BAG SYSTEM SERVICE CAUTIONS )

Scheme 29

Scheme 29
Scheme 29
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the quarter trim. (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) )
  5. Remove the scuff plate. (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) )
  6. Remove the tire house trim. (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) )
  7. Remove the connector.
  8. Remove the bolt.
  9. Remove the side air bag sensor.
  10. Install in the reverse order of removal.
  11. Turn the ignition switch to the ON position and hold for 5 s or more.
  12. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) )

Scheme 30

Scheme 30: CLOCK SPRING REMOVAL/INSTALLATION
Scheme 30: CLOCK SPRING REMOVAL/INSTALLATION
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  4. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-430310-S13032094912011101700000) ) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-430311-S39290501642011101700000) ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) )
  5. Remove the screw.
  6. Remove the connector.
  7. Remove the clock spring.
  8. Install in the reverse order of removal.
  9. Turn the ignition switch to the ON position.
  10. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate normally, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) )

Clock Spring Installation Note

CAUTIONIf the clock spring is not adjusted, the spring wire in the clock spring could over-wind and break when the steering wheel is turned. Always adjust the clock spring after installing it.
  1. Adjust the clock spring after installing it. (See «CLOCK SPRING ADJUSTMENT»(ref-430310-S17505995962011101700000) )
