Front Axle: Overview Mazda MX-5 NC

Scheme 1

Scheme 2

Scheme 3

1. Remove the brake caliper component and disc plate.
2. Remove the wheel hub bolt using the SST (Scheme 2)
3. Place a new wheel hub bolt in the wheel hub.
4. Install the wheel hub bolt by placing a proper sized washer on the hub, and tightening the nut (Scheme 3)

Scheme 4

1. Install the magnetic vase and dial gauge (Scheme 4), and inspect the wheel bearing for axial looseness. If it exceeds the maximum specification, replace the wheel hub component. Maximum front wheel bearing play 0.05 mm {0.002 in}
