Lighting Systems: Overhaul Mazda MX-5 NC

Steering Column Switches 7 illustrations ~196 words

COMBINATION SWITCH DISASSEMBLY/ASSEMBLY

CAUTIONFor vehicles with DSC: If the disc on the combination switch is deformed or has foreign material adhering to it, performance of the steering angle sensor may be reduced, causing abnormal operation. When handling the combination switch, be careful not to deform the disc and make sure there is no foreign material on it.

Scheme 33

Scheme 33
Scheme 33
  1. Disassemble in the order indicated in (Scheme 34).
  2. Assemble in the reverse order of disassembly.

Scheme 34

Scheme 34: FRONT FOG LIGHT SWITCH INSPECTION
Scheme 34: FRONT FOG LIGHT SWITCH INSPECTION

Scheme 35

Scheme 35
Scheme 35
  1. Verify that the continuity between the front fog light switch terminals is as indicated in (Scheme 35). If not as indicated in (Scheme 35), replace the light switch.

Scheme 36

Scheme 36: HAZARD WARNING SWITCH REMOVAL/INSTALLATION
Scheme 36: HAZARD WARNING SWITCH REMOVAL/INSTALLATION
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
  3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244480-S26287572182006092400000).)
  4. Remove the center panel unit. (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244490-S18996003212006092400000).)
  5. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-244480-S01520918242006092400000).)
  6. Remove the decoration panel (passenger's side). (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-244480-S22809572592006092400000).)
  7. Remove in the order indicated in (Scheme 37).
  8. Install in the reverse order of removal.

Scheme 37

Scheme 37: HAZARD WARNING SWITCH INSPECTION
Scheme 37: HAZARD WARNING SWITCH INSPECTION

Scheme 38

Scheme 38
Scheme 38
  1. Verify that the continuity between the hazard switch terminals is as indicated in (Scheme 38). If not as indicated in (Scheme 38), replace the hazard warning switch.

Scheme 39

Scheme 39: LIGHT SWITCH REMOVAL/INSTALLATION
Scheme 39: LIGHT SWITCH REMOVAL/INSTALLATION
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
  3. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-244480-S03023275402006092400000) .)
  4. Disconnect the connector.
  5. Remove the screws and then remove the light switch.
  6. Install in the reverse order of removal.
