Engine Controls - Service & Adjustment Specifications: Other Mazda MX-5 NB рестайлинг

Specifications 10 illustrations ~365 words

ENGINE COMPRESSION

Warm engine to normal operating temperature. Remove all spark plugs. Disconnect ignition coil primary wire connector. Hold throttle plate fully open. Crank engine and note compression pressure.

ApplicationMinimum psi (kg/cm 2 ) @ RPMStandard psi (kg/cm 2 ) @ RPM
B2300 B3000 & B4000(1)(1)
Mazda6
2.3L (2)139 (9.8) @ 285199 (14.0) @ 285
3.0L(1)(1)
Miata (2)146 (10.3) @ 300198 (13.9) @ 300
MPV(1)(1)
Protege & Protege5 (2)119 (8.4) @ 300171 (12.0) @ 300
Tribute
2.0L & 3.0L(1)(1)
(1) Lowest compression reading should not be less than 75 percent of highest compression reading. (2) Difference between cylinders should not be more than 28 psi (2.0 kg/cm 2 ).
(1)Lowest compression reading should not be less than 75 percent of highest compression reading.
(2)Difference between cylinders should not be more than 28 psi (2.0 kg/cm 2 ).

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Application(1) In. (mm)
Except Mazda6 2.3L, Miata, Protege, Protege5 & Tribute 2.0L(2)
Mazda6 2.3L
Intake.009-.011 (.23-.28)
Exhaust.011-.013 (.28-.33)
Miata
Intake.007-.009 (.18-.23)
Exhaust.011-.013 (.28-.33)
Protege & Protege5.009-.012 (.23-.30)
Tribute 2.0L
Intake.004-.007 (.11-.18)
Exhaust.011-.013 (.28-.33)
(1) Adjust valves with engine cold. (2) Engines are equipped with hydraulic valve lash adjusters. Valve clearance is not adjustable.
(1)Adjust valves with engine cold.
(2)Engines are equipped with hydraulic valve lash adjusters. Valve clearance is not adjustable.

VALVE CLEARANCE SPECIFICATIONS

IGNITION COIL

ApplicationPrimarySecondary
B2300, B3000 & B4000(1)(1)
Mazda6
2.3L.49-.579500-11,100
3.0L.54-.56(2) 5000-6000
Miata(1)7000-11,000
MPV105600
Protege & Protege5(1)7200-10,800
Tribute
2.0L(1)10,000-14,500
3.0L1010,000-14,500
(1) Information is not available from manufacturer. (2) Ohms @ 77°F (25°C).
(1)Information is not available from manufacturer.
(2)Ohms @ 77°F (25°C).

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

CRANKSHAFT POSITION SENSOR

ApplicationOhms @ 68°F (20°C)
B2300, B3000 & B4000300-800
Mazda6 2.3L400-550
Mazda6 3.0L & MPV315-385
Miata(1)
Protege & Protege5(2) 550
Tribute290-390
(1) Information is not available from manufacturer. (2) Specification given is approximate.
(1)Information is not available from manufacturer.
(2)Specification given is approximate.

CRANKSHAFT POSITION SENSOR RESISTANCE

HIGH TENSION WIRE RESISTANCE

Note. High tension lead resistance specification 2.0L Tribute is not available from manufacturer.

Mazda6 (2.3L)

High tension wire resistance should measure

  1. Cylinder No. 1 - 5900-13,600 ohms
  2. Cylinder No. 2 - 4900-11,500 ohms
  3. Cylinder No. 3 - 3800-8900 ohms
  4. Cylinder No. 4 - 3600-8500 ohms

Miata

Miata uses coil on plug configuration on cylinders No. 2 and 4. High tension lead for cylinder No. 1 should measure 5000-13,000 ohms. High tension lead for cylinder No. 3 should measure 1500-4000 ohms.

Protege & Protege5

Protege & Protege5 uses coil on plug configuration on cylinders No. 2 and 4. High tension lead for cylinder No. 1 should measure 5600-12,100 ohms. High tension lead for cylinder No. 3 should measure 1900-4000 ohms.

SPARK PLUGS

ApplicationNGK No.
B2300(1) AGSF-3ZFEM
B3000
Original
Left Side(1) AWSF-32P
Right Side(1) AWSF-32PG
Replacement(1) AWSF-32PP
B4000
Original
Left Side(1) AGSF-22P
Right Side(1) AGSF-22PG
Replacement(1) AGSF-22PP
Mazda6
2.3LITR6F-13
3.0L(1) AGSF-22FSCM
Miata(2) BKR5E-11 Or (3) BKR6E-11
MPV(1) AGSF-32WM
Protege & Protege5(2) BKR5E-11, (3) BKR6E-11 Or (4) PZFR6F
Tribute
2.0L
Cylinders No. 1 & 3(1) AZFS-32F
Cylinders No. 2 & 4(1) AZFS-32FE
3.0L(1) AWSF-32F
(1) Motorcraft spark plug number. (2) Standard plug. (3) Cold plug. (4) Turbocharged engine.
(1)Motorcraft spark plug number.
(2)Standard plug.
(3)Cold plug.
(4)Turbocharged engine.

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
B4000 (1).061-.068 (1.6-1.7)10-14 (14-20)
Mazda6 2.3L(2)10-14 (14-20)
Miata, Protege & Protege5.040-.043 (1.0-1.1)(3) 11-16 (15-22)
Tribute
2.0L.051 (1.3)11 (15)
3.0L.051-.055 (1.3-1.4)11 (15)
INCH Lbs. (N.m)
B2300.041-.045 (1.0-1.1)80-177 (9-20)
B3000 (1).042-.046 (1.1-1.2)80-177 (9-20)
Mazda6 3.0L(2)80-177 (9-20)
MPV.051-.055 (1.3-1.4)80-177 (9-20)
(1) If original spark plugs are removed for inspection and must be reinstalled, refer to Vehicle Emission Control Information Label for spark plug gap. (2) Information not available from manufacturer. (3) Turbocharged engine 8-17 (10-24).
(1)If original spark plugs are removed for inspection and must be reinstalled, refer to Vehicle Emission Control Information Label for spark plug gap.
(2)Information not available from manufacturer.
(3)Turbocharged engine 8-17 (10-24).

SPARK PLUG SPECIFICATIONS

FIRING ORDER

Note. Firing order information for Mazda6 is not available from manufacturer.

Note. Firing order and coil pack information (Scheme 2)- (Scheme 10)

Note. On Miata, Protege and Protege5, cylinders No. 1 and No. 4, and cylinders No. 2 and No. 3 are fired simultaneously (wasted spark).

Scheme 2

Scheme 2: Firing Order & Coil Pack (Tribute 2.0L)
Scheme 2: Firing Order & Coil Pack (Tribute 2.0L)

Scheme 3

Scheme 3: Firing Order & Coil Pack (B2300)
Scheme 3: Firing Order & Coil Pack (B2300)

Scheme 4

Scheme 4: Firing Order & Coil Pack (B3000 & B4000)
Scheme 4: Firing Order & Coil Pack (B3000 & B4000)

Scheme 5

Scheme 5: Firing Order (MPV & Tribute 3.0L Engine)
Scheme 5: Firing Order (MPV & Tribute 3.0L Engine)

Scheme 6

Scheme 6: Firing Order & Coils (Miata, Protege & Protege5)
Scheme 6: Firing Order & Coils (Miata, Protege & Protege5)

IGNITION TIMING

ApplicationMan. Trans.(1) Auto. Trans.
B2300 & B300010 @ Idle10 @ Idle
B4000(2)(2)
Mazda6
2.3L8 @ Idle8 @ Idle
3.0L10 @ Idle10 @ Idle
Miata6-18 @ 750-8506-18 @ 750-850
MPV (3)N/A4-16 @ 700-800
Protege & Protege56-18 @ 650-7506-18 @ 650-750
Tribute
2.0L8-12 @ IdleN/A
3.0LN/A(2)
(1) Place automatic transaxle/transmission in Park. (2) Information is not available from manufacturer. (3) Connect a jumper wire between terminals TEN and GND of data link connector. (Scheme 7)
(1)Place automatic transaxle/transmission in Park.
(2)Information is not available from manufacturer.
(3)Connect a jumper wire between terminals TEN and GND of data link connector. (Scheme 7)

IGNITION TIMING SPECIFICATIONS (Degrees BTDC @ RPM)

Scheme 7

Scheme 7
Scheme 7

IGNITION WIRE ROUTING

Note. On B3000 and B4000, ignition wire routing is not available from manufacturer.

Scheme 8

Scheme 8: Ignition Wire Routing (B2300 & Tribute 2.0L)
Scheme 8: Ignition Wire Routing (B2300 & Tribute 2.0L)

Scheme 9

Scheme 9: Ignition Wire Routing (Mazda6 2.3L)
Scheme 9: Ignition Wire Routing (Mazda6 2.3L)

Scheme 10

Scheme 10: Ignition Wire Routing (Miata 1.8L, Protege & Protege5 2.0L)
Scheme 10: Ignition Wire Routing (Miata 1.8L, Protege & Protege5 2.0L)

FUEL PUMP

ApplicationPressure - psi (kPa)
B2300, B3000 & B400030-56 (207-386)
Mazda6(1)
Miata92 (634)
MPV85-114 (586-786)
Protege & Protege564-92 (441-634)
Tribute70 (483)
(1) Information is not available from manufacturer.
(1)Information is not available from manufacturer.

MAXIMUM FUEL PUMP PRESSURE SPECIFICATIONS

Application(1) Pressure - psi (kPa)
B2300, B3000 & B400030-56 (207-386)
Mazda6
2.3L55-64 (379-441)
3.0L63-74 (434-510)
Miata53-61 (365-421)
MPV61-66 (421-455)
Protege & Protege5
With Vacuum Connected30-37 (207-255)
Without Vacuum38-46 (262-317)
Tribute55-70 (337-483)
(1) With engine idling.
(1)With engine idling.

REGULATED FUEL PRESSURE SPECIFICATIONS

INJECTOR RESISTANCE

ApplicationOhms
B230011-13
B30008.5-15.5
B400011-18
Mazda6
2.3L11.4-12.6
3.0L13.1-14.5
Miata12-13
MPV13.1-14.5
Protege & Protege514.2-14.8
Tribute11-18

INJECTOR RESISTANCE - OHMS @ 68°F (20°C)

IDLE SPEED & MIXTURE

Note. Idle mixture is not adjustable. If idle mixture is incorrect, see appropriate SELF-DIAGNOSTICS article.

ApplicationMan. Trans. RPM(1) Auto. Trans. RPM
B2300800-950800-950
B3000760-800880-920
B4000760-800760-830
Mazda6
2.3L600-700650-750
3.0L700-800700-800
Miata750-850750-850
MPVN/A700-800
Protege & Protege5650-750650-750
Tribute
2.0L800-900N/A
3.0LN/A730-750
(1) Place automatic transaxle/transmission in Park.
(1)Place automatic transaxle/transmission in Park.

IDLE SPEED SPECIFICATIONS

THROTTLE POSITION SENSOR

Note. For information on connector terminal identification and test conditions specified in the following tables, see THROTTLE POSITION SENSOR in ON-VEHICLE ADJUSTMENTS article.

Test Condition (1)Ohms
B2300, B3000, B4000, Mazda6 & Tribute(3)
Miata
Between Terminals "A" & "B"2500-5000
Between Terminals "B" & "C"200-1100
MPV (2)3200-4800
Protege & Protege5 (2)4000-6000
(1) With throttle closed. (2) Between terminals "A" & "C". (Scheme 11) (3) Information not available.
(1)With throttle closed.
(2)Between terminals "A" & "C". (Scheme 11)
(3)Information not available.

THROTTLE POSITION (TP) SENSOR RESISTANCE (ALL MODELS)

Scheme 11

Scheme 11
Scheme 11
ECM/PCM Wire Color (1)Closed Throttle Volts (2)(2) Wide Open Throttle Volts
B2300, B3000, B4000 & Tribute
Gray/White (89)0.494.65
Mazda6
2.3L
Sensor No. 1 (3M)0.40-0.604.25-4.75
Sensor No. 2 (3J)4.40-4.600.25-0.75
3.0L
Sensor No. 1 (89)4.16-4.750.30-1.28
Sensor No. 2 (63)0.31-1.054.23-4.64
Miata
Green/Black (4V)0.1-1.13.0-4.6
MPV
Brown/Yellow (89)0.7-1.24.0-5.0
Protege & Protege5
Brown/Yellow (89)0.1-1.13.0-4.6
(1) Measure voltage between ground and ECM/PCM terminal No. in parentheses. (2) Voltage measurement should change gradually and smoothly as throttle is opened.
(1)Measure voltage between ground and ECM/PCM terminal No. in parentheses.
(2)Voltage measurement should change gradually and smoothly as throttle is opened.

THROTTLE POSITION (TP) SENSOR VOLTAGE
