Engine Mechanical - Overhaul - 1.8L (Bp): Specifications Mazda MX-5 NB рестайлинг

Mechanical 9 illustrations

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Camshaft Pulley Bolt
Without Variable Valve Timing Actuator37-44 (50-60)
With Variable Valve Timing Actuator47-61 (63-83)
Connecting Rod Nuts35-37 (48-50)
Crankshaft Pulley Bolts9.1-12.6 (12.3-17.1)
Crankshaft Pulley Boss Bolt116-122 (157-166)
Cylinder Head Bolts (1) (2)56-60 (76-81)
Drive Plate/Flywheel Bolts72-75 (97-102)
Intake Manifold Nuts14-18 (19-25)
Lower Oil Control Valve Pipe Bolts (3)
Bolt 112-17 (16-23)
Bolt 226-35 (35-47)
Bolt 3(4)
Main Bearing Cap Bolts (1) (5)40-43 (54-58)
MBSP Bolts12-15 (16-21)
Oil Jet Bolt8.7-12.9 (11.8-17.6)
Oil Pressure Switch9-13 (11.8-17.6)
Oil Pump Bolts14-18 (19-25)
Pulley Boss Bolt116-122 (157-166)
Spark Plug11-16 (15-22)
Thermostat Housing Bolts14-18 (19-25)
Timing Belt Pulley Bolt28-38 (38-51)
Timing Belt Tensioner Bolt28-38 (38-51)
Water Pump Bolts14-18 (19-25)
INCH Lbs. (N.m)
Camshaft Cap Bolts (6)100-125 (11.3-14.2)
Cylinder Head Cover Bolts (7)44-78 (5-8.8)
End Plate Bolts69.5-95.4 (7.9-10.7)
Dipstick Tube Bolt71-97 (8-11)
Oil Control Valve Adapter Bolt70.8-97.3 (8-11)
Oil Control Valve Case Bolts (8)70.8-97.3 (8-11)
Oil Pan Bolts71-97 (8-11)
Oil Pump Cover Bolts52.2-77.8 (5.9-8.8)
Oil Strainer Bolts/Nut69.5-95.4 (7.9-10.7)
Rear Cover Bolt69.5-95.4 (7.9-10.7)
Seal Plate Bolts (9)69.5-95.4 (7.9-10.7)
Timing Case Cover Bolts (10)69.5-95.4 (7.9-10.7)
Upper Oil Control Valve Pipe Bolts (11)69.5-95.4 (7.9-10.7)
Variable Tumble Control System Shutter Valve Bolt69.5-95.4 (7.9-10.7)
Variable Valve Timing Actuator Cover Bolts35-53 (4-6)
Water Pump Pulley Bolts69.5-94.7 (7.9-10.7)
(1) Tighten to specification in 2 or 3 steps. (2) Tighten cylinder head bolts in sequence. (Scheme 5) (3) Tighten lower oil control valve pipe bolts in sequence. (Scheme 6) (4) Tighten to 71-97 INCH Lbs. (8-11 N.m). (5) Tighten main bearing bolts in sequence. (Scheme 7) (6) Tighten camshaft cap bolts in sequence. (Scheme 8) (7) Tighten cylinder head cover bolts in sequence. (Scheme 9) (8) Tighten oil control valve case assembly bolts in sequence. see scheme 136 (9) Tighten seal plate bolts in sequence. see scheme 137 (10) Tighten timing case cover bolts in sequence. see scheme 138 (11) Tighten upper oil control valve pipe bolts in sequence. see scheme 139
(1)Tighten to specification in 2 or 3 steps.
(2)Tighten cylinder head bolts in sequence. (Scheme 5)
(3)Tighten lower oil control valve pipe bolts in sequence. (Scheme 6)
(4)Tighten to 71-97 INCH Lbs. (8-11 N.m).
(5)Tighten main bearing bolts in sequence. (Scheme 7)
(6)Tighten camshaft cap bolts in sequence. (Scheme 8)
(7)Tighten cylinder head cover bolts in sequence. (Scheme 9)
(8)Tighten oil control valve case assembly bolts in sequence. see scheme 136
(9)Tighten seal plate bolts in sequence. see scheme 137
(10)Tighten timing case cover bolts in sequence. see scheme 138
(11)Tighten upper oil control valve pipe bolts in sequence. see scheme 139

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9
