Differential: Overview Mazda MX-5 NB рестайлинг

Scheme 1

Scheme 2

1. Remove the filter plug.
2. Verify that the oil is at the brim of the filler plug hole. If it is low, add the specified oil.
3. Install the filler plug. Tightening torque 40-53 N.m (29-39 ft.lbf)

Scheme 3

1. Remove the filler and drain plugs.
2. Drain the differential oil into a container.
3. Wipe the plugs clean.
4. Install the drain plug and a new washer. Tightening torque 40-53 N.m (29-39 ft.lbf)
5. Add the specified oil from the filler plug until the level reaches the brim of the plug hole. Specified oil Type (API service GL-5) Above-18°C (0°F):SAE 90 Below-18°C (0°F):SAE 80 Capacity (Approximate quantity): 1.00 L (1.06 US qt, 0.88 lmp qt)
6. Install the filler plug. Tightening torque 40-53 N.m (29-39 ft.lbf)

Scheme 4

1. On level ground, jack up the vehicle and support it on safety stands.
2. Drain the differential oil. NOTE: For easier installation, do not depress the brake pedal after removing the brake caliper component.
3. Remove the brake caliper component, then suspend the brake caliper component using a rope.
4. Remove the lower arm installation bolt and nut.
5. Pull the rear hub support from the drive shaft. NOTE: If the drive shaft will come out of the rear hub support easily, install a discarded nut onto the drive shaft so that the nut is flush with the end of the drive shaft. Tap the nut with a copper hammer to loosen the drive shaft from the wheel hub.
6. Remove the drive shaft from the differential. (See «DRIVE SHAFT REMOVAL NOTE»(/mazda/mx-5/nb-2001-2005/remont/axle-shafts/#drive-shaft) .)
7. Remove the oil seal.
8. Apply lithium-based grease to the new oil seal lip and install it using the SST.
9. Install a new clip onto the drive shaft. (See «DRIVE SHAFT INSTALLATION NOTE»(/mazda/mx-5/nb-2001-2005/remont/axle-shafts/#drive-shaft) .)
10. Install the lower arm installation bolt and nut. Tightening torque 54-76 N.m (40-56 ft.lbf)
11. Install the brake caliper component. Tightening torque 50-68 N.m (37-50 ft.lbf)
12. Add the specified oil. (See «DIFFERENTIAL OIL REPLACEMENT».)
13. Adjust the rear wheel alignment.

Scheme 5

1. Drain the differential oil.
2. Remove the crossmember bracket. (See «CROSSMEMBER BRACKET REMOVAL/INSTALLATION».)
3. Remove the main silencer. (See «EXHAUST SYSTEM REMOVAL/INSTALLATION»(/mazda/mx-5/nb-2001-2005/remont/exhaust/#exhaust-system) .)
4. Remove in the order indicated in the figure.
5. Install in the reverse order of removal.
6. Add the specified oil to the specified level. (See «DIFFERENTIAL OIL REPLACEMENT».)

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Disconnect the wire harness from the PPF.
2. Support the transmission with a jack.
3. Remove the PPF bracket.
4. Remove the differential-side bolts, and pry out the spacer.
5. Remove the differential mounting spacer. CAUTION: Removing the PPF spacers will reduce the performance of the PPF. Do not remove the PPF spacers. If the spacers are removed, replace the PPF as a component.
6. Remove the transmission-side bolts, and remove the PPF. NOTE: If the sleeve cannot be removed easily, tap the side of sleeve with a plastic hammer.
7. Remove the sleeve.
8. To prevent damaging the fire wall and engine mount, support the transmission as follows. Prepare a steel plate (as shown in the figure), a wooden block, bolts (M8x1.25), and washers. Install a wooden block as shown in the figure.

1. Support the differential using a jack.
2. Lower the differential and move it forward.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Install the differential mounting spacer. Tightening torque 38-51 N.m (28-38 ft.lbf)
2. Support the transmission horizontally with a jack.
3. Install the PPF, and tighten the transmission side bolt slightly.
4. Align the PPF of the differential side, and install the sleeve.
5. Install the spacer and bolt to the front side installation hole of the differential side.
6. Install the PPF installation bolt in the order as shown. Tightening torque 104-123 N.m (76.7-91.1 ft.lbf)
7. Install the PPF bracket (MT only) Tightening torque A: 104-123 N.m (76.7-91.1 ft.lbf) B: 37-53N.m (27-39 ft.lbf)
8. Remove the jack, and install the wiring harness.
9. Measure the length A as shown. Standard length MT: 60.0-72.0mm (2.36-2.38 in) AT: 50.5-62.5mm (1.99-2.46 in)
10. If not as specified, adjust the position of the PPF.

Scheme 19

1. Disassembly in the order indicated in the figure.
2. Assemble in the reverse order of disassembly.

Scheme 20

1. Strike the differential carrier with a plastic hammer to separate it from the case.

Scheme 21

1. Mount the differential gear component on the SSTs.
