Oil Pipe Installation Note Mazda MX-5 NB рестайлинг

Accessory Drive Belts 5 illustrations ~189 words
CAUTIONPerform the following procedures so that there is no load applied on each connection part while installing the oil pipe as it may cause oil leakage.

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47
  1. Hold the frame of the OCV filter and install the OCV so as to align with the projected part on flange end of the oil pipe.
  2. Apply engine oil to the new washer.
  3. Temporarily install the upper and side oil pipe and position the oil pipe.
  4. Tighten the oil pipe bolts for several times in the numerical order shown in the figure.
  5. Tighten the oil pipe bolts for several times on the portion A shown in the figure. Tightening torque 7.8-10.8 N.m {80-110 kgf.cm, 70-95 in.lbf}
  6. Temporarily tighten the oil pipe bolt on the portion B shown in the figure. Tightening torque 2.9-6.9 N.m {26-61 kgf.cm, 26-61 in.lbf}
  7. Temporarily tighten the oil pipe bolt on the portion C shown in the figure. Tightening torque 11.8-17.6 N.m {1.2-1.8 kgf.m, 8.7-13 ft.lbf}
  8. Tighten the oil pipe bolts for several times in the numerical order shown in the figure. Tightening torque No. 1, 2, 3, 4, 7: 7.8-10.8 N.m {80-110 kgf.cm, 70-95 in.lbf} No. 5: 15.7-23.5 N.m {1.6-2.3 kgf.m, 11.6-17.3 ft.lbf} No. 6:34.4-47.0 N.m {3.5-4.7 kgf.m, 25.4-34.6 ft.lbf}
