Engine Controls - Service & Adjustment Specifications: Overview Mazda MX-5 NB

FIRING ORDER & COIL IDENTIFICATION

Note. For firing order, refer to appropriate illustration. (Scheme 1)- (Scheme 9).

Firing Order & Coil Packs (B2500). Scheme 1

Firing Order & Coil Pack (B3000 & B4000). Scheme 2

Firing Order & Coil Packs (Miata 1.8L). Scheme 3

Firing Order (Millenia 2.3L). Scheme 4

Firing Order & Distributor Rotation (Millenia 2.5L). Scheme 5

Firing Order & Coil Pack (626 2.0L). Scheme 6

Firing Order & Coil Pack (626 2.5L). Scheme 7

Coil Identification (Protege 1.6L)

Note. Firing order for Protege 1.6L is 1-3-4-2; cylinder No. 1 is located on the passenger side of engine compartment.

Coil Identification (Protege 1.6L). Scheme 8

Coil Pack Identification (Protege 1.8L)

Note. Firing order for Protege 1.8L is 1-3-4-2; cylinder No. 1 is located on the passenger side of engine compartment.

Coil Pack Identification (Protege 1.8L). Scheme 9
