SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Compressor Type | Panasonic Rotary Vane | |
| Compressor Belt Deflection (1) | ||
| New | 5/16-23/64" (8-9 mm) | |
| Used | 23/64-25/64" (9-10 mm) | |
| Compressor Oil Capacity (2) | 5.1 ozs. | |
| Refrigerant (R-134a) Capacity | 21.2 ozs. | |
| System Operating Pressures (3) | ||
| High Side | 171-213 psi (12-15 kg/cm 2 ) | |
| Low Side | 14-28 psi (1.0-2.0 kg/cm 2 ) | |
| (1) Measure with 22 lbs. (10 kg) pressure applied to center of longest belt run. (2) Use Denso Oil 9 refrigerant oil. (3) Specification is with ambient temperature at 86°F (30°C). | ||
| (1) | Measure with 22 lbs. (10 kg) pressure applied to center of longest belt run. |
| (2) | Use Denso Oil 9 refrigerant oil. |
| (3) | Specification is with ambient temperature at 86°F (30°C). |
SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG SYSTEM SAFETY article in GENERAL SERVICING. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| A/C Compressor Mounting Bolt | 11-18 (15-24) |
| Evaporator Assembly Inlet (Fitting) | 11-18 (15-24) |
| Instrument Panel Bolts | 12-16 (16-22) |
| INCH Lbs. (N.m) | |
| Compressor Clutch Bolt | 71-98 (8-11) |
| Compressor Inlet & Outlet Bolt | 89-140 (10-16) |
| Evaporator Assembly Outlet (Fitting) | 89-169 (10-19) |
| Receiver-Drier Inlet & Outlet Nut | 89-169 (10-19) |
| Receiver-Drier Mounting Bolt | 62-89 (7-10) |
