SERVICE VALVE LOCATIONS
| Vehicle | High | Low | ||
|---|---|---|---|---|
| Acura | ||||
| Integra | (1) | (2) | ||
| SLX | (3) | (4) | ||
| 2.3CL | (3) | (4) | ||
| 3.0CL | (1) | (4) | ||
| 3.2TL | (1) | (4) | ||
| 3.5RL | (6) | (4) | ||
| Audi | ||||
| Except A8 | (7) | (7) | ||
| A8 | (16) | (4) | ||
| BMW | (8) | (9) | ||
| Honda | ||||
| Accord | (1) | (4) | ||
| Civic | (10) | (10) | ||
| CR-V | (11) | (2) | ||
| Odyssey | (10) | (10) | ||
| Passport | (12) | (13) | ||
| Prelude | (1) | (2) | ||
| Hyundai | ||||
| Accent | (3) | (5) | ||
| Elantra | (14) | (4) | ||
| Sonata | (14) | (4) | ||
| Tiburon | (14) | (4) | ||
| Infiniti | (14) | (4) | ||
| Isuzu | ||||
| Amigo & Rodeo | (12) | (13) | ||
| Hombre | (3) | (4) | ||
| Oasis | (10) | (10) | ||
| Trooper | (3) | (4) | ||
| Vehi-Cross | (11) | (13) | ||
| Jaguar | (6) | (4) | ||
| Kia | (3) | (4) | ||
| Land Rover | ||||
| Discovery | (3) | (4) | ||
| Range Rover | (8) | (4) | ||
| Lexus | ||||
| ES300, GS300, GS400, SC300 & SC400 | (16) | (4) | ||
| LS400 | (6) | (4) | ||
| LX470 | (10) | (4) | ||
| RX300 | (16) | (8) | ||
| Mazda | ||||
| B2300, B3000 & B4000 | (14) | (6) | ||
| Miata | (8) | (4) | ||
| Millenia | (14) | (4) | ||
| Protege | (3) | (4) | ||
| 626 | (15) | (4) | ||
| Mercedes-Benz | (16) | (6) | ||
| Mitsubishi | ||||
| Diamante | (3) | (4) | ||
| Eclipse | (3) | (4) | ||
| Galant | (3) | (4) | ||
| Mirage | (3) | (4) | ||
| Montero | (6) | (6) | ||
| Montero Sport | (3) | (4) | ||
| 3000GT | (1) | (4) | ||
| Nissan | ||||
| Altima | (3) | (4) | ||
| Frontier | (14) | (4) | ||
| Maxima | (14) | (4) | ||
| Pathfinder | (14) | (4) | ||
| Quest | (11) | (17) | ||
| Sentra & 200SX | (3) | (4) | ||
| Porsche | ||||
| 911 | (8) | (9) | ||
| Saab | (6) | (2) | ||
| Subaru | (18) | (18) | ||
| Suzuki | ||||
| Esteem | (14) | (4) | ||
| Vitara & Grand Vitara | (6) | (2) | ||
| Swift | (3) | (4) | ||
| Toyota | ||||
| Avalon | (1) | (4) | ||
| Camry, Camry Solara & Celica | (16) | (4) | ||
| Corolla | (14) | (4) | ||
| Land Cruiser | (10) | (4) | ||
| RAV4 | (10) | (13) | ||
| Sienna | (6) | (2) | ||
| Tacoma | (7) | (7) | ||
| 4Runner | (16) | (7) | ||
| Volkswagen | ||||
| Except Beetle | (7) | (7) | ||
| Beetle | (20) | (20) | ||
| Volvo | ||||
| C70, S70 & V70 | (19) | (19) | ||
| S80 | (20) | (20) | ||
| (1) On high pressure line, near receiver-drier. (2) On low pressure line, near top of condenser. (3) On high pressure line, between accumulator/receiver-drier and evaporator. (4) On low pressure line, between evaporator and compressor. (5) On low pressure line, near compressor. (6) On top of accumulator/receiver-drier. (7) On thin evaporator inlet (high pressure) line or thick outlet (low pressure) line. (8) On high pressure hose/line. (9) On low pressure hose/line. (10) On top of condenser, on right side. (11) On high pressure (thin) line, at rear of engine compartment. On Honda Passport or Isuzu Rodeo (Scheme 22) (12) On high pressure outlet at compressor. On Honda CR-V (Scheme 21) (13) On low pressure (thick) line, at rear of engine compartment. (14) On high pressure line, between compressor and condenser. (15) On high pressure hose/line between condenser and evaporator. (16) In front of condenser. (17) On low pressure line, between accumulator and compressor. (18) On high and low pressure lines, near compressor. (19) On low pressure line, near receiver-drier. Volvo uses only one service valve. (20) Information is not available from manufacturer. | ||||
| (1) | On high pressure line, near receiver-drier. |
| (2) | On low pressure line, near top of condenser. |
| (3) | On high pressure line, between accumulator/receiver-drier and evaporator. |
| (4) | On low pressure line, between evaporator and compressor. |
| (5) | On low pressure line, near compressor. |
| (6) | On top of accumulator/receiver-drier. |
| (7) | On thin evaporator inlet (high pressure) line or thick outlet (low pressure) line. |
| (8) | On high pressure hose/line. |
| (9) | On low pressure hose/line. |
| (10) | On top of condenser, on right side. |
| (11) | On high pressure (thin) line, at rear of engine compartment. On Honda Passport or Isuzu Rodeo (Scheme 22) |
| (12) | On high pressure outlet at compressor. On Honda CR-V (Scheme 21) |
| (13) | On low pressure (thick) line, at rear of engine compartment. |
| (14) | On high pressure line, between compressor and condenser. |
| (15) | On high pressure hose/line between condenser and evaporator. |
| (16) | In front of condenser. |
| (17) | On low pressure line, between accumulator and compressor. |
| (18) | On high and low pressure lines, near compressor. |
| (19) | On low pressure line, near receiver-drier. Volvo uses only one service valve. |
| (20) | Information is not available from manufacturer. |
